PTMA210152M: DescriptionWideband RF LDMOS Integrated Power Amplifier 15 W, 1800 鈥?2200 MHz; CategoryWireless rf/communication Radio frequency and microwave; File Size242KB，15 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric View All

PTMA210152M Overview

Wideband RF LDMOS Integrated Power Amplifier 15 W, 1800 鈥?2200 MHz

PTMA210152M Parametric

Parameter Name	Attribute value
Maker	Infineon
package instruction	15.90 X 11 MM, 3.35 MM HEIGHT, GREEN, PLASTIC, MO-166, 20 PIN
Reach Compliance Code	compli
Characteristic impedance	50 Ω
structure	COMPONENT
Gain	27.5 dB
Maximum input power (CW)	15 dBm
JESD-609 code	e3
Maximum operating frequency	2200 MHz
Minimum operating frequency	1800 MHz
RF/Microwave Device Types	NARROW BAND HIGH POWER
Terminal surface	MATTE TIN
Maximum voltage standing wave ratio	10

Preview

Download Datasheet

View All

PTMA210152M

Confidential, Limited Internal Distribution

Wideband RF LDMOS Integrated Power Amplifier

15 W, 1800 – 2200 MHz

Description

The PTMA210152M is a wideband, matched, 15-watt, 2-stage

LDMOS integrated amplifier intended for wideband driver

applications in the 1800 to 2200 MHz band. This device is offered in

a 20-lead thermally-enhanced overmolded package for cool and

reliable operation.

PTMA210152M

Package PG-DSO-20-63

Broadband Performance

= 28 V, I

DQ1

= 80 mA, I

DQ1

= 160 mA

Fixture Tuned For 2110 - 2170 MHz

-5

-10

Features

•

Designed for wide RF bandwidth and low memory

effects

Broadband input on-chip matching

Typical two-carrier WCDMA performance at

2140 MHz, 28 V, 7 W avg.

- Gain = 28.5 dB

- Efficiency = 33 %

- IMD3 = –32 dBc

Typical CW performance at 2140 MHz, 28 V

- Output power at P–1dB ~ 20 W

- Efficiency > 49%

Integrated ESD protection. Meets HBM Class 1B

(minimum), per JESD22-A114F

Capable of handling 10:1 VSWR @ 28 V,

15 W (CW) output power

Thermally-enhanced RoHS-compliant package

1500

1700

1900

2100

2300

Return Loss (dB)

Gain

Gain (dB)

•

Return Loss

-15

-20

-25

-30

2500

•

Frequency (MHz)

RF Characteristics

Two-carrier WCDMA Measurements

(not subject to production test—verified by design/characterization in Infineon test

fixture)

= 28 V, I

DQ1

= 80 mA, I

DQ2

= 160 mA, ƒ = 2110 – 2170 MHz, P

OUT

= 7 W average

Characteristic

Gain

Power Added Efficiency

Input Return Loss

Adjacent Channel Power Ratio

Intermodulation Distortion

OUT

Conditions

Symbol

Min

—

Typ

28.5

–14

–36

–32

Max

—

Unit

dBc

IRL

ACPR

IMD3

table continued next page

All published data at T

CASE

= 25°C unless otherwise indicated

ESD:

Electrostatic discharge sensitive device—observe handling precautions!

Data Sheet

1 of 15

Rev. 04, 2010-04-16

*See Infineon distributor for future availability.
