SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 874, REV. B
1N5614/UL
1N5616/UL
1N5618/UL
1N5620/UL
1N5622/UL
JAN
JANTX
JANTXV
SJ
SX
SV
HERMETIC AXIAL LEAD / MELF
GENERAL PURPOSE RECTIFIER
DESCRIPTION: A 200/400/600/800/1000 VOLT, 1.0 AMP, AXIAL LEAD/SURFACE MOUNT
2000 NS GLASS RECTIFIER.
MAXIMUM RATINGS
RATING
Peak Inverse Voltage
(PIV)
1N5614
1N5616
1N5618
1N5620
1N5622
Average DC Output
Current (I
o
) T
C
= 55
°C
T
C
= 100
°C
Peak Single Cycle Surge
Current (I
fsm
)
t
p
= 8.3 ms Single
Half Cycle Sine
Wave,
Superimposed On
Rated Load
Junction to Lead
d = 0.375”
Junction to Endcap
-
CONDITIONS
All ratings are at T
A
= 25
o
C unless otherwise specified.
MIN
-
TYP
-
200
400
600
800
1000
-
-
1.0
0.75
-
-
30
Amps(pk)
Amps
MAX
UNIT
Vdc
Thermal Resistance (
θJL
)
Thermal Resistance (θ
JEC
)
Operating and Storage
Temp. (T
op
& T
stg
)
-
-
-65
-
-
-
36
13
+175
°C/W
°C/W
°C
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
Maximum Forward
Voltage (V
f
)
Maximum Instantaneous
Reverse Current At Rated
(PIV)
Maximum Reverse
Recovery Time
CONDITIONS
I
F
= 3.0A (300
μsec
pulse, duty cycle <
2%)
T
A
= 25° C
T
A
= 100° C
I
F
= 0.5A, I
R
= 1.0A
I
RR
= 0.25A
MIN
-
TYP
-
MAX
1.3
UNIT
Volts
-
-
0.5
25
2000
μAmps
μAmps
ns
-
-
•
221 West Industry Court Deer Park, NY 11729-4681 Phone (631) 586 7600 Fax (631) 242 9798
•
•
World Wide Web - www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SENSITRON
TECHNICAL DATA
DATA SHEET 874, REV. B
1N5614/UL
1N5616/UL
1N5618/UL
1N5620/UL
1N5622/UL
JAN
JANTX
JANTXV
SJ
SX
SV
MECHANICAL DIMENSIONS: in inches / mm
0.033 (.84
0.026 .66)
.110 (2.79
.065 1.65)
.225 (5.72
.130 3.30)
1.30 (33.0
1.00 25.4)
PKG. 102
.028 (.72
.019 .48)
0.20 R Max
(5.08)
.003 Min
(.076)
.128 (3.8
.091 3.4)
.230 (5.9
.168 4.2)
.128 (3.8
.091 3.4 )
MELF-1
•
221 West Industry Court Deer Park, NY 11729-4681 Phone (631) 586 7600 Fax (631) 242 9798
•
•
World Wide Web - www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SENSITRON
TECHNICAL DATA
DATA SHEET 874, REV. B
1N5614/UL
1N5616/UL
1N5618/UL
1N5620/UL
1N5622/UL
JAN
JANTX
JANTXV
SJ
SX
SV
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the
datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment, medical
equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by means of users’
fail-safe precautions or other arrangement .
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of
the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any
other problems that may result from applications of information, products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from use at
a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of Sensitron
Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder
maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When
exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations.
•
