TX5-256SL
SMD TCXO
Sine wave
Features
Applications: mobile communications, instrumentation, broadcast
Frequency range up to 200 MHz
Tight frequency stability vs. temperature
Low phase noise
Parameter
Frequency range
Standard frequencies
Frequency stability:
vs. temperature
vs. supply & load change
vs. aging
Frequency tolerance ex. factory
Supply voltage
Supply current
Output signal
Output level
Output load
Frequency adjustment
Phase noise @ 20.0 MHz carrier frequency
Operating temperature range
Storage temperature range
Packaging units
Customer specifications on request
Specification
TX5-256SL3
TX5-256SL5
9.6 ~ 200 MHz
10.00, 12.80, 15.36, 16.384, 20.00, 26.00 & 27.00 MHz
≤ ±0.5
~
±2.5
ppm
≤ ±0.2
ppm
≤ ±1.0
ppm
≤ ±0.5
ppm
+3.3 V
±5
%
1.5 ~ 20 mA
sine wave
0 dBm
> ±5 ppm
-145 dBc/Hz
-20 ~ +70 °
C
-40 ~ +85 °
C
tape & reel
tray
3 ~ 7 dBm
50
Ω
with internal trimmer
@ 1 kHz
commercial application
industrial application
-55 ~ +125 °
C
500 pieces
50 pieces
±5
%
1 year
@ +25 °
C
+5.0 V
±5
%
st
Pin function
# 1
# 7
# 8
# 14
not connected
GND
Output
Vdc
Example for solder pattern
Do not design any conductive path between the pattern
Example for IR reflow soldering temperature
2002/95/EC RoHS compliant
QuartzCom AG
sales@quartzcom.com
www.quartzcom.com
QuartzCom Asia
sales-asia@quartzcom.com
QuartzCom USA
sales-usa@quartzcom.com
30 Apr. 10
