RDC-19220S-303T

Description
Synchro or Resolver to Digital Converter, CMOS, PDIP40, 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40
CategoryAnalog mixed-signal IC    converter
File Size537KB,20 Pages
ManufacturerData Device Corporation
Download Datasheet Parametric Compare View All

RDC-19220S-303T Overview

Synchro or Resolver to Digital Converter, CMOS, PDIP40, 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40

RDC-19220S-303T Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerData Device Corporation
Parts packaging codeDIP
package instruction2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40
Contacts40
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresBUILT-IN-TEST; PROGRAMMABLE RESOLUTION
Maximum analog input voltage2.3 V
Maximum angular accuracy3 arc min
Converter typeSYNCHRO OR RESOLVER TO DIGITAL CONVERTER
JESD-30 codeR-PDIP-T40
JESD-609 codee0
length52.05 mm
Maximum negative supply voltage-5.25 V
Minimum negative supply voltage-4.75 V
Nominal negative supply voltage-5 V
Number of digits16
Number of functions1
Number of terminals40
Maximum operating temperature70 °C
Minimum operating temperature
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum seat height4.57 mm
Signal/output frequency10000 Hz
Maximum supply voltage5.25 V
Minimum supply voltage4.75 V
Nominal supply voltage5 V
surface mountNO
technologyCMOS
Temperature levelCOMMERCIAL
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum tracking rate18 rps
width15.24 mm
RDC-19220/2S
Make sure the next
Card you purchase
has...
TM
16-BIT MONOLITHIC TRACKING
RESOLVER-TO-DIGITAL CONVERTER
FEATURES
Accuracy up to 2.3 Arc Minutes
Internal Synthesized Reference
+5 Volt Only Option
Programmable:
- Resolution: 10-, 12-, 14-, or 16-Bit
- Bandwidth
- Tracking Rate
Differential Resolver Input Mode
Velocity Output Eliminates
Tachometer
Built-In-Test (BIT) Output,
No 180° Hangup
DESCRIPTION
The RDC-19220/2S is a low-cost versatile state-of-the-art 16-bit
monolithic Resolver-to-Digital Converter. This single chip converter
offers programmable features such as resolution, bandwidth and
velocity output scaling.
Resolution programming allows selection of 10, 12, 14, or 16 bits,
with accuracies to 2.3 minutes. This feature combines the high track-
ing rate of a 10-bit converter with the precision and low-speed veloc-
ity resolution of a 16-bit converter in one package.
The internal Synthesized Reference section eliminates errors due to
quadrature voltage. Previously, a 6 degree phase shift caused prob-
lems for a 16-bit converter. The synthesized reference capability
ensures operation with a phase shift up to 45 degrees.
The velocity output (VEL) from the RDC-19220/2S, which can be
used to replace a tachometer, is a 4 V signal referenced to ground.
The full-scale value of VEL is set by the user with a single resistor.
The RDC-19220/2S converter is available with operating temperature
ranges of 0° to +70°C, -40° to +85°C, and -55° to +125°C.
-55° to +125°C Operating
Temperature
APPLICATIONS
The low cost, small size, high accuracy, and versatile performance of
the RDC-19220/2S converter makes it ideal for use in modern high
performance industrial control systems. Typical applications include
motor control, radar antenna positioning, machine tool control, robot-
ics, and process control.
FOR MORE INFORMATION CONTACT:
Data Device Corporation
105 Wilbur Place
Bohemia, New York 11716
631-567-5600 Fax: 631-567-7358
www.ddc-web.com
Technical Support:
1-800-DDC-5757 ext. 7382
©
1999, 2000 Data Device Corporation

RDC-19220S-303T Related Products

RDC-19220S-303T RDC-19220S-203T RDC-19220S-202T RDC-19220S-302T
Description Synchro or Resolver to Digital Converter, CMOS, PDIP40, 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40 Synchro or Resolver to Digital Converter, CMOS, PDIP40, 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40 Synchro or Resolver to Digital Converter, CMOS, PDIP40, 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40 Synchro or Resolver to Digital Converter, CMOS, PDIP40, 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40
Is it Rohs certified? incompatible incompatible incompatible incompatible
Maker Data Device Corporation Data Device Corporation Data Device Corporation Data Device Corporation
Parts packaging code DIP DIP DIP DIP
package instruction 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40 2 X 0.600 INCH, 0.200 INCH HEIGHT, PLASTIC, DDIP-40
Contacts 40 40 40 40
Reach Compliance Code compliant compliant compliant compliant
ECCN code EAR99 EAR99 EAR99 EAR99
Other features BUILT-IN-TEST; PROGRAMMABLE RESOLUTION BUILT-IN-TEST; PROGRAMMABLE RESOLUTION BUILT-IN-TEST; PROGRAMMABLE RESOLUTION BUILT-IN-TEST; PROGRAMMABLE RESOLUTION
Maximum analog input voltage 2.3 V 2.3 V 2.3 V 2.3 V
Maximum angular accuracy 3 arc min 3 arc min 5 arc min 5 arc min
Converter type SYNCHRO OR RESOLVER TO DIGITAL CONVERTER SYNCHRO OR RESOLVER TO DIGITAL CONVERTER SYNCHRO OR RESOLVER TO DIGITAL CONVERTER SYNCHRO OR RESOLVER TO DIGITAL CONVERTER
JESD-30 code R-PDIP-T40 R-PDIP-T40 R-PDIP-T40 R-PDIP-T40
JESD-609 code e0 e0 e0 e0
length 52.05 mm 52.05 mm 52.05 mm 52.05 mm
Maximum negative supply voltage -5.25 V -5.25 V -5.25 V -5.25 V
Minimum negative supply voltage -4.75 V -4.75 V -4.75 V -4.75 V
Nominal negative supply voltage -5 V -5 V -5 V -5 V
Number of digits 16 16 16 16
Number of functions 1 1 1 1
Number of terminals 40 40 40 40
Maximum operating temperature 70 °C 85 °C 85 °C 70 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
encapsulated code DIP DIP DIP DIP
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form IN-LINE IN-LINE IN-LINE IN-LINE
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
Maximum seat height 4.57 mm 4.57 mm 4.57 mm 4.57 mm
Signal/output frequency 10000 Hz 10000 Hz 10000 Hz 10000 Hz
Maximum supply voltage 5.25 V 5.25 V 5.25 V 5.25 V
Minimum supply voltage 4.75 V 4.75 V 4.75 V 4.75 V
Nominal supply voltage 5 V 5 V 5 V 5 V
surface mount NO NO NO NO
technology CMOS CMOS CMOS CMOS
Temperature level COMMERCIAL INDUSTRIAL INDUSTRIAL COMMERCIAL
Terminal surface TIN LEAD TIN LEAD TIN LEAD TIN LEAD
Terminal form THROUGH-HOLE THROUGH-HOLE THROUGH-HOLE THROUGH-HOLE
Terminal pitch 2.54 mm 2.54 mm 2.54 mm 2.54 mm
Terminal location DUAL DUAL DUAL DUAL
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Maximum tracking rate 18 rps 18 rps 18 rps 18 rps
width 15.24 mm 15.24 mm 15.24 mm 15.24 mm
