C9PTUK312.500 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> oscillator> C9PTUK312.500

C9PTUK312.500: DescriptionLVPECL Output Clock Oscillator, 0.75MHz Min, 800MHz Max, 312.5MHz Nom; CategoryPassive components oscillator; File Size54KB，3 Pages; ManufacturerRaltron; Websitehttp://www.raltron.com/; Environmental Compliance

Download Datasheet Parametric View All

C9PTUK312.500 Overview

LVPECL Output Clock Oscillator, 0.75MHz Min, 800MHz Max, 312.5MHz Nom

C9PTUK312.500 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Raltron
package instruction	DILCC6,.2
Reach Compliance Code	compliant
Other features	TAPE AND REEL; TRISTATE ENABLE/DISABLE FUNCTION
maximum descent time	1 ns
Frequency Adjustment - Mechanical	NO
frequency stability	20%
JESD-609 code	e4
Manufacturer's serial number	C9P
Installation features	SURFACE MOUNT
Number of terminals	6
Maximum operating frequency	800 MHz
Minimum operating frequency	0.75 MHz
Nominal operating frequency	312.5 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-20 °C
Oscillator type	LVPECL
Output load	50 OHM
Package body material	CERAMIC
Encapsulate equivalent code	DILCC6,.2
physical size	7mm x 5mm x 2mm
power supply	3.3 V
Certification status	Not Qualified
longest rise time	1 ns
Maximum slew rate	100 mA
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au)

Preview

Download Datasheet

View All

CLOCK

Page 1 of 3

C9P: PLL LVPECL SERIES: ULTRA HF CLOCK OSCILLATOR, LVPECL, +3.3 VDC

DESCRIPTION: A crystal controlled, high frequency, highly stable oscillator, adhering to Low Voltage Differential Signaling

(LVPECL) Standards. The output can be Tri-stated to facilitate testing or combined multiple clocks. The device is contained in

a sub-miniature, very low profile, leadless ceramic SMD package with 6 gold contact pads. This miniature oscillator is ideal for

today's automated assembly environments.

APPLICATIONS AND FEATURES:

Infiniband; Fiber Channel; SATA; 10GbE; Network Processors; SOHO Routing; Switches;

Common Frequencies: 150 MHz; 156.25 MHz; 155.52 MHz; 161.1328 MHz; 212.5MHz; 312.5MHz

+3.3 VDC LVPECL

Frequency Range from 750KHz to 800 MHz

PLL multiplication (F>25MHz)

Miniature Ceramic SMD Package Available on Tape and Reel

Lead Free and ROHS Compliant

SYMBOL

T(stg)

Vcc

VALUE

-40…+85

-55…+90

+4.6

Vss-0.5…Vcc+0.5

UNIT

°C

VDC

ABSOLUTE MAXIMUM RATINGS:

PARAMETER

Operating temperature range

Storage temperature range

Supply voltage

Maximum Input Voltage

Maximum Output Voltage

ELECTRICAL PARAMETERS:

PARAMETER

SYMBOL

Vcc

Connected between each output and Vcc – 2.0 VDC

min

max

Measured at 50% of Vcc

Measured at 20/80% and 80/20% Vcc Levels

Integrated Phase tji RMS,

Fo=155.52MHz

Fj = 12 kHz…20 MHz

Fo=622.08MHz

Fo=155.52MHz.

Random period Jitter Rj using

wavecrest analyzer

Fo=622.08MHz

Fo=155.52MHz.

Acumm. Peak to Peak Jitter Tp-p

using wavecrest analyzer

Fo=622.08MHz

∆f=10

∆f=100

∆f=1

KHz

∆f=10

KHz

typ. @155.52MHz

∆f=100

KHz

∆f=1M

∆f=10M

∆f>20M

Op. Temp., Aging, Load, Supply and Cal. Variations

High Voltage or No Connect

Ground

High Voltage

Ground or No Connect

TEST CONDITIONS

VALUE

0.75~ 800.00**

+3.3

±5%

100.0 MAX

LVPECL

Voh

Vol

tr / tf

Vcc-1.025

Vcc-1.620

40/60 to 60/40 or 45/55 to 55/45

0.7 TYP 1.0 MAX

2.6 TYP**

2.5 TYP**

4 TYP **

6 TYP **

30 TYP**

40 TYP**

-60

-90

-120

-125

-121

-140

-145

±20, ±25, ±50,

±100

MAX

0.7•Vcc MIN

0.3•Vcc MAX

0.7•Vcc MIN

0.3•Vcc MAX

Ω

VDC

UNIT

MHz

VDC

Nominal Frequency

Supply Voltage

Supply Current

Output Logic Type

Load

Output Voltage Levels

Duty Cycle

Rise / Fall Time

Jitter

Phase Noise

£(∆f)

dBc/Hz

ppm

VDC

Overall Frequency Stability

Enable High Option;

Pin 1

Output Enabled

Output Disabled

Enable Low Option;

Pin 1

Output Disabled

Output Enabled

∆f/fc

Dis

RALTRON ELECTRONICS CORP.

10651 N.W . 19

Miami, Florida 33172

U.S.A.

phone: (305) 593-6033

fax: (305) 594-3973

e-mail: sales@raltron.com

WEB: http://www.raltron.com
