REVISION EC
DO NOT
SCALE FROM
THIS PRINT
NOTES:
No OF POSITIONS
1.
C
REPRESENTS A CRITICAL DIMENSION.
-02 THRU -50
2. PARTS MAY BE CUT TO POSITION.
(PER ROW)
3. MAXIMUM CUT FLASH: .010 [0.25]
4. MINIMUM PUSHOUT FORCE: 1.0 LB.
LEAD STYLE
5. MEASURED AT BEND RADIUS, NOT AT END OF PIN.
6. TUBE ONLY -04 THROUGH -50 POSITIONS (SEE TABLE 2).
-01: .120 [3.05]
7. SHEAR TAILS TO DIMENSION SHOWN.
-02: .075 [1.91]
8. MAXIMUM BURR ALLOWANCE: .003 [0.08]
-03: .065 [1.65]
9. GOLD PLATING TO BE ON POST, TIN PLATING TO BE ON TAIL.
-04: .150 [3.81]
10. FILL WITH ALIGNMENT PIN HOLES TO TAIL SIDE.
-05 .170 [4.32]
11. DUE TO THE HIGH AMOUNT OF INSERTION FORCE NEEDED, LOCKING CLIPS
-14: .150 [3.81]
ARE NOT COMPATIBLE WITH AUTO PLACEMENT. SAMTEC RECOMMENDS
(NOT AVAILABLE WITH
MANUAL PLACEMENT FOR ALL ASSEMBLIES WITH LOCKING CLIPS.
-SM, FM, LM PLATING OPTIONS)
FTSH-1XX-XX-XXX-DV-XXX
No OF POS x .0500
+.005
[
+0.13
]
-.010 -0.25
(No OF POS x .0500[1.27]) - .0500[1.27]
02
50
.135 3.43
REF
01
FTSHC-50-D
49
PLATING SPECIFICATION
(VALUES GIVEN ARE IN MICRO INCHES)
-L: LIGHT SELECTIVE, 10 Au / 40 MIN Ni ON
CONTACT AREA, MATTE TIN ON TAIL
-F: FLASH SELECTIVE, 3 Au / 40 MIN Ni ON
CONTACT AREA, MATTE TIN ON TAIL
-S: SELECTIVE, 30 Au / 40 MIN Ni ON
CONTACT AREA, MATTE TIN ON TAIL
-H: HEAVY GOLD, 30 Au / 40 Ni ON
CONTACT AREA, 3 Au / 40 Ni ON TAIL
-SM: HEAVY SELECTIVE GOLD, 30 Au / 40 MIN Ni
ON CONTACT AREA, MATTE TIN ON TAIL
-LM: LIGHT SELECTIVE GOLD, 10 Au / 40 MIN Ni
ON CONTACT AREA, MATTE TIN TAIL
-FM: FLASH SELECTIVE GOLD, 3 Au / 40 MIN Ni ON
CONTACT AREA, MATTE TIN ON TAIL
-LTL: LIGHT GOLD, 10 Au / 40 MIN Ni ON
CONTACT AREA, 90 / 10 ± 5% TIN LEAD ON TAIL
TAIL OPTION
-DV: DOUBLE VERTICAL
2 MAX SWAY
(USE **FTSHC-1XX-XX-XXX-DV FOR ALL OPTIONS
(EITHER DIRECTION)
EXCEPT -ES, -EJ, -EJM, -EJC, -EC, -EP, -EL, -EPC, -A,
THEN USE FTSH-50-D AND BUILD PER PRINT)
** = SEE FTSHC-1XX-XX-XXX-DX-XX PRINT FOR DETAILS
2 MAX SWAY
(EITHER DIRECTION)
SEE TABLE 1
*
-P: PICK & PLACE PAD (4 POS MIN)
(SEE FIG 11, SHT 4 & TABLE 5)
-TR: TAPE & REEL PACKAGING
-ES: END SHROUDS (SEE FIG 6, SHT 3)
