Power Inductor
CDH20D09D,CDH20D11D,
CDH20D14D
■
Features
◎
Magnetically unshielded construction.
◎
Land pattern is compatible to Chip 2012 size.
◎
Storage temperature range:-40℃~+105℃.
◎
Operating temperature range:-40℃~+105℃(including coil’s self-
heat).
◎
RoHS Compliance.
■
Applications
Ideally used in Mobilephone,PDA,MP3,DSC/DVC,HDD,etc as
converter inductor.
■
Shapes and Dimensions/Recommended Land Patterns(mm)
◆
Dimensions (mm)
1.8
2.15
*H
0.7
2.2
0.5
◆
Land pattern
*H CDH20D09D: 1.0mm Max;
CDH20D11D: 1.2mm Max;
CDH20D14D: 1.5mm Max.
2.2
2.2
1
Power Inductor
CDH20D09D,CDH20D11D,
CDH20D14D
■
Electrical Characteristics specification.
◆
CDH20D14D
CDH20D14DNP-R72NC
CDH20D14DNP-1R0NC
CDH20D14DNP-1R5NC
CDH20D14DNP-2R2MC
CDH20D14DNP-3R3MC
CDH20D14DNP-4R7MC
CDH20D14DNP-6R8MC
CDH20D14DNP-100MC
CDH20D14DNP-150MC
0.72 30%
1.0 30%
1.5 30%
2.2 20%
3.3 20%
4.7 20%
6.8 20%
10 20%
15 20%
56 25%
68 25%
100 20%
175 20%
215 20%
265 20%
385 20%
765 20%
1000 20%
1 Saturation Current: This indicates the value of D.C. current when the inductance decreases to 70% of
its nominal value.
2 Temperature Rise Current: The actual current when temperature of coil becomes T=40 .(Ta=20 )
