PKL 4110A PI / PKL 4110 PI
Advanced Specification
50A - 60A DC/DC Power Module
48V Input, 3.3V Output
• High Efficiency, 92% Typ
• High Power Density, 68 W/in
3
(3.3V @
60A)
• Fast Dynamic Response, 200 ms,
±250 mVpeak Typ.
• Low Output Ripple, 70mVp-p Typ.
• Wide input voltage range (36-75V)
• 1,500 V dc isolation voltage
• Max. case temperature +100°C
• UL 1950/UL
C
1950 Recognized
• TUV to EN 60950 Type Approved
• Demonstrated compliance with
isolation requirements equivalent to
Basic Insulation per UL 60950
• Patent Pending Paralleling Feature
• Heatsinks available as an option for
extended operation
The PKL 4000 series represents another one of
Ericsson's "industry first" achievements in the con-
tinuing development of our "Third Generation" of
high-density, high-efficiency power modules. The
PKL 4110A PI module packs 68W/in
3
at 92%
efficiency (3.3V @ 60A) in an half-brick footprint
that has been enhanced to include two additional
output pins for motherboard connection reliability at
this high power.
These breakthrough features come from using the
most advanced patented topology utilizing inte-
grated magnetics and synchronous rectification on a
low-resistivity multilayer PCB.
This product features fast dynamic response times
and low output ripple, which are important
parameters when supplying low-voltage logics.
The PKL 4000 PI Series also is especially well suited
for limited board space and high dynamic load
applications.
Ericsson's PKL 4000 Series Power Modules address
the converging "New Telecom" market, by specifying
the input voltage range in accor-dance with ETSI
specifications. The PKL 4000 Series also offers over-
voltage protection, under-voltage protection, over-
temperature protection, soft-start, paralleling, and
short circuit protection.
These modules are manufactured on highly
automated manufacturing lines. Ericsson's world-
class quality commitment is reflected in our standard
five year warranty. Ericsson Inc.,
Power Modules
has been an ISO 9001 certified Suplier since 1991.
For a complete product program, please reference the back
page.
E
General
Connections
Pin
1
2
3
4
5, 10
6
7
8
9, 11
Designation
-INPUT
CASE
REMOTE
ON/OFF
+INPUT
-OUTPUT
-SENSE
TRIM
+SENSE
+OUTPUT
Function
Negative input
Connected to base plate
Remote control (primary) to
turn-on and turn-off the output
Positive input.
Negative output (two pins)
Negative remote sense
Output voltage adjust
Positive remote sense
Positive output (two pins)
I
I rush
I
I max
Max. Input
Current
Inrush Current
Input capacitance
Input idling
power
Input stand-by
power
I
O
= 0 , T =–30…+95 °C
C
T
C
=–30…+95 °C,
RC Open
V
Ion
Input
T
C
<T
Cmax
unless otherwise specified
Characteristics
V
I
Input voltage
range
Turn-off input
voltage
Turn-on input
voltage
Ramping from higher
voltage
Ramping from lower
voltage
V
i
= V
i
min = 36 V
Conditions
min
36
typ
max
75
Units
V
d c
V
Ioff
31
33
V
d c
34
36
V
d c
PKL 4110A PI
PKL 4110 PI
6.5
5.5
1
A
dc
Note: If the remote sense is not needed the "-Sense" should be
connected to "-Out" and the "+Sense" should be
connected to "+Out."
Except Charging of C
I
3.5
A
dc
µF
Weight
C
I
P
Ii
P
RC
110 grams
Case
6
0.4
0.6
W
W
Aluminum base plate with metal standoffs.
Pins
Pin Material: Brass
Pin Plating: Tin/Lead over Nickel
Mechanical Data
2.42
[61,5] OVERALL LENGTH
0.19
[4,82]
0.20
[5,1]
0.50
[12,72]
-INPUT
-OUTPUT
2.042
[51,86]
0.21
[5,3]
PIN
EXT.
0.50
[12,7]
OVERALL
HEIGHT
0.50
[12,72
0.400
[10,16]
1.000
[25,40]
0.400
[10,16]
CASE
-SENSE
1.400
[35,56]
2.00
[50,8]
0.700
[17,78]
BOTTOM VIEW
REMOTE
ON/OFF
TRIM
1.000
[25,40]
+SENSE
+OUTPUT
+INPUT
1.400
[35,56]
0.040 [1,02] DIA. PLATED
BRASS PINS
TYPICAL 7 PLACES
2.40
[61,0]
OVERALL
WIDTH
0.137
[3,47]
M3 X [0,5] MOUNTING INSERTS
TYPICAL 4 PLACES
MAX. SCREW TORQUE: 3.9 IN-LBS.[0,44 N-M]
0.332
[8,42]
0.080 [2,06] DIA. PLATED
BRASS PINS
TYPICAL 4 PLACES
Dimensions: inches [mm]
Tolerances: .xx ± 0.02 [ ,x ± ,5]
.xxx ±0.010 [,xx ± ,25]
2
EN/LZT 108 5167 R1 ©Ericsson Inc., Power Modules , November 2002
08EN/
PKL 4110A PI / PKL 4110 PI
T
C
= –40…+100°C, V
I
= 36...75V unless otherwise specified.
