3.3V, SMD, LV-PECL Oscillator
Model: FCPAXT Series
Page 1 of 1
RoHS Compliant / Pb Free
XpressO
®
Equivalent
FXO-PC73
Rev. 3/9/2007 Preliminary
http://www.foxonline.com/need_a_sample.htm
FEATURES
•
•
•
•
3.3V Operation
LV-PECL
Enable/Disable
Tape and Reel (2,000 pcs. STD)
Why XpressO?
Lower Cost, Faster Delivery, Low Jitter!
• PART NUMbER SELECTION
Learn More - Internet Required
Model
Number
728-Frequency-xxxxx FCP90AXT
745-Frequency-xxxxx FCP95AXT
Part Number
Frequency Operating
Frequency
Stability
1
Temperature
Range (MHz)
±100PPM -10 ~ +70
(ºC)
12.000 ~ 600.000
±50PPM -10 ~ +70
(ºC)
12.000 ~ 600.000
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
o
)
Storage Temperature Range (T
stg
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
Output Symmetry (50% Vp-p)
Rise Time (20% ~ 80% Vp-p) (T
r
)
Fall Time (80% ~ 20% Vp-p) (T
f
)
Output Voltage
(V
ol
)
(V
oh
)
Output Load
Start-up Time
(T
s
)
Output Disable Time
Output Enable Time
Phase Noise (@ 10kHz)
Phase Jitter (12kHz ~ 20MHz)
Maximum Soldering Temp / Time
Moisture Sensitivity Level (MSL)
1
12.000 ~ 600.000 MHz
-55ºC ~ +125ºC
3.3V ± 5%
120mA
40% ~ 60%
0.5nS
0.5nS
1.7V
2.2V Min
See Recommended Circuit
10mS
100nS
10mS
-120dBc/Hz
5pS RMS
260ºC / 10 Seconds
1
MAX
(unless otherwise noted)
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, vibration
.
2
An internal pulldown resistor from pin 2 to pin 3 allows active output if pin 2 is left open.
Note: A 0.01µF bypass capacitor should be placed between V
dd
(Pin 6) and GND (Pin 3) to
minimize power supply line noise.
All specifications subject to change without notice.
FCPAXT Series Recommended Circuit
TERMINATIONS: Au
All dimensions are in millimeters.
• ENAbLE / DISAbLE FUNCTION
2
(Pin 2)
OUTPUT (Pin 4, Pin 5)
OPEN
ACTIVE
'1' Level V
ih
≥
V
dd
-1.1V
High Z
'0' Level V
il
≤
V
dd
-1.6V
ACTIVE
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554
http://www.foxonline.com
© 2008 FOX ELECTRONICS | ISO9001:2000 Certified
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282 |
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486
|
Japan
Tel: +81.3.3374.2079 Fax: +81.3.3374.5221
