The NANO Line - .025" Contact Spacing
NANO contacts incorporate the highly reli-
able Twist Pin concept, which allows conti-
nuity in very dense areas and under severe
shock and vibration, requiring low engage-
ment and separation forces. Termination
can consist of uninsulated pigtails or insu-
lated wire all pre-harnessed at our factory
to your specifications.
Due to various industry application require-
ments the NANO line is available in several
different configurations, available in strip,
metal shell and plastic, rectangular or cir-
cular configurations with center jackscrew.
Successful applications for NANO connec-
tors are many and varied, from the Air
Force's AIRS program to actual human
implantations in the medical research field.
Specifications
• Contact Rating - 1 amp max.
• Minimum contact centers - 0.025 (0.64).
• Wire sizes - #32 AWG stranded, #30 AWG solid.
• Contact termination - integral pigtail or multiple indent crimp.
• Contact rentention - fixed via epoxy.
• Contact materials - socket: nickel silver.
pin bundle: precious metal alloy or BeCu.
pin Sleeve: nickel silver or cartridge brass.
• Mating/unmating force - 6oz. per contact max.
Insulator
No. of Contacts
Pin Bundle
Material
Socket Sleeve
Material
Pin Sleeve
Material
Phenolic
1-40
Contacts
Shell
Type
NTP
Single Row
Strip
NDM
Metal Shell
Rectangular
Alum. alloy
2024 T351 per
QQ-A-250 or
6061-T6 per
QQ-A-200
nickel plate
Phenolic
9, 15, 21, 25
31, 37
Polyester
9, 24, 44
Polyester
27, 72, 266
NJS
NJSC
Rectangular
Circular
Center Jackscrew Center Jackscrew
- Precious metal per ASTM B477 and ASTM B541, or BeCu per CDA alloy 172 & 102 -
- Nickel silver/ASTM B122, Comp. B-
- Nickel silver per ASTM B122, Comp. B or Cartridge Brass per CDA alloy 260 -
Test Data
The table below summarizes the results of key tests
performed in accordance with MIL-STD-202, where
applicable. Data is applicable to standard connec-
Test
Dielectric Withstanding
Voltage
Insulation Resistance
Thermal Shock
Physical Shock
Method
Method 301:
350 VAC at sea level
100 VAC at 70,000' altitude
Method 302, Condition A
Method 107, Condition B:
-65˚C to +125˚C
Method 213, Condition I:
100 G's, 3-axes, 6 millisecond
duration sawtooth pluse
Method 204, Condition D:
15 G's, 10-2,000 Hz, 12 hours
500 cycles of mating and
unmating, 500 CPH max.
Method 106, omit 7b
Method 101, Condition B:
48 hours
Method 307:
At 1 amp
At 100 milliamps
Contact Retention
-
tor with standard terminations. Variations may
affect this data, so please consult the factory for
further information on your requirements.
Criteria of Acceptance
No breakdown
No breakdown
5,000 megohms minium
No physical damage
No physical damge
No loss of continuity > 1 µ sec
No physical damge
No loss of continuity > 1 µ sec
No mechanical or electrical defect
Insulation resistance > 100 megohms
Shall be capable of mating and unmating,
and meet contact resistance requirements
30 milliohms maximum
Cu Nanopin contact.
60 milliohms maximum With precious metal
80 milliohms maximum
}
alloy Nanopin contact.
3 lb. minimum axial load
Vibration
Durability
Moisture Resistance
Salt Spray
Contact Resistance
}
With gold plated Be-
Dimensions shown in inch (mm)
Specifications and dimensions subject to change
www.ittcannon.com
70
Strip Connectors - .025" Contact Spacing
How to Order - NT
R
RoHS COMPLIANCE
SERIES
INSULATOR MATERIAL
CONTACT LOCATION
CONTACT ARRANGEMENTS
CONTACT TYPE
TERMINATION TYPE
SERIES
Nano Strip
INSULATOR MATERIAL
P - Phenolic
CONTACT LOCATION
1 - Contacts on .025 (0.64) centers
2 - Contacts on .050 (1.27) centers
MODIFICATION CODE
CONTACT ARRANGEMENTS
40 Maximum - .025 (0.64) centers
20 Maximum - .050 (1.27) centers
CONTACT TYPE
P - Pin (Plug)
S - Socket (Receptacle)
TERMINATION MODIFICATION
L - Solid uninsulated wire
T - One piece contact/lead
H - Insulated harness wire
MODIFICATION CODE
For termination code, see NJS section,
page 73.