Output
Characteristics
Output voltage initial
setting and accuracy
Output adjust range
V
O
Output voltage
tolerance band
Line regulation
Load regulation
V
t
t
t
t
s
I
O
r
r
Conditions
T
C
=+25 °C, V
I
= 53 V, I =I
Omax
O
I
O
=I
Omax
I
O
=0 to I
O max
I
O
=I
O m a x
V
I
= 53V, I
O
=0 to I
O max
,
Load step = 0.25 x I
Omax
di/dt = 1A/us
Device
min
All
All
All
All
All
All
All
3.25
2.64
3.2
Output
typ
3.3
max
3.35
3.63
3.4
Unit
V
V
V
mV
mV
mV
µs
V
Oi
5
5
+/-250
200
10
0
0
15
15
Load transient
voltage deviation
Load transient
recovery time
Start-up time
Output current
From V
I
connection to V
O
= 0.9
×
V
Onom
All
PKL 4110A PI
PKL 4110 PI
15
60
50
198
165
ms
A
P
Omax
Max output power
At V
O
= V
Onom
PKL 4110A PI
PKL 4110 PI
W
I
lim
Current limit threshold
V
O
= 0.96 V
Onom
@ T
C
<100
o
C
PKL 4110A PI
PKL 4110 PI
61.0
51.0
64.8
54.5
65
55
70
72.0
62.0
74
64
150
A
mV
p-p
dB
A
I
sc
Short circuit current
PKL 4110A PI
PKL 4110 PI
V
Oa c
SVR
OVP
Output ripple & noise
Supply voltage
rejection (ac)
Over voltage protection
I
O
=I
O max, f < 20 MHz
f < 1kHz
V
I
= 53V,
All
All
All
-50
3.9
4.4
5.0
V
Miscellaneous
Characteristics
η
P
d
f
S
Efficiency
Power dissapation
Conditions
I
O
= I
Omax
, V
I
= 53V, T
C
= +25
o
C
I
O
= I
Omax
, V
I
= 53V, T
C
= +25
o
C
I
O
= 0...1.0 x I
Omax
Device
All
PKL 4110A PI
PKL 4110 PI
All
min
typ
92
17.2
14.3
150
max
Unit
%
W
kHz
Switching frequency
Absolute Maximum Ratings
Characteristics
T
C
T
S
V
I
V
I S O
V
RC
I
2
t
Maximum Operating Case Temperature
Storage temperature
Input voltage:
Continuous
Transient (100ms)
Isolation voltage
(input to output test voltage)
Remote control voltage
Inrush transient
1,500
12
1
min
– 40
– 40
– 0.5
max
+100
+125
+80
+100
Unit
°C
°C
V dc
V dc
V dc
Vdc
A
2
s
Typical Characteristics
PKL 4110A PI & PKL 4110 PI Efficiency
95.0%
94.0%
93.0%
92.0%
Efficiency (%)
91.0%
90.0%
89.0%
88.0%
87.0%
86.0%
85.0%
84.0%
0
10
20
30
40
50
60
Output Current (A)
36V
53V
Stress in excess of Absolute Maximum Ratings may cause permanent
damage. Absolute Maximum Ratings, sometimes referred to as "no
destruction limits," are normally tested with one parameter at a time
exceeding the limits of output data or electrical characteristics. If exposed
to stress above these limits, function and performance may degrade in an
unspecified manner.
72V
EN/LZT 108 5167 R1 ©Ericsson Inc., Power Modules, November 2002
3
Product Program
V
I
V
O
/I
O
P
O
max
198W
165W
Ordering Number
PKL 4110A PI
PKL 4110 PI
48/60V 3.3V/60A
48/60V 3.3V/50A
The PKL 4000 DC/DC power modules will be
available with the different options listed in the
Product Options Table
Please check with the factory for availability.
Product Options
Option
Negative remote on/off
logic
Industry Standard Trim
(i.e. V
o
Adjust)
Positive remote on/off logic
Lead length 0.145"
±
0.010"
Suffix Example
-
T
P
LA
PKL 4110A PI
PKL 4110A PIT
PKL 4110A PIP
PKL 4110A PILA
Information given in this Advanced Specification is believed to be accurate
and reliable. No responsibility is assumed for the consequences of its use
for any infringement of patents or other rights of third parties that may result
from its use. No license is granted by implication or otherwise under any
patent or patent rights of Ericsson Power Modules. These products are
sold only according to Ericsson Power Modules' general conditions of
sale, unless otherwise confirmed in writing. Specifications are subject to
change without notice.
Ericsson Inc.,
Power Modules
1700 International Pkwy.
Richardson, Texas 75081
Phone: 877-374-2642
www.ericsson.com/powermoduless
The latest and most complete
information can be found on our website!
Preliminary
Advanced Specification
EN/LZT 108 5167 R1b
© Ericsson Inc.,
Power Modules, November,
2002
4
EN/LZT 108 5167 R1b ©Ericsson Inc., Power Modules , November 2002
