LED LAMP
FYL-8033
FYL-8033PGC1A
Features:
High instensity
General purpose leads
RoHs complant.
Package configuration
Descriptions:
Dice material: InGaN
Emitting Color: Pure Green
Device Outline: Φ8mm concave Type.
Lens Type: Water clear
8.05(.317)
135°
7.95(.313)
11.0(.43)
1.0(.04)
25.4(1.0)
CATHODE
Radiation pattern.
0.5(.02)
2.54(.1)
Relative Lumionous Intensity(LOP @max=1)
All dimensions are millimeters (inches)
Tolerance is ±0.25mm(.010”) unless
otherwise noted.
MAX.
70
100
20
0.4
5
150
-30
℃
to +80
℃
-40
℃
to +100
℃
260
℃
for 5 Seconds
Unit
mW
mA
mA
mA/℃
V
V
ratings(Ta=25゜
Absolute maximun ratings(Ta=25
゜
с)
Parameter
Power Dissipation
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width)
Continuous Forward Current
Derating Linear From 50℃
Reverse Voltage
Electrostatic Discharge (ESD)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature[4mm(.157”) From Body]
characteristics(Ta=25゜
Electrical and optical characteristics(Ta=25
゜
с)
Parameter
Symbol
Min.
Luminous Intensity
Viewing Angle
Peak Emission
Dominant Wavelength
Spectral Line Half-Width
Forward Voltage
Reverse Current
I
V
2θ
1/2
λp
λd
△λ
V
F
I
R
--
100
515
517
10
2.8
Typ.
2000
110
520
522
15
3.2
Max.
--
120
525
527
20
3.6
50
Max1.0(.04)
Unit
mcd
Deg
nm
nm
nm
V
A
Test Condition
I
F
=20mA
V
R
=5V
.
LED LAMP
Typical Electrical Characteristics Curves
(25゜
(25
゜
с Ambient Temperature Unless Otherwise Noted)
Spectral Reduance
( 1 )
( 2 )
Normalized Response
(1)InGaN peak@505nm /bluish Green
(2)InGaN peak@520nm /pure Green
Wave Length(nm)
Forward Current Vs
Forward Voltage
50
Relative Luminous intensity
Forward current
Relative Intensity (Lop@20mA=1)
vs
40
Forward Current(mA)
30
20
10
0
2.3
2.5
2.7
2.9
3.1
3.3
3.5
3.7
3.9
4.1
4.3
Forward Voltage(V)
F o r w a r d
C u r r e n t
I F ( m A )
Forward Current Derating Curve
6 0
5 0
Forward Current(mA)
Luminous Intensity Vs Ambient Temperature
4 0
3 0
2 0
1 0
0
0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
9 0
A l G a A s
o r
A l G a I n P
Ambient Temperature TA( )
Relative Luminous Intensity
G a P
Ambient Temperature TA( C )