NT P
NT
2 40 S
H ***
Dimensions
NTP
B
.025 (0.64) TYP.
.055
(1.40)
MAX.
.055
(1.40)
MAX.
.025 (0.64) TYP.
B
.055
(1.40)
MAX.
B
.025 (0.64) TYP.
A
.220
(5.59)
MAX.
A
.160
(4.06)
MAX.
A
.080
(2.03)
Plug - "H" and "L"
Termination Types
Part Number
by Insulator Size
NTPI-1*-**
NTPI-2*-**
NTPI-3*-**
NTPI-4*-**
NTPI-5*-**
NTPI-6*-**
NTPI-7*-**
NTPI-8*-**
NTPI-9*-**
NTPI-10*-**
A
Ref.
-
.025 (0.64)
.050 (1.27)
.075 (1.91)
.100 (2.54)
.125 (3.18)
.150 (3.81)
.175 (4.45)
.200 (5.08)
.225 (5.72)
B
±.010 (0.25)
.050 (1.27)
.075 (1.91)
.100 (2.54)
.125 (3.18)
.150 (3.81)
.175 (4.45)
.200 (5.08)
.225 (5.72)
.250 (6.35)
.275 (6.99)
Part Number
by Insulator Size
NTPI-11*-**
NTPI-12*-**
NTPI-13*-**
NTPI-14*-**
NTPI-15*-**
NTPI-16*-**
NTPI-17*-**
NTPI-18*-**
NTPI-19*-**
NTPI-20*-**
A
Ref.
.250 (6.35)
.275 (6.99)
.300 (7.62)
.325 (8.26)
.350 (8.89)
.375 (9.53)
.400 (10.16)
.425 (10.80)
.450 (11.43)
.475 (12.07)
Plug - "T"
Termination Types
B
±.010 (0.25)
.300 (7.62)
.325 (8.26)
.350 (8.89)
.375 (9.53)
.400 (10.16)
.425 (10.80)
.450 (11.43)
.475 (12.07)
.500 (12.70)
.525 (13.34)
Part Number
by Insulator Size
NTPI-21*-**
NTPI-22*-**
NTPI-23*-**
NTPI-24*-**
NTPI-25*-**
NTPI-26*-**
NTPI-27*-**
NTPI-28*-**
NTPI-29*-**
NTPI-30*-**
A
Ref.
.500 (12.70)
.525 (13.34)
.550 (13.97)
.575 (14.61)
.600 (15.24)
.625 (15.88)
.650 (16.51)
.675 (17.15)
.700 (17.78)
.725 (18.42)
B
±.010 (0.25)
.550 (13.97)
.575 (14.61)
.600 (15.24)
.625 (15.88)
.650 (16.51)
.675 (17.15)
.700 (17.78)
.725 (18.42)
.750 (19.05)
.775 (19.69)
Receptacle - "H", "L", and "T"
Termination Types
Part Number
by Insulator Size
NTPI-31*-**
NTPI-32*-**
NTPI-33*-**
NTPI-34*-**
NTPI-35*-**
NTPI-36*-**
NTPI-37*-**
NTPI-38*-**
NTPI-39*-**
NTPI-40*-**
A
Ref.
