FEATURES AND SPECIFICATIONS
Features and Benefits
n
n
n
n
2 to 24 circuits
Holds wires for secure, reliable contact
Molded to length
High flammability rating
Electrical
Voltage: 300 V
Maximum Current: 15 Amp
Insulation Resistance: >5,000 Megaohms
5.08mm (.200”) Pitch
Beau Eurostyle®
Single-piece
Terminal Block
39880, 39884
Fixed
Mechanical
Rec . Tightening Torque:
5 in. lbs, .56 Nm
Operating Temperature: 110
o
C
Wire Strip Length: 1/4” or 6mm
Reference Information
UL :
CSA:
File No. E48521
Guide No. XCFR2
File No. 025562
Physical
Housing: Polyamide, UL94 V-0, black
Screws:
3mm Steel
Screw Plating: Zinc chromate
Contacts: Phosphor bronze
Contact Plating: Tin
Pressure Clamp: Brass
Pressure Clamp Plating: Nickel
Wire Range: 12 to 26 AWG, 2.5 to 0.2mm
2
9.86
.388”
88 Series
CATALOG DRAWING (FOR REFERENCE ONLY)
C
3988X-01XX
2.79
.11”
15.75
.620”
5.33
.21”
3.30
.13”
5.13
.202”
A
2.54
.100”
1.02
.04”
2.54
.100”
2.79
.11”
C
X
2.79
.11”
5.13
.202”
2.79
.11”
3988X-02XX
5.13
.202”
9.86
.388”
5.08
.200”
1.02
.04”
15.75
.620”
ORDERING INFORMATION AND DIMENSIONS
Order # (Engineering #)
Replace XX with # of circuits, 02-24
Vertical
Steel Screws
39880-01XX (8805XX)
# of
Circuits
2
3
4
5
6
7
8
9
10
11
12
13
A
in
.20
.40
.60
.80
1.00
1.20
1.40
1.60
1.80
2.00
2.20
2.40
mm
5.1
10.2
15.2
20.3
25.4
30.5
35.6
40.6
45.7
50.8
55.9
61.0
in
.40
.60
.80
1.00
1.20
1.40
1.60
1.80
2.00
2.20
2.40
2.60
Bronze Screws
39884-01XX (8805XX-49)
C
mm
10.2
15.2
20.3
25.4
30.5
35.6
40.6
45.7
50.8
55.9
61.0
66.0
Tin Plated
39880-02XX (8808XX)
# of
Circuits
14
15
16
17
18
19
20
21
22
23
24
A
in
2.60
2.80
3.00
3.20
3.40
3.60
3.80
4.00
4.20
4.40
4.60
mm
66.0
71.1
76.2
81.3
86.4
91.4
96.5
101.6
106.7
111.8
116.8
in
2.80
3.00
3.20
3.40
3.60
3.80
4.00
4.20
4.40
4.60
4.80
Right Angle
Gold Plated
39884-02XX (8808XX-49)
C
mm
71.1
76.2
81.3
86.4
91.4
96.5
101.6
106.7
111.8
116.8
121.9
*Consult factory for imprinting and other options
Molex Industrial Division
New England Operations
Gilford, NH 03249-6600
Phone
(603) 524-5101
Fax
(603) 524-1627
