SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 848, REV. A
SHD120136
SCHOTTKY RECTIFIER
Ultra Low Reverse Leakage
200°C Operating Temperature
Applications:
•
Switching Power Supply
•
Converters
•
Free-Wheeling Diodes
•
Polarity Protection Diode
Features:
•
•
•
•
•
•
•
Ultra low Reverse Leakage Current
Soft Reverse Recovery at Low and High Temperature
Very Low Forward Voltage Drop
Low Power Loss, High Efficiency
High Surge Capacity
Guard Ring for Enhanced Durability and Long Term Reliability
Guaranteed Reverse Avalanche Characteristics
Maximum Ratings:
Characteristics
Peak Inverse Voltage
Max. Average Forward
Current
Max. Peak One Cycle Non-
Repetitive Surge Current
Non-Repetitive Avalanche
Energy
Repetitive Avalanche Current
Max. Thermal Resistance
Max. Junction Temperature
Max. Storage Temperature
Symbol
V
RWM
I
F(AV)
I
FSM
E
AS
I
AR
R
θJC
T
J
T
stg
Condition
-
50% duty cycle, rectangular
wave form
8.3 ms, half Sine wave
(1)
T
J
= 25
°C,
I
AS
= 0.23A,
L = 130 mH
I
AS
decay linearly to 0 in 1
µs
ƒ
limited by T
J
max V
A
=1.5V
R
-
-
-
Max.
200
7.5
140
7.7
0.4
2.45
-65 to +200
-65 to +200
Units
V
A
A
mJ
A
°C
°C
Electrical Characteristics:
Characteristics
Max. Forward Voltage Drop
Max. Reverse Current
Symbol
V
F1
V
F2
I
R1
I
R2
Max. Junction Capacitance
C
T
Condition
@ 7.5A, Pulse, T
J
= 25
°C
@ 7.5A, Pulse, T
J
= 125
°C
@V
R
= 200V, Pulse,
T
J
= 25
°C
@V
R
= 200V, Pulse,
T
J
= 125
°C
@V
R
= 5V, T
C
= 25
°C
f
SIG
= 1MHz,
V
SIG
= 50mV (p-p)
I
F
= 0.5A, I
R
= 1.0A,
I
RM
= 0.25 A, T
J
= 25°C
Max.
0.98
0.82
0.05
0.5
150
Units
V
V
mA
mA
pF
Max. Reverse Recovery Time
t
rr
25
nsec
•
221 WEST INDUSTRY COURT
•
DEER PARK, NY 11729-4681
•
PHONE (631) 586-7600
•
FAX (631) 242-9798
•
•
World Wide Web - http://www.sensitron.com
•
E-mail Address - sales@sensitron.com
•
SHD120136
TECHNICAL DATA
DATA SHEET 848, REV.A
MECHANICAL DIMENSIONS: IN Inches / mm
LCC-5
PINOUT TABLE
DEVICE TYPE
SINGLE RECTIFIER
PIN 1
CATHODE
PIN 2
ANODE
PIN 3
ANODE
Typical Forward Characteristics
10
1
Typical Reverse Characteristics
200 °C
10
1
Instantaneous Reverse Current - I
R
(mA)
10
0
175 °C
150 °C
10
-1
200 °C
175 °C
125 °C
100 °C
75 °C
10
-2
Instantaneous Forward Current - I
F
(A)
10
0
10
-3
50 °C
10
-4
25 °C
10
-5
10
-1
125 °C
0
40
80
120
160
Reverse Voltage - V
R
(V)
200
240
Typical Junction Capacitance
Junction Capacitance - C
T
(pF)
25 °C
10
-2
120
80
40
10
-3
0.0
0.2
0.4
0.6
0.8
Forward Voltage Drop - V
F
(V)
1.0
0
0
40
80
120
160
Reverse Voltage - V
R
(V)
200
240
Note:
The V
f
curves shown are for the SD090SCU200 unpackaged die only.
•
