LED LAMP
FYL-5483PGC1A
FYL-5483PGC1A
Features:
High instensity
General purpose leads
RoHs complant.
Package configuration
4.7(.185)
5.7(.224)
4.7(.185)
7.9(.31)
25.4(1.0)
1.0(.04)
Descriptions:
Dice material: InGaN
Emitting Color: Pure Green
Device Outline: Φ5*4 mm ellipse Type.
Lens Type: Water clear
Radiation pattern.
Max1.0(.04)
CATHODE
0.5(.02)
2.54(.1)
Relative Lumionous Intensity(LOP @max=1)
ratings(Ta=25゜
Absolute maximun ratings(Ta=25
゜
с)
Parameter
Power Dissipation
Peak Forward Current (1/10 Duty Cycle, 0.1ms Pulse Width)
Continuous Forward Current
Derating Linear From 50℃
Reverse Voltage
Electrostatic Discharge (ESD)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature[4mm(.157”) From Body]
All dimensions are millimeters (inches)
Tolerance is ±0.25mm(.010”) unless
otherwise noted.
MAX.
Unit
70
100
20
0.4
5
150
mW
mA
mA
mA/
℃
V
V
-30
℃
to +80
℃
-40
℃
to +100
℃
260
℃
for 5 Seconds
characteristics(Ta=25゜
Electrical and optical characteristics(Ta=25
゜
с)
Parameter
Symbol
Min.
Luminous Intensity
I
V
--
X
35
Viewing Angle
2θ
1/2
y
65
Peak Emission
λp
515
Wavelength
Dominant Wavelength
λd
520
Spectral Line Half-Width
△λ
30
Forward Voltage
V
F
2.8
Reverse Current
I
R
Typ.
3500
40
70
520
525
35
3.2
Max.
--
45
75
525
530
40
3.6
50
Unit
mcd
Deg
nm
nm
nm
Test Condition
I
F
=20mA
V
A
V
R
=5V
115 QiXin Road, NingBo, Zhejiang,
TEL:86-574-87927870, 87933652
E-mail:sales@foryard.com
China
315051
FAX:86-574-87927917
http:/www.foryard.com
.
LED LAMP
Typical Electrical Characteristics Curves
(25゜
(25
゜
с Ambient Temperature Unless Otherwise Noted)
Spectral Reduance
( 1 )
( 2 )
Normalized Response
(1)InGaN peak@505nm /bluish Green
(2)InGaN peak@520nm /pure Green
Wave Length(nm)
Forward Current Vs
Forward Voltage
50
Relative Luminous intensity
Forward current
Relative Intensity (Lop@20mA=1)
vs
40
Forward Current(mA)
30
20
10
0
2.3
2.5
2.7
2.9
3.1
3.3
3.5
3.7
3.9
4.1
4.3
Forward Voltage(V)
F o r w a r d
C u r r e n t
I F ( m A )
Forward Current Derating Curve
6 0
5 0
Forward Current(mA)
Luminous Intensity Vs Ambient Temperature
4 0
3 0
2 0
1 0
0
0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
9 0
A l G a A s
o r
A l G a I n P
Ambient Temperature TA( )
Relative Luminous Intensity
G a P
Ambient Temperature TA( C )
115 QiXin Road, NingBo, Zhejiang,
TEL:86-574-87927870, 87933652
E-mail:sales@foryard.com
China
315051
FAX:86-574-87927917
http:/www.foryard.com
.
LED LAMP
LAMP PACKING.
Label 1
FORYARD
OPTOELECTRONICS
Pb
Part No:
Quanlity:
Date:
Q.A:
QC1
PASSED
3mm.5mm.10mm Polybag
B o x
D i m e n s i o n ( c m ) : 3 0 * 1 9 * 1 1 . 5
)
c s
( p
T Y
Q '
.
NO
R T
P A
Label 2
FORYARD
OPTOELECTRONICS
Pb
Part No:
Quanlity:
Date:
Q.A:
QC1
PASSED
Anti-electrostatic bag
DEVICE
5mm(T-1
3mm(T-1 )
10mm(T-1)
Blue/Green/White
3/4)
QTY/polybag(pcs)
1000
1000
250
500pcs
Polybag/box A
8 bags
10 bags
8 bags
8 bags
Fig
Label
Label
Label
Label
1
1
1
2
CARTON
Dimension(cm):39*32*38
)
c s
( p
T Y
Q '
R T
P A
E R
M B
N U
S
K G
W
G .
8
* 3
W
3 1
N .
8 *
: 3
A S
S
K G
C M
C/NO
M E
6 Boxes/Carton
5mm:48,000pcs
3mm:60,000pcs
10mm:12,000pcs
Blue/Pure Green/bluish Green
/White:24,000pcs
