DST847BDJ Overview

DUAL NPN SMALL SIGNAL SURFACE MOUNT TRANSISTOR

DST847BDJ
45V DUAL NPN SMALL SIGNAL TRANSISTOR IN SOT-963
Features
Dual NPN SS
BV
CEO
> 45V
I
C
= 100mA High Collector Current
P
D
= 300mW Power Dissipation
1mm Package Footprint, 5 Times Smaller than SOT23
0.5mm Height Package Minimizing Off-Board Profile
Complementary PNP Type Available (DST857BDJ)
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
2
Mechanical Data
Case: SOT-963
Case Material: Molded Plastic, “Green” Molding Compound;
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads; Solderable per MIL-
STD-202, Method 208
Weight: 0.0027 grams (Approximate)
SOT-963
Top View
Device Symbol
Top View
Pin-Out
Ordering Information
(Note 4)
Device
DST847BDJ-7
Notes:
Compliance
AEC-Q101
Marking
TA
Reel size (inches)
7
Tape width (mm)
8
Quantity per reel
10,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen and Antimony free, "Green"
and Lead-Free.
3. Halogen and Antimony free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl)
and <1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
SOT-963
TA
TA = Product Type Marking Code
DST847BDJ
Document number: DS32035 Rev. 2 - 2
1 of 7
www.diodes.com
March 2015
© Diodes Incorporated
