Specifications
1
Ordering Information
NAT500 -
Calibration Wavelength
8
8/13
13
13/15
15
15/16
16
850 nm
1
850 and 1310 nm
1310 nm
1310 and 1550 nm
1550 nm
1550 and 1610 nm
1610 nm
9/125 Corning SMF-28
50/125 multimode fiber
62/125 multimode fiber
FC/SPC
FC/APC
FC/UPC
SC/SPC
SC/APC
SC/UPC
ST/SPC
ST/UPC
LC/UPC
None
1 meter
Specify X meters
1
Precision Variable Attenuator
DiCon’s Precision Variable Attenuator is a TTL-driven
component which sets attenuation levels in the 0 to 30 dB
range with superior repeatability and absolute accuracy. The
attenuation level is set using a high-precision motor with either
the I
2
C standard interface or a proprietary Step-Up/Step-Down
interface.
Attenuation range
2
Resolution
Repeatability
Absolute accuracy
3
Insertion loss
PDL
4
Back-reflection
4
Flatness
5
Tuning speed
Optical power
Operating temperature
Storage temperature
Humidity
Power requirements
Fiber jacket
1.
2.
3.
4.
5.
6.
6
0-30 dB max.
0.1 dB max.
±0.01 dB max.
±0.1 dB max.
0.8 dB typ., 1.3 dB max.
0.2 dB max.
-50 dB max.
±0.1 dB max.
50 ms min., 1400 ms max.
300 mW max.
0°C to +50°C
-20°C +70°C
40°C/90%RH/5 days
+12 VDC, 250 mA max.
0.9 mm tight buffer
-
-
-
Fiber Type
9
50
62
FC
FC/APC
FC/UPC
SC
SC/APC
SC/UPC
ST
ST/UPC
LC
N
1
X
Connector Type
All specifications referenced without connectors.
For 60 dB attenuation range, see 60 dB Variable Attenuator datasheet.
At calibration wavelength.
Singlemode fiber only.
Within 100 nm window centered around calibration wavelength.
+5 VDC, 500 mA version available upon request.
Features
•
•
•
•
•
New Product
Housing Dimensions
Superior repeatability and absolute accuracy
Singlemode or multimode fiber type
Up to two calibration wavelengths
Direct motor control or absolute attenuation setting
Compatible with 60 dB Variable Attenuator
Pigtail Length
1. Multimode fiber only.
12-
PIN RIGHT ANGLE HEADER
PIN 1
OUTPUT
Precision Variable Attenuators can be used to adjust the power level
in automated test systems. Applications include bit error rate
testing of transmitters and receivers as well as channel equalization
in testing of WDM systems.
INPUT
Units: mm
Electrical connector is 12-pin right-angle header (Molex part number 22-
12-2124). Mate with Molex part number 22-01-3127 or equivalent.
U.S. patented. Specifications subject to change. Copyright ©2001 DiCon Fiberoptics, Inc. All rights reserved.
DiCon Fiberoptics, Inc. 1689 Regatta Blvd. Richmond, CA 94804
Tel. (510)620-5000
Fax. (510)620-4100
www.diconfiber.com
11/2