(MOLDED IN 5 POS MIN; -02 & -03 LEAD STYLE ONLY)
(SNAP SHROUDS 9 POS MIN; -02 & -03 LEAD STYLE ONLY)
(MUST USE FTSH-50-D)
-EJ: EJECTOR SHROUDS: SEE FIG 4, SHT 2)
(10 POS MIN; -01 LEAD STYLE ONLY)(MUST USE FTSH-50-D)
-EJM: EJECTOR SHROUDS WITH MOLDED ALIGNMENT PIN
(SEE FIG 5, SHT 2; 10 POS MIN; -01 LEAD STYLE ONLY)
(NOT VALID WITH -A OPTION)(MUST USE FTSH-50-D)
-EJC: EJECTOR SHROUDS WITH LOCKING CLIP
(SEE FIG 5, SHT 2 & NOTE 11)
(10 POS MIN; -01 LEAD STYLE ONLY; NOT VALID WITH -A
OPTION)
(MUST USE FTSH-50-D)
-EC: LOCKING CLIP (SEE FIG 7, SHT 3 & NOTE 11)
(9 POS MIN; -02 & -03 LEAD STYLE ONLY)(MUST USE FTSH-50-D)
-EP: GUIDE POST (SEE FIG 8, SHT 3; 9 POS MIN; -02 & -03 LEAD STYLE
ONLY)
(USE ONLY WHEN MATING WITH CLP)(MUST USE FTSH-50-D)
-EL: BOARD LOCK (SEE FIG 9, SHT 3)
(9 POS MIN; -02 & -03 LEAD STYLE ONLY)
(USE ONLY WHEN MATING WITH CLP)(MUST USE FTSH-50-D)
-EPC: GUIDE POST & LOCKING CLIP
(SEE FIG 10, SHT 3 & NOTE 11; USE ONLY WHEN MATING WITH CLP)
(9 POS MIN; -02 & -03 LEAD STYLE ONLY; NOT VALID
WITH -A OPTION)(MUST USE FTSH-50-D)
-A: ALIGNMENT PIN (MOLDED OR STAKED; SEE FIG 3, SHT 2)
(MOLDED: 3 POS MIN; STAKED: 6 POS MIN)
(SAMTEC DISCRETION ON WHICH -A PIN USED)
(MUST USE FTSH-50-D)
-K: KEYING OPTION FOR MATING WITH FFSD
(SEE TABLE 3, SHT 2; 05 THRU 25 AVAILABLE AS STANDARD)
(POSITION 13, 17, 20 & 25 AVAILABLE WITH -EJ OPTION)
(LEAD STYLE -01 ONLY, SEE FIG 2, SHT 2)
(ALIGNMENT PIN AVAILABLE WITH -K OPTION BUT MUST BE MOLDED)
(MUST USE FTSH-XX-CN-XX)
-M: METAL PICK & PLACE PAD (5 POS MIN; USE MPP-22-5)
(SEE FIG 12, SHT 4; NOT AVAILABLE WITH -K OPTION)
OPTIONS
* = NOT ENGINEERING APPROVED
.016 0.41 SQ
REF (TYP)
"B"
CONTACT AREA
(SEE NOTE 9 & TABLE 1)
EC
EC
C
C
.050±.004 1.27±0.10
2 MAX SWAY
(EITHER DIRECTION)
"A" C
90°±3°
SEE NOTE 3
(2 PLCS)
.099 2.51
REF
.004[.10]
.115 2.92
(SEE NOTE 5)
SEE NOTE 8
PATENT NUMBERS
5713755 / 5961339
FTSH-1XX-XX-XXX-DV SHOWN
(SEE FTSHC-1XX-XX-XXX-DX-XX PRINT FOR DETAILS)
FIG 1
.23 5.8
(SEE NOTE 7)
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
ANGLES
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
1
.XXX: .005 [.13]
