RL-1233
AIR CORE INDUCTORS
BOBBIN WOUND
DESCRIPTION
• Air Core Inductors
FEATURES & APPLICATIONS
• 38 different values ranging from 0.56 µH to 680 µH with
current rating, depending on type, from 0.8 A to 8 A
• Handles high currents without saturating as metal core
inductors would
• Supplied ready for PCB insertion or, as an option, with
flying leads for wiring directly into circuits
• Typical applications include: power line filters, switching
regulated power supplies, audio filters, speaker crossover
networks, power amplifiers and power RF suppression circuits
Verify operation with sample in actual circuit. Order samples at www.rencousa.com.
ENVIRONMENTAL DATA
•
•
Storage temperature range:
-55°C to +130°C
Operating temperature range:
-40°C to +130°C
PACKAGING INFORMATION
• Packaging information: pg. 493
MECHANICAL DIMENSIONS
U.S. Standard (mm)
PART NUMBER
RL-1233
A (TYP.)
0.56 (14.22)
B (MIN.)
0.50 (12.70)
C
See Table
D (MAX.)
1.16 (29.46)
E (MAX.)
0.63 (16.00)
PART NUMBER
RL-1233
PART WEIGHT
23.0g (0.81oz)
FRONT VIEW
BOTTOM VIEW
1
SCHEMATIC
A
D
B
(2PL)
1
C
2
E
TIN TO
WITHIN
0.06 (1.524)
2
RENCO ELECTRONICS INC.
595 International Place, Rockledge, FL 32955-4200 USA • www.rencousa.com • ISO 9001 Certified
Toll Free Engineering Hot Line: 800.645.5828 • P: 321.637.1000 • F: 321.637.1600
INDUCTORS
RL-1233
Renco Part No.
RL-1233
RL-1233-0.56
RL-1233-0.68
RL-1233-0.82
RL-1233-1.0
RL-1233-1.2
RL-1233-1.5
RL-1233-1.8
RL-1233-2.2
RL-1233-2.7
RL-1233-3.3
RL-1233-3.9
RL-1233-4.7
RL-1233-5.6
RL-1233-6.8
RL-1233-8.2
RL-1233-10
RL-1233-12
RL-1233-15
RL-1233-18
RL-1233-22
RL-1233-27
RL-1233-33
RL-1233-39
RL-1233-47
RL-1233-56
RL-1233-68
RL-1233-82
RL-1233-100
RL-1233-120
RL-1233-150
RL-1233-180
RL-1233-220
RL-1233-270
RL-1233-330
RL-1233-390
RL-1233-470
RL-1233-560
RL-1233-680
Inductance
(µH)
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
560.0
680.0
Max. DCR
(Ohms)
0.006
0.007
0.008
0.009
0.010
0.011
0.013
0.014
0.015
0.016
0.017
0.019
0.022
0.024
0.026
0.030
0.033
0.038
0.039
0.053
0.075
0.080
0.090
0.100
0.135
0.151
0.166
0.230
0.255
0.285
0.395
0.542
0.617
0.830
0.907
0.978
1.375
1.525
Irms
(A)
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
8.0
4.0
3.5
3.5
3.5
3.5
2.5
2.5
2.5
2.0
2.0
2.0
1.5
1.3
1.3
1.0
1.0
1.0
0.8
0.8
“C”
DIM Ref.
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.823 (20.90)
0.915 (23.24)
0.862 (21.89)
0.862 (21.89)
0.862 (21.89)
0.862 (21.89)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.957 (24.31)
0.925 (23.50)
NOTES:
1. INDUCTANCE VALUES ± 15% TESTED AT 10 kHz, 0.1 Vrms. VALUES BELOW 10µH ARE ±20%
2. ELECTRICAL SPECIFICATIONS MEASURED AT 25ºC
3. Irms - CURRENT THAT CAUSES THE TEMPERATURE TO
RISE APPROX. 40ºC ABOVE AMBIENT OF 25ºC
