MCO-2S
SMD Clock Oscillator
HCMOS / TTL
Features
Applications: telecommunications, instrumentation, automotive
Miniature package: 6.0 x 3.5 x 1.4 mm
Frequency up to 125 MHz
High shock and vibration resistant
Parameter
Frequency range
Standard frequencies
Supply voltage
Supply current
Frequency stability (*)
Output signal
Output level
Output load
Jitter (rms)
Symmetry
Rise / fall time
Tri-state function
Operating temperature range
Specification
MCO-2S25
2 ~ 125 MHz
16.00, 16.384, 20.00, 24.576, 32.00, 40.00 & 48.0 MHz
+2.5 V
5
%
< 16 mA
±10 ppm
±20 ppm
V
OH
0.9 Vdc
15 pF / 10LS TTL
< 1 ps
45 ~ 55 %
+3.3 V
5
%
35 mA
-20 ~ +70 °C
-40 ~ +85 °C
HCMOS / TTL compatible
V
OL
0.1 Vdc
15 ~ 50 pF / 10 TTL
@ ½ Vdc
MCO-2S3
@ 12 kHz ~ 20 MHz from carrier frequency
Storage temperature range
Packaging units
(*) All inclusive:
Customer specifications on request
3 ~ 8 ns
pin #1 = high or open
pin #3
signal
pin #1 = low
pin #3
high impedance
-20 ~ +70 °C
standard application
-40 ~ +85 °C
industrial application
-40 ~ +125 °C
automotive application
-55 ~ +125 °C
tape & reel
1’000 pieces
frequency stability vs. temperature, tolerance, aging, supply & load variation, on request
Pin function
#1
#2
#3
#4
Tri-state
GND
Output
Vdc
Example for solder pattern
Do not design any conductive path between the pattern
Example for IR reflow soldering temperature
2002/95/EC RoHS compliant
QuartzCom AG
sales@quartzcom.com
www.quartzcom.com
QuartzCom Asia
sales-asia@quartzcom.com
QuartzCom USA
sales-usa@quartzcom.com
20 Apr. 10
