BCM856S_07

Description
100 mA, 65 V, 2 CHANNEL, PNP, Si, SMALL SIGNAL TRANSISTOR
Categorysemiconductor    Discrete semiconductor
File Size90KB,9 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Download Datasheet Parametric Compare View All

BCM856S_07 Overview

100 mA, 65 V, 2 CHANNEL, PNP, Si, SMALL SIGNAL TRANSISTOR

BCM856S_07 Parametric

Parameter NameAttribute value
Number of terminals6
Transistor polarityPNP
Maximum collector current0.1000 A
Maximum Collector-Emitter Voltage65 V
Processing package descriptionROHS COMPLIANT PACKAGE-6
Lead-freeYes
EU RoHS regulationsYes
China RoHS regulationsYes
stateACTIVE
packaging shapeRECTANGULAR
Package SizeSMALL OUTLINE
surface mountYes
Terminal formGULL WING
terminal coatingMATTE TIN
Terminal locationDUAL
Packaging MaterialsPLASTIC/EPOXY
structureSEPARATE, 2 ELEMENTS
Number of components2
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
Maximum ambient power consumption0.2500 W
Transistor typeGENERAL PURPOSE SMALL SIGNAL
Minimum DC amplification factor200
Rated crossover frequency250 MHz
BCM856S
PNP Silicon AF Transistor Array
Precision matched transistor pair:
∆I
C
10%
For current mirror applications
Low collector-emitter saturation voltage
Two (galvanic) internal isolated Transistors
Complementary type: BCM846S
BC856S: For orientation in reel see
package information below
Pb-free (RoHS compliant) package
1)
Qualified according AEC Q101
4
5
6
1
2
3
C1
6
B2
5
E2
4
TR2
TR1
1
E1
2
B1
3
C2
EHA07175
Type
BCM856S
Maximum Ratings
Parameter
Marking
Pin Configuration
Package
3Ms
1=E1 2=B1 3=C2 4=E2 5=B2 6=C1 SOT363
Symbol
V
CEO
V
CES
V
CBO
V
EBO
I
C
I
CM
P
tot
T
j
T
stg
Value
65
80
80
5
100
200
250
150
-65 ... 150
Unit
V
Collector-emitter voltage
Collector-emitter voltage
Collector-base voltage
Emitter-base voltage
Collector current
Peak collector current
Total power dissipation-
T
S
= 115 °C
Junction temperature
Storage temperature
1
Pb-containing
mA
mW
°C
package may be available upon special request
1
2007-04-27
