Multi-Layer
Chip Inductor
3rd Dot
2nd Dot
1st Dot
.236
max
LDR0608
.325
max
.394
.590
FEATURES
n
n
n
Radial leaded
Epoxy Coated
Supplied in bulk and T/R
.079
OPERATING TEMPERATURE RANGE -55•C to +105•C
CURRENT RATING Based on 0.25 w power dissipation.
att
TESTING Inductanceand Q measured withQ meter HP4342A
at specified frequency. DCR measured with Milliohm meter.
SRF measured on HP4191A Impedance Analyzer.
PACKAGING Bulk or Tape and Reel.
PART
NUMBER
LDR0608-1R0M
LDR0608-1R2M
LDR0608-1R5M
LDR0608-1R8M
LDR0608-2R2M
LDR0608-2R7M
LDR0608-3R3M
LDR0608-3R9M
LDR0608-4R7M
LDR0608-5R6K
LDR0608-6R8K
LDR0608-8R2K
LDR0608-100K
LDR0608-120K
LDR0608-150K
LDR0608-180K
LDR0608-220K
LDR0608-270K
LDR0608-330K
LDR0608-390K
LDR0608-470K
LDR0608-560K
LDR0608-680K
LDR0608-820K
LDR0608-101K
LDR0608-121K
LDR0608-151K
LDR0608-181K
LDR0608-221K
LDR0608-271K
LDR0608-331K
LDR0608-391K
LDR0608-471K
LDR0608-561K
LDR0608-681K
LDR0608-821K
LDR0608-102K
Notes:
(1) Inductance and Q to be measured on HP4342A Q meter or equiv alent.
(2) Maximum Operating Temperatur e: -45°C to 125°C.
(3) Marking: Color code per EIA; 4 bands.
(4) Rated Curr ent: based on curr ent le v el when L is less than 10% fr om it’s
initial r eading.
(5) Dielectric Withstanding: 500Vr ms.
INDUCTANCE
µH
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
560.0
680.0
820.0
1000.0
TOLERANCE
±%
20
20
20
20
20
20
20
20
20
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Q
MINIMUM
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
50
50
50
50
50
50
50
50
50
50
50
45
45
45
45
55
55
55
55
55
TEST
FREQUENCY
(MHz)
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
7.960
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
2.520
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.796
0.252
SELF RESONANT
FREQUENCY
(MHz)
105.0
90.0
75.0
70.0
65.0
60.0
50.0
45.0
40.0
35.0
30.0
25.0
20.0
15.0
13.0
11.0
10.0
9.0
8.0
7.5
7.0
6.5
6.0
5.5
5.0
4.8
4.4
4.2
3.8
3.6
3.3
3.0
2.8
2.4
2.2
2.0
1.8
DC RESISTANCE
OHMS
MAXIMUM (Ω )
0.10
0.15
0.20
0.22
0.24
.027
0.30
0.30
0.35
0.35
0.40
0.40
0.45
0.50
1.55
0.60
0.65
0.75
0.85
0.90
1.00
1.20
1.30
1.50
1.70
1.90
2.10
2.30
2.50
2.75
4.68
6.00
6.50
8.50
9.00
9.60
11.50
IDC
MAXIMUM
(mA)
1030
980
920
880
830
790
750
720
670
640
620
590
550
530
500
480
460
430
410
390
370
350
340
320
305
290
275
185
175
165
155
145
140
135
125
120
100
