DATA SHEET
SILICON POWER TRANSISTOR
2SC4331,4331-Z
NPN SILICON EPITAXIAL TRANSISTOR
FOR HIGH-SPEED SWITCHING
The 2SC4331 and 2SC4331-Z are mold power transistors developed for
high-speed switching and features a very low collector-to-emitter saturation
voltage.
This transistor is ideal for use in switching regulators, DC/DC converters,
motor drivers, solenoid drivers, and other low-voltage power supply devices,
as well as for high-current switching.
PACKAGE DRAWING (Unit: mm)
1.5
−0.1
+0.2
6.5 ±0.2
5.0 ±0.2
1.6 ±0.2
2.3 ±0.2
0.5 ±0.1
4
5.5 ±0.2
7.0 MIN.
13.7 MIN.
+0.2
FEATURES
• Available for high-current control in small dimension
• Z type is a lead-processed product and is deal for mounting a hybrid IC.
• Low collector saturation voltage
V
CE(sat)
= 0.3 V MAX. (I
C
= 3.0 A)
• Fast switching speed:
t
f
≤
0.4
μ
s MAX. (I
C
= 3.0 A)
• High DC current gain and excellent linearity
1
2
3
1.1 ±0.2
0.5
−0.1
2.3 2.3
0.75
0.5
−0.1
+0.2
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Collector to Base Voltage
Collector to Emitter Voltage
Emitter to Base Voltage
Collector Current (DC)
Collector Current (pulse)
Base Current (DC)
Total Power Dissipation (T
C
= 25°C)
Total Power Dissipation (T
A
= 25°C)
Junction Temperature
Storage Temperature
Note 1
<R>
150
100
7.0
5.0
10
2.5
15
V
TO-251 (MP-3)
V
CBO
V
CEO
V
EBO
I
C(DC)
I
C(pulse)
I
B(DC)
P
T1
P
T2
T
j
T
stg
1.0
5.0 ±0.2
4.4 ±0.2
4
5.5 ±0.2
1.5
−0.1
+0.2
V
V
A
A
A
W
Note 3
6.5 ±0.2
2.3 ±0.2
0.5 ±0.1
Note
1.0 ±0.5
0.4 MIN.
0.5 TYP.
2.5 ±0.5
Note
5.6 ±0.3
9.5 ±0.5
1 2 3
Note 2
, 2.0
W
°C
°C
0.5 ±0.1
0.5 ±0.1
2.3 ±0.3
2.3 ±0.3
0.15 ±0.15
150
−55
to +150
Notes 1.
PW
≤
10 ms, duty cycle
≤
50%
2.
Printing board mounted
3.
7.5 cm
2
×
0.7 mm, ceramic board mounted
TO-252 (MP-3Z)
Electrode Connectio
1. Base
2. Collector
3. Emitter
4. Collector Fin
Note
The depth of notch at the top of the fin is
from 0 to 0.2 mm.
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No. D16136EJ3V0DS00 (3rd edition)
Date Published January 2007 NS CP(K)
Printed in Japan
2002
The mark <R> shows major revised points.
The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.