.XXXX: .0010 [.025]
MATERIAL:
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
code 55322
e-Mail info@SAMTEC.com
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 5:1
INSULATOR: LCP UL 94 VO
TERMINAL: PHOSPHOR BRONZE
.050 x .050 CL DOUBLE VERTICAL SMT TERMINAL STRIP
FTSH-1XX-XX-XXX-DV-XXX
10/12/1995
SHEET
1
OF
5
F:\DWG\MISC\MKTG\FTSH-1XX-XX-XXX-DV-XXX-MKT.SLDDRW
BY:
PURVIS
REVISION EC
-K OPTION
(LEAD STYLE -01 ONLY)
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
(POSITION 13, 17, 20 & 25 AVAILABLE WITH
-EJ OPTION)
((No OF POS x .0500[1.270])
- .003[.08])±.006[0.15]
FIG 2
-EJ OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
(-01 LEAD STYLE ONLY)
USE SUB-FTSH-EJEHA
(2 REQ'D PER ASSEMBLY, EACH
USES 1 EHA-02 & 1 FTSH-EJ)
.222 5.65
REF
FIG 4
SCALE 2 : 1
.135 3.43
REF
.200 5.08
REF
.440 11.18
REF
.085 2.16 REF
C
L
.200 5.08 REF
.126 3.20 REF
+.005
.115
- .000
+0.13
2.92
0.00
(No OF POS x .050[1.27])+.621[15.77]
±.010[0.25]
(No OF POS x .050[1.27])+.772[19.61] REF
FTSH-50-D
.392 9.96
REF
(SEE NOTE 5)
FTSH-50-CN-XX
-EJ OPTION (SHROUDS OPEN)
.076 1.93 REF
-A OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
(6 POSITION MINIMUM FOR STAKED ALIGNMENT PINS)
(3 POSITION MINIMUM FOR MOLDED ALIGNMENT PINS)
C
L
FTSH-50-D
(SEE NOTE 10)
.034 0.86
C
FIG 3
-EJC & -EJM OPTIONS
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 4)
(-01 LEAD STYLE ONLY)
USE SUB-FTSH-EJEHA
(2 REQ'D PER ASSEMBLY, EACH
USES 1 EHA-02 & 1 FTSH-EJ)
USE SUB-FTSH-EJEHA-A
(2 REQ'D PER ASSEMBLY, EACH
USES 1 EHA-02 & 1 FTSH-EJ-A)
FIG 5
SCALE 2 : 1
C
L
C
L
(No OF POS - 2)
x .050[1.27]
C
C
L
SM-A9H
(STAKED ALIGNMENT PINS)
.035 0.89
REF
-EJC
.085
- .000
[2.16
+.005
+0.13
0.00
]
LC-05-TM
.010 0.25 REF
-EJC
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
FTSH-50-D-XX
.034 0.86
.050 1.27 REF
(No OF POS - 2)
x .050[1.27]
FULL R
.035 0.89
REF
.035 0.89
REF
-EJM
.05 1.3
REF
-EJM
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
code 55322
e-Mail info@SAMTEC.com
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
.050 x .050 CL DOUBLE VERTICAL SMT TERMINAL STRIP
DWG. NO.
