0.5–18 GHz and 2–18 GHz
SUPER-SLIM HIGH PERFORMANCE
DROP-IN PIN SWITCHES
·
·
·
·
·
·
·
·
·
Reflective and Absorptive
SPST thru SP6T plus Transfer
High Speed
High Isolation—up to 80 dB
Low Insertion Loss
Super-Slim Packages
Drop-In Applications
Integral TTL Drivers
Hermetically Sealed
DESCRIPTION
The super-slim series of broadband hermetically sealed
switches offers fast switching speed and low insertion
loss in very compact packages. Both 0.5 to 18 GHz and 2
to 18 GHz models are available. The switches are gold
plated and have removable SMA connectors for use in
drop-in applications. Superior RF performance is achieved
over the entire bandwidth due to the use of selected PIN
diodes and optimum RF circuit designs.
All models include integral drivers with reverse voltage pro-
tection. The drivers are TTL compatible and are tailored to
each RF circuit to give optimum switching performance.
The small size, high speed, broad bandwidth and low in-
sertion loss make these switches ideal for EW systems,
automatic test equipment and simulators.