.750 (19.05)
.775 (19.69)
.800 (20.32)
.825 (20.96)
.850 (21.59)
.875 (22.23)
.900 (22.86)
.925 (23.50)
.950 (24.13)
.975 (24.77)
B
±.010 (0.25)
.800 (20.32)
.825 (20.96)
.850 (21.59)
.875 (22.23)
.900 (22.86)
.925 (23.50)
.950 (24.13)
.975 (24.77)
1.000 (25.40)
1.025 (26.04)
Dimensions shown in inch (mm)
Specifications and dimensions subject to change
www.ittcannon.com
71
Center Jackscrew - .030" Contact Spacing
How to Order - NJS
R
RoHS COMPLIANCE
SERIES
CONTACT ARRANGEMENTS
CONTACT TYPE
TERMINATION TYPE
TERMINATION CODE
SERIES
- Nano center jackscrew rectangular (9,
24, 44)
NJSC - Nano center jackscrew circular (27, 72
266)
NJS
CONTACT ARRANGEMENTS
9, 24, 27, 44, 72, 266
CONTACT TYPE
P = Pin (Plug)
S = Socket (Receptacle)
TERMINATION CODE*
NJS
NJS - 24 P
H ***
TERMINATION TYPE
H = Insulated harness wire
L = Solid uninsulated wire
T = One piece contact/Lead
* See Termination Codes shown below for additional length modification codes.
(H) 001 = 18" #32 AWG 7/40 strd. Type
"ET" Teflon per MIL-W-16878/6,
color yellow.
(H) 003 = 18" #32 AWG 7/40 strd. Type
"ET" Teflon per MIL-W-16878/6
color coded to MIL-STD-681, Sys-
tem 1.
(L) 1 = 1/2" uninsulated solid #30 AWG
gold plated copper.
(L) 2 = 1" uninsulated solid #30 AWG gold
plated copper
(T)* = Consult customer service
Standard Wire Termination Codes
The following termination codes are listed for your information. For additional codes please refer to Appendix on page 80 and 82.
All wire lengths ae minimum.
Harness Type (H)
#32
AWG, 7/40 stranded, Type
"ET"
per
MIL-W-16878/6
Solid Uninsulated Type (L)
#32
AWG gold plated copper.
Length
3 (76.2)
6 (152.4)
8 (203.2)
10 (254.0)
12 (304.8)
18 (457.2)
20 (508.0)
All Yellow
H 020
H 019
H 026
H 029
H 028
H 001
H 038
Color Coded
H 027
H 016
H 034
H 025
H 002
H 003
H 023
Length
24 (609.6)
30 (762.0)
36 (914.4)
48 (1219.2)
72 (1828.8)
120 (3048.0)
All Yellow
H 009
H 010
H 011
H 013
H 017
H 042
Color Coded
H 004
H 005
H 006
H 048
H 046
H 041
Code
L61
L56
L57
L39
L58
L1
Length
.125 (3.18)
.150 (3.81)
.190 (4.83)
.250 (6.35)
.375 (9.53)
.500 (12.70)
Code
L14
L2
L7
L6
L16
L10
Length
.750 (19.05)
1.000 (25.40)
1.500 (38.10)
2.000 (50.80)
2.500 (63.50)
3.000 (76.20)
Center Jackscrew/Rectangular
NJS-9 & NJS-24
1
D
9
5
8
4
B
B
A
0-80 UNF-2B
THREADED INSERT
C
C
Face View Pin Insert
A
Max.
.255 (6.48)
.255 (6.48)
.435 (11.05)
.435 (11.05)
Receptacle Side View
B
Max.
.165 (4.19)
.165 (4.19)
.165 (4.19)
.165 (4.19)
.165 (4.19)
.165 (4.19)
.165 (4.19)
.165 (4.19)
C
±.005 (0.13)
.138 (3.51)
.078 (1.98)
.138 (3.51)
.078 (1.98)
Plug Side View
D
±.005 (0.13)
.116 (2.95)
.116 (2.95)
.116 (2.95)
.116 (2.95)
.116 (2.95)
.116 (2.95)
.116 (2.95)
.116 (2.95)
Part Number
NJS-9P*
NJS-9S*
NJS-24P*
NJS-24S*
NJSC-266
NJSC-72
NJSC-44
NJSC-27
Dimensions shown in inch (mm)
Specifications and dimensions subject to change
www.ittcannon.com
73
