MAX4537CSE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> MAX4537CSE

MAX4537CSE: DescriptionQUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDSO16, 0.150 INCH, MS-012C, SOIC-16; CategoryAnalog mixed-signal IC The signal circuit; File Size1MB，12 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

MAX4537CSE Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MAX4537CSE	-	-	View	Buy Now

MAX4537CSE Overview

QUAD 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDSO16, 0.150 INCH, MS-012C, SOIC-16

MAX4537CSE Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SOIC
package instruction	SOP,
Contacts	16
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SPST
JESD-30 code	R-PDSO-G16
JESD-609 code	e0
length	9.9 mm
Humidity sensitivity level	1
Maximum negative supply voltage (Vsup)	-6 V
Negative supply voltage minimum (Vsup)	-2 V
Nominal Negative Supply Voltage (Vsup)	-5 V
Number of channels	1
Number of functions	4
Number of terminals	16
Nominal off-state isolation	65 dB
On-state resistance matching specifications	4 Ω
Maximum on-state resistance (Ron)	100 Ω
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Maximum seat height	1.75 mm
Maximum supply voltage (Vsup)	6 V
Minimum supply voltage (Vsup)	2 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
Maximum disconnect time	50 ns
Maximum connection time	100 ns
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	20
width	3.9 mm
