V613ME20-LF
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B | Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev B2
-60
-70
-80
-90
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
Applications
•
Spread Spectrum Radios
•
Earthstations
•
Downconvertors
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
-100
-110
-120
-130
-140
-150
1 E+3
10 E+3
100 E+3
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (14 dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Additional Notes
Min
1785
Typ
-103
-30
Max
1900
Units
MHz
dBc/Hz
dBc
0.5
49
0
2.5
50
4.5
5
50
2
7
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
-30
MINI-14S
Min
Typ
4.75
17
85
Max
20
Units
Vdc
mA
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
V613ME20-LF
Rev B2
1960
1945
1930
1915
1900
1885
1870
1855
1840
1825
1810
1795
1780
1765
1750
1735
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
FREQUENCY (MHz)
85 °C
25 °C
-30 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
Footprint
RECOMMENDED FOOTPRINT
7
6
5
4
3
2
1
0
1743
SEVERAL HOLES OF O 0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
POWER OUTPUT (dBm)
0.030 MIN. CUTBACK
FROM LIVE PADS
1775
1807
1842
1879
1917
1951
FREQUENCY (MHz)
85 °C
25 °C
-30 °C
Physical Dimensions
PIN CONFIGURATION
Z-COMM
XXXXXXXX-LF
W/O#
D/C
P1
P2
P3
REST
Vt
RF OUT
Vcc
GROUND
PACKAGE
MINI-14S
MINI-14S-L
H
0.220
0.130
MINI-14S-LOW 0.160
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
