BB914...
Silicon Variable Capacitance Diode
•
For FM radio tuner with extended
frequency band
•
High tuning ratio at low supply voltage (car radio)
•
Monolitic chip (common cathode)
for perfect dual diode tracking
•
Good linearity for C- V curve
•
High figure of merit
•
Pb-free (RoHS compliant) package
1)
•
Qualified according AEC Q101
BB914
!
,
,
Type
BB914
Package
SOT23
Configuration
common cathode
L
S
(nH)
1.8
Marking
SM
Maximum Ratings
at
T
A
= 25°C, unless otherwise specified
Parameter
Diode reverse voltage
Peak reverse voltage
(
R
≥
5kΩ )
Forward current
Operating temperature range
Storage temperature
1
Pb-containing
Symbol
V
R
V
RM
I
F
T
op
T
stg
Value
18
20
50
-55 ... 125
-55 ... 150
Unit
V
mA
°C
package may be available upon special request
1
2007-04-20
BB914...
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Symbol
Values
Parameter
min.
DC Characteristics
Reverse current
V
R
= 16 V
V
R
= 16 V,
T
A
= 85 °C
AC Characteristics
Diode capacitance
V
R
= 2 V,
f
= 1 MHz
V
R
= 8 V,
f
= 1 MHz
C
T
Unit
max.
nA
20
200
typ.
-
-
I
R
-
-
pF
42.5
17.6
43.75
18.7
2.34
-
0.28
45
19.75
2.42
1.5
-
%
Ω
Capacitance ratio
V
R
= 2 V,
V
R
= 8 V,
f
= 1 MHz
C
T2
/
C
T8
2.28
-
-
Capacitance matching
1)
V
R
= 2 V,
V
R
= 8 V,
f
= 1 MHz
∆
C
T
/
C
T
r
S
Series resistance
V
R
= 2 V,
f
= 100 MHz
1
For
details please refer to Application Note 047.
2
2007-04-20
