V585ME41-LF
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B | Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev A1
-60
-70
-80
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
Applications
•
CATV Headend
•
Test Equipment
•
Downconvertors
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
-90
-100
-110
-120
-130
1000
10000
100000
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (14 dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Additional Notes
Min
720
Typ
-98
-12
Max
1750
Units
MHz
dBc/Hz
dBc
0.75
58
2
5.5
50
21
9
150
2
8
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
-40
MINI-14S-L
Min
Typ
5
18
85
Max
24
Units
Vdc
mA
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
1900
V585ME41-LF
Rev A1
FREQUENCY (MHz)
1700
1500
1300
1100
900
700
500
0
1.5
3
4.5
6
7.5
9
10.5
12
13.5
15
16.5
18
19.5
21
85 °C
25 °C
-40 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
Footprint
RECOMMENDED FOOTPRINT
14
12
10
8
6
4
2
0
591
POWER OUTPUT (dBm)
SEVERAL HOLES OF O 0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
0.030 MIN. CUTBACK
FROM LIVE PADS
735 844
945 1038 1125 1208 1290 1371 1451 1528 1601 1666 1724 1771
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
Physical Dimensions
PIN CONFIGURATION
Z-COMM
XXXXXXXX-LF
W/O#
D/C
P1
P2
P3
REST
Vt
RF OUT
Vcc
GROUND
PACKAGE
MINI-14S
MINI-14S-L
H
0.220
0.130
MINI-14S-LOW 0.160
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
