VXO-1S-DS-6p
SMD VCXO
LVDS
Features
Applications: wireless communications, 10 Gigabit Ethernet, SDH,
SONET, Fibre Channel, DSL, GPON
Output frequency up to 312.5 MHz
Low jitter < 0.5 ps
Parameter
Frequency range
Standard frequencies
Supply voltage
Supply current
Frequency stability
(all inclusive) (*)
Output signal
Output voltage
Output load
Symmetry
Rise / Fall time
Frequency pulling range
Voltage control
Enable / Disable function
Jitter (rms)
Operating temperature range
Packaging units
(*) All inclusive
Customer specifications on request
Specification
VXO-1S25-DS-6p
VXO-1S3-DS-6p
19.44 ~ 312.5 MHz
19.44, 76.80, 77.76, 106.25, 120.00, 122.88, 125.00, 153.60, 155.52
156.25, 159.375, 161.1328, 200.00, 212.5 & 256.00 MHz
+2.5 V
±5
%
30 ~ 75 mA
<
±25
ppm
<
±50
ppm
V
OH
≤
1.60 V
45 ~ 55 %
over -20 ~ +70 °C
over -40 ~ +85 °C
LVDS
V
OL
≥
0.9 V
100
Ω
@ ½ Vdc
1 ~ 3 ns
±50
~
±100
ppm
+1.25 V
±1.25
V
Pin #2 = high or open
Pin #2 = low
< 0.5 ps
Pin #4 & #5
Pin #4 & #5
+1.65 V
±1.35
V
(E) signal
(D) no signal
+3.3 V
±5
%
@ 12 kHz ~ 20 MHz from carrier frequency
commercial application
industrial application
500 or 1’000 pieces
-20 ~ +70 °C
-40 ~ +85 °C
tape & reel
frequency stability vs. temperature, tolerance, aging, supply & load variation
Pin function
#1
#2
#3
#4
#5
#6
Vc Voltage control
E/D
GND
Output
Complementary output
Vdc
Example for solder pattern
Do not design any conductive path between the pattern
Example for IR reflow soldering temperature
2002/95/EC RoHS compliant
QuartzCom AG
sales@quartzcom.com
www.quartzcom.com
QuartzCom Asia
sales-asia@quartzcom.com
QuartzCom USA
sales-usa@quartzcom.com
31 Mar. 10
