This product complies with the RoHS Directive (EU 2002/95/EC).
DSA7101
Silicon PNP epitaxial planar type
For low frequency amplification
Complementary to DSC7101
DSA8101 in MiniP3 type package
Features
Low collector-emitter saturation voltage V
CE(sat)
Contributes to miniaturization of sets, reduction of component count.
Eco-friendly Halogen-free package
Package
Code
MiniP3-F2-B
Package dimension clicks here.→
Click!
Packaging
DSA7101×0L Embossed type (Thermo-compression sealing): 1000 pcs / reel (standard)
Absolute Maximum Ratings
T
a
= 25°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Emitter-base voltage (Collector open)
Collector current
Peak collector current
Collector power dissipation
*
Junction temperature
Storage temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
j
T
stg
Rating
–80
–80
–5
– 0.5
–1
1
150
–55 to +150
Unit
V
V
V
A
A
W
°C
°C
Name
Pin
1. Base
2. Collector
3. Emitter
Marking Symbol: 4C
Note) *: Printed circuit board: Copper foil area of 1 cm
2
or more, and the board thickness
of 1.7 mm for the collector portion
Absolute maximum rating without heat sink for P
C
is 0.5 W
Electrical Characteristics
T
a
= 25°C±3°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Emitter-base voltage (Collector open)
Collector-base cutoff current (Emitter open)
Forward current transfer ratio
*1
Collector-emitter saturation voltage
*1
Base-emitter saturation voltage
*1
Transition frequency
Collector output capacitance
(Common base, input open circuited)
Symbol
V
CBO
V
CEO
V
EBO
I
CBO
h
FE1 *2
h
FE2
V
CE(sat)
V
BE(sat)
f
T
C
ob
Conditions
I
C
= –10
mA,
I
E
= 0
I
C
= –100
mA,
I
B
= 0
I
E
= –10
mA,
I
C
= 0
V
CB
= –20 V, I
E
= 0
V
CE
= –10 V, I
C
= –150 mA
V
CE
= –5 V, I
C
= –500 mA
I
C
= –300 mA, I
B
= –30 mA
I
C
= –300 mA, I
B
= –30 mA
V
CE
= –10 V, I
C
= –50 mA
V
CB
= –10 V, I
E
= 0, f = 1 MHz
90
50
100
– 0.2
– 0.9
120
10
30
– 0.4
–1.2
Min
–80
–80
–5
– 0.1
220
Typ
Max
Unit
V
V
V
mA
V
V
MHz
pF
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *1: Pulse measurement
*2: Rank classification
Code
Rank
h
FE1
Marking Symbol
Q
Q
90 to 155
4CQ
R
R
130 to 220
4CR
0
No-rank
90 to 220
4C
Product of no-rank is not classified and have no marking symbol for rank.
Publication date: May 2012
Ver. CED
1
