VA
CONNECTOR
1
2
H JST
7.92mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 7A AC, DC (AWG #18)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10m
Ω
max.
After environmental testing/20m
Ω
max.
• Insulation resistance:
1,000M
Ω
min.
• Withstanding voltage: 1,200V AC/minute
• Applicable wire: AWG #20 to #18
• Applicable PC board thickness: 1.6mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
This 7.92mm pitch large current carrying
capacity connector is used with primary
power supply circuits and various other
circuits requiring large currents. It features
an anti-misinsertion construction and a
reliable locking mechanism to ensure
maximum safety.
• Box contact
• Secure contact and mounting
• Compact connector with a large capacity
Standards ––––––––––––––––––––––
1
Certified LR20812
2
R75122
Side entry type
7.92
±0.05
0
Recognized E60389
PC board layout (viewed from soldering side) and Assembly layout
Top entry type
10.6
7.92
± 0.05
2.0
min
5.0
min
2.0
min
7.2
min
21.5
17.5
0.1
φ 1.65
＋0
Circuit No.1
φ1.65
＋0.1
0
Circuit No.1
7.2
min
Side entry type with PCB stabilizer
5.0
7.92
±0.05
1.95
min
22.0
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing
method. The dimensions above should serve as a guideline.
Contact JST for details.
5.7
min
φ1.65
＋0.1
0
Circuit No.1
5.7
7.7
Contact
Model No.
SVA-41T-P1.1
11.6
3.0
4.0
5.2
10.6
Applicable wire
AWG #
mm
2
0.5∼0.83
20∼18
Insulation O.D.
(mm)
1.9∼3.7
Q'ty /
reel
3,500
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
3.8
RoHS compliance
Contact
SVA-41T-P1.1
Crimping
machine Crimp applicator
AP-K2N
MKS-L
−
−
Applicator
Dies
MK/SVA-41-11
−
−
Crimp applicator with dies
APLMK SVA41-11
−
−
10.6
1
VA CONNECTOR
Housing
Circuits
2
Circuit No.1
6.8
3.8
10.6
2.1
9.7
Model No.
VAR-2
Material
PA 6, UL94V-0, natural (white)
Q'ty / bag
1,000
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
VAR-2-oo-
(blank)…natural (white)
K…black R…red E…blue Y…yellow M…green N…brown
7.92
12.92
14.3
Locking header
Top entry type
1.14
With plugged up
Top entry type
7.7
1.14
7.7
9.4
3.2
Circuit No.1
7.92
11.82
Circuit No.1
7.92
11.82
3.7
Side entry type
3.7
3.2
9.4
8.5
1.14
Circuit No.1
7.92
11.82
3.6
1.14
9.4
8.5
Side entry type
7.7
3.2
14.9
4.0
3.6
Circuit No.1
7.92
11.82
Circuits
7.7
3.2
14.9
4.0
Top entry type
Side entry type
Side entry type with PCB stabilizer
2
2
2
Model No.
B2P3 -VH
B2P3S-VH
S2P3 -VH
Q'ty / box
1,000
500
500
With plugged up
Side entry type with PCB stabilizer
11.82
13.9
Circuits
Top entry type
Side entry type
2
2
Model No.
*B2P-VA
*B2PS-VA
Material and Finish
Q'ty / box
1,000
500
1.14
Post: Brass, copper-undercoated, tin-plated (reflow treatment)
Wafer: PA 66, UL94V-0, natural (white)
RoHS compliance
This product displays (LF)(SN) on a label.
Note: *Marked products are not CSA/TÜV approved.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
B2P3(S)-VH-oo-
(blank)…natural (white)
BK…black R…red BL…blue Y…yellow M…green N…brown
O…orange PK…pink P…purple H…gray
S2P3-VH-oo-
(blank)…natural (white)
BK…black R…red Y…yellow M…green
Circuit No.1
7.92
7.7
5.7
3.6
ex.
2
9.4
