PolySwitch®
PTC Devices
Overcurrent Protection Device
PRODUCT: RXEF250
DOCUMENT: SCD25227
REV LETTER: G
REV DATE: JULY 26, 2016
PAGE NO.: 1 OF 2
Specification Status: Released
Electrical Rating
Voltage: 72 V max (AC or DC)
Current: 40 A max (AC or DC)
Insulating Material:
Cured, Flame Retardant Epoxy
Polymer
meets UL94 V-0 Requirements
Lead Material:
20 AWG Tin Plated Copper
Marking:
Manufacturer’s Mark
X250
and Part Identification
Lot Identification
TABLE I. DIMENSIONS:
A
MIN
--
mm:
--
in*:
*Rounded off approximation
(0.82)
--
(1.00)
(0.37)
(0.43)
(0.30)
--
--
(0.12)
MAX
20.8
MIN
--
B
MAX
25.4
MIN
9.4
C
MAX
10.9
MIN
7.6
D
MAX
--
MIN
--
E
MAX
3.0
TABLE II. PERFORMANCE RATINGS :
I HOLD
RATED
CURRENT
CURRENT
RATINGS
INITIAL
RESISTANCE
VALUES
TIME TO TRIP
ONE HOUR
POST-TRIP
RESISTANCE
STANDARD TRIP
OHMS
AT 20C
MAX
0.13
TRIPPED- STATE
POWER DISSIPATION
AMPERES
AMPERES
OHMS
SECONDS AT
WATTS
WATTS
AT 20C
AT 20C
AT 20C
20C, 12.5A
AT 20C
AT 20C
HOLD
HOLD
TRIP
MIN
MAX
MAX
NOMINAL
MAX
2.50
2.50
5.00
0.05
0.08
15.6
2.5
3.38
Agency Recognitions
UL, CSA, TUV, CQC
Reference Documents:
PS300
Precedence:
This specification takes precedence over documents referenced herein.
Effectivity:
Reference documents shall be the issue in effect on the date of invitation for bid.
CAUTION:
Operation beyond the rated voltage or current may result in rupture, electrical arcing or flame.
Materials Information
ROHS Compliant
ELV Compliant
Pb-Free
Halogen Free*
HF
* Halogen Free refers to: Br≤900ppm, Cl≤900ppm, Br+Cl≤1500ppm.
© 2016 Littelfuse,Inc.
Specifications are subject to change without notice.
Revised July 26, 2016
