CIRCUIT PROTECTORS
MICRO FUSE
CCP
STRUCTURE
1
2
3
4
External electrode
Fuse wire
(Al-alloy wire)
Internal electrode
(Cu, Ni plated)
Molding (epoxy resin)
IDENTIFICATION
TYPE
CCP 2B, CCP 2E
COATING COLOR
Black
MARKING
White, 2 digits
Products with Pb-free terminations
meet RoHS requirements
TYPE DESIGNATION (HOW TO ORDER)
Old Part No.
New Part No.
(Pb-free)
CCP
CCP
PRODUCT CODE
2E
2E
STYLE
2B: 1206
2E: 1210
Specifications given herein may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
38
38
FUSING
CURRENT
(see below)
TE
T
FUSING
MAGNIFICATION
‘Nil‘: 200%(2B), 250%(2E)
H: 200% (2E)
TE
TAPING*
TE, BK
*Please see “PACKAGING”
TERMINATION
SURFACE MATERIAL
T: Sn
Blank: Sn/Pb
FEATURES
■
Immediate cutting off against excessive current of circuit
without generation of heat and fuming
■
Excellent dimension accuracy, mountability
and shock-resistance due to plastic molding
■
Excellent terminal strength and solderability
due to metal electrode
■
Rated ambient temperature: + 70° C
■
Operation temperature range: -40° C . . . +125°C
■
Suitable for reflow and wave soldering
■
Awarded approvals: UL 248.14 File No. E131375
c-UL (CSA) C22.2 No. 248.14 File No. E131375
DIMENSIONS (mm)
SIZE
1206
1210
TYPE
CCP 2B
CCP 2E
L
3.2 ± 0.2
3.2 ± 0.2
W
1.6 ± 0.2
2.5 ± 0.2
t
1.2 ± 0.2
2.2 ± 0.2
a
1.2 ± 0.1
1.7 ± 0.1
b
0.8 ± 0.1
1.9 ± 0.1
c
0.6 ± 0.1
0.5 ± 0.1
RATING
SIZE
TYPE
CCP 2B 15
CCP 2B 20
CCP 2B 25
CCP 2B 30
CCP 2B 35
CCP 2B 40
CCP 2B 50
CCP 2B 63
CCP 2B 80
CCP 2B 100
CCP 2E 10
CCP 2E 13
CCP 2E 15
CCP 2E 20
CCP 2E 25
CCP 2E 30
CCP 2E 35
CCP 2E 38
CCP 2E 40
CCP 2E 45
CCP 2E 50
CCP 2E 63
CCP 2E 100
CCP 2E 10 H
CCP 2E 13 H
CCP 2E 15 H
CCP 2E 20 H
CCP 2E 25 H
CCP 2E 30 H
CCP 2E 35 H
CCP 2E 38 H
CCP 2E 40 H
CCP 2E 45 H
CCP 2E 50 H
CCP 2E 63 H
FUSING CHARACTERISTICS
RATED*
CURRENT
0.75 A
1.00 A
1.25 A
1.50 A
1.75 A
2.00 A
2.50 A
3.15 A
4.00 A
5.00 A
0.4 A
0.52 A
0.6 A
0.8 A
1.0 A
1.2 A
1.4 A
1.5 A
1.6 A
1.8 A
2.0 A
2.5 A
4.0 A
0.50 A
0.65 A
0.75 A
1.00 A
1.25 A
1.50 A
1.75 A
1.90 A
2.00 A
2.25 A
2.50 A
3.15 A
FUSING
CURRENT
1.5 A
2.0 A
2.5 A
3.0 A
3.5 A
4.0 A
5.0 A
6.3 A
8.0 A
10.0 A
1.0 A
1.3 A
1.5 A
2.0 A
2.5 A
3.0 A
3.5 A
3.8 A
4.0 A
4.5 A
5.0 A
6.25 A
10.0 A
1.0 A
1.3 A
1.5 A
2.0 A
2.5 A
3.0 A
3.5 A
3.8 A
4.0 A
4.5 A
5.0 A
6.3 A
FUSING
TIME
INTERNAL
RESISTANCE
(MAX.)
150 mΩ
100 mΩ
75 mΩ
60 mΩ
50 mΩ
45 mΩ
35 mΩ
23 mΩ
19 mΩ
15 mΩ
200 mΩ
170 mΩ
150 mΩ
100 mΩ
75 mΩ
60 mΩ
50 mΩ
48 mΩ
45 mΩ
40 mΩ
35 mΩ
23 mΩ
15 mΩ
200 mΩ
170 mΩ
150 mΩ
100 mΩ
75 mΩ
60 mΩ
50 mΩ
48 mΩ
45 mΩ
40 mΩ
35 mΩ
23 mΩ
RATED
VOLTAGE
(
AVERAGE
)
1206
NEW
NEW
Fusing current (A)
CCP2E • CCP2E H
open within
1 sec at
250% rated
current
1210
NEW
72 V
open within
1 sec at
200% rated
current
Fusing time (sec.)
Fusing current (A)
* Rated current needs to be derated if part is used at an higher ambient temperature than rated.
** High rated voltage (76V: 0.75A~2A, 40V: 2.5A~4A) is also available. Please call KOA.