(MOLDED ALIGNMENT PINS)
FTSH-1XX-XX-XXX-DV-XXX
PURVIS
10/12/1995
SHEET
2
OF
5
F:\DWG\MISC\MKTG\FTSH-1XX-XX-XXX-DV-XXX-MKT.SLDDRW
BY:
REVISION EC
-ES OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
(USE -02 OR -03 LEAD STYLE ONLY)
(9 POS MIN FOR SNAP SHROUDS)
(5 POS MIN FOR MOLDED SHROUDS)
.265 6.73 REF
.075 1.91 REF
.120 3.05 REF
FIG 6
-EP OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 6)
(USE ONLY WHEN MATING WITH CLP)
(No OF POS x .050[1.27])+.231[5.87]±.008[0.20]
(No OF POS x .050[1.27])+.156[3.96] REF
.032[0.81] REF
CHAMFER
FTSH-EP
.314 7.96
FIG 8
02
.188 4.78
REF
01
(No OF POS x .050[1.27])+.101[2.57]±.008[0.20]
ES-FTSH
.168 4.27
REF
.194 4.91
.087 2.21 REF
.139 3.53
REF
.288 7.32
REF
-EL OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 6)
(USE ONLY WHEN MATING WITH CLP)
FTSH-EL
FIG 9
.125 3.18
REF
(SNAP SHROUDS)
02
.1750 4.445
REF
01
FTSH-49-ES-XX-X
FTSH-50-D
(SEE NOTE 10)
.293 7.44
REF
.319 8.09
(No OF POS x .050[1.27]) +.153[3.89] REF
(No OF POS x .050[1.27])+.257[6.53]
.0960 2.438
REF
-EPC OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 6)
(USE ONLY WHEN MATING WITH CLP)
(No OF POS x .050[1.27])+.231[5.87]±.008[0.20]
(No OF POS x .050[1.27])+.156[3.96] REF
FIG 10
.1775 4.509
REF
.075 1.91 REF
.0990 2.515
REF
FTSH-EP
.288 7.32
REF
.120 3.05 REF
.032[0.81] REF
CHAMFER
(MOLDED SHROUDS)
-EC OPTION
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 6)
(No OF POS x .050[1.27])+.131[3.32]±.008[0.20]
.280 7.11
REF
.314 7.96
FIG 7
LC-05-TM
(No OF POS x .050[1.27])+.079[2.01]±.008[.20]
.055 1.40
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
code 55322
e-Mail info@SAMTEC.com
DESCRIPTION:
DWG. NO.
.055 1.40
FTSH-EC
LC-05-TM
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.050 x .050 CL DOUBLE VERTICAL SMT TERMINAL STRIP
(No OF POS x .050[1.27])+.079[3.30]±.008[0.20]
F:\DWG\MISC\MKTG\FTSH-1XX-XX-XXX-DV-XXX-MKT.SLDDRW
FTSH-1XX-XX-XXX-DV-XXX
10/12/1995
SHEET
3
OF
5
BY:
PURVIS
REVISION EC
"M"
.20 5.1
REF
.13 3.3 REF
.07 1.7 REF
.20 5.1
REF
"P"
.16 4.1
REF
.24 6.1
REF
.13 3.3
REF
PPP-25
PPP-48
"M" = No OF POSITIONS x .0500 [1.270]
"P" ={("M" -200 [508]) / 2} .020 [.51]
-P
-P OPTION
(DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG 1)
FIG 11
.23 5.8 REF
C
L
EC
FTSH-50-CN-XX
FTSHC-50-D
PPP-25-NT
(DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG 2)
-K-P-TR
*MOLDED SHROUD ONLY
** USE PPP-25-NT WITH -TR
PACKAGING ONLY
(DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG 1)
.32 8.1
REF
-P-TR
NOTE: TAPE & REEL ORIENTATION:
POLARIZATION NOTCH TO THE RIGHT
.32 8.1
REF
PPP-41
.16 4.1
REF
(DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIGS 4 & 5)
-EJ-P & -EJX -P
"M" REF
*-M: METAL PICK & PLACE PAD
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1)
(NOT AVAILABLE WITH -K OPTION)(5 POS MIN)
* = NOT ENGINEERING APPROVED
"P"
FIG 12
TAPE & REEL VIEW
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
.250 6.35
REF
.100 2.55 REF
MPP-22-5
"B"
FTSHC-50-D
"M" = No OF POSITIONS x .0500[1.270]
"P" = {("M" - .250[6.35]) / 2} ± .020[0.51]
F:\DWG\MISC\MKTG\FTSH-1XX-XX-XXX-DV-XXX-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
code 55322
e-Mail info@SAMTEC.com
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
.050 x .050 CL DOUBLE VERTICAL SMT TERMINAL STRIP
DWG. NO.
FTSH-1XX-XX-XXX-DV-XXX
10/12/1995
SHEET
4
OF
5
BY:
PURVIS
京公网安备 11010802033920号
EEWORLD
