ADE-ED6812/4: DescriptionDouble Balanced Mixer, 830MHz Min, 3160MHz Max, CASE CD542, 6 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size90KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric Compare View All

ADE-ED6812/4 Overview

Double Balanced Mixer, 830MHz Min, 3160MHz Max, CASE CD542, 6 PIN

ADE-ED6812/4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mini-Circuits
Reach Compliance Code	unknown
Characteristic impedance	50 Ω
structure	COMPONENT
JESD-609 code	e0
Maximum operating frequency	3160 MHz
Minimum operating frequency	830 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
RF/Microwave Device Types	DOUBLE BALANCED
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	1.55

Preview

Download Datasheet

View All

Engineering Development Model

Frequency Mixer

Level 7 (LO Power +7 dBm)

Important Note

This model has been designed, built and tested in our engineering

department. Performance data represents model capability.

At present it is a non-catalog model. On request, we can supply a

final specification sheet, part number and price/delivery information.

ADE-ED6812/4

Please click "Back", and then click "Contact Us" for Applications support.

CASE STYLE : CD542

ELECTRICAL SPECIFICATIONS 50Ω @ +25°C

Parameter

Frequency

LO

(f

L

to f

U

)

RF

(f

L

to f

U

)

IF

Min.

830

500

Typ.

Max.

3160

1300

Units

MHz

dB

Conversion Loss

LO-RF Isolation

LO-IF Isolation

7.5

34

17

MAXIMUM RATINGS

Operating Temperature

Storage Temperature

-40°C to 85°C

-55°C to 100°C

PIN CONNECTIONS

LO

RF

IF

GROUND

1

4

5

2, 3, 6

REV. X1

ADE-ED6812/4

060619

Page 1 of 1

ADE-ED6812/4 Related Products

	ADE-ED6812/4	ADE-ED6812/4+
Description	Double Balanced Mixer, 830MHz Min, 3160MHz Max, CASE CD542, 6 PIN	Double Balanced Mixer, 830MHz Min, 3160MHz Max, CASE CD542, 6 PIN
Is it lead-free?	Contains lead	Lead free
Is it Rohs certified?	incompatible	conform to
Maker	Mini-Circuits	Mini-Circuits
Reach Compliance Code	unknown	unknown
Characteristic impedance	50 Ω	50 Ω
structure	COMPONENT	COMPONENT
JESD-609 code	e0	e3
Maximum operating frequency	3160 MHz	3160 MHz
Minimum operating frequency	830 MHz	830 MHz
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C
RF/Microwave Device Types	DOUBLE BALANCED	DOUBLE BALANCED
Terminal surface	Tin/Lead (Sn/Pb)	Tin (Sn) - with Nickel (Ni) barrier
Maximum voltage standing wave ratio	1.55	1.55
