8-1437558-7

Description
TOGGLE SWITCH, SPDT, LATCHED AND MOMENTARY, 4A, 28VDC, PANEL MOUNT
CategoryMechanical and electronic products    switch
File Size133KB,2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

8-1437558-7 Overview

TOGGLE SWITCH, SPDT, LATCHED AND MOMENTARY, 4A, 28VDC, PANEL MOUNT

8-1437558-7 Parametric

Parameter NameAttribute value
Brand NameAlcoswitch
Is it Rohs certified?incompatible
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
Actuator typeFLAT TYPE
body width8 mm
body height10 mm
Body length or diameter13 mm
Contact (AC) maximum rated R load6A@125VAC
Maximum contact current (AC)6 A
Maximum contact current (DC)4 A
Contact (DC) maximum rated R load4A@28VDC
Maximum contact voltage (AC)125 V
Maximum contact voltage (DC)28 V
Electrical life40000 Cycle(s)
JESD-609 codee4
Manufacturer's serial number1437558
Installation featuresPANEL MOUNT-THREADED
Maximum operating force14.71 N
Maximum operating temperature80 °C
Minimum operating temperature-20 °C
sealEPOXY TERMINAL SEALED
surface mountNO
Switch actionLATCHED AND MOMENTARY
switch functionSPDT
Switch typeTOGGLE SWITCH
Terminal surfaceGold (Au)
Termination typeSOLDER
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Switches & Knobs > Product Feature Selector > Product Details
MTF106H Product Details
Toggle Switches
Not EU RoHS or ELV Compliant
 (
Find RoHS Compliant Alternates
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
MTF Series
Single Pole ­ Double Throw Configuration (Pole­Throw)
Current Rating = 6 A
Mount Style = Panel
Termination Type = Vertical, Wire Lugs
MTF106H
(8­1437558­7)
TE Internal Number: 8­1437558­7
View all Features
 Superseded
Search for Replacement Parts
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Additional Product Images:
Dimensional Drawing
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Current Rating (A) = 6
Termination Features:
Termination Type = Vertical, Wire Lugs
Seal Type = Terminal Seal (Insert Molded)
Dimensions:
Toggle Length (mm [in]) = 12.32 [0.485]
Body Features:
Mount Style = Panel
Bushing Style = Threaded
Bushing Type = 1/4­40
Actuator Finish = Satin Chrome
Contact Features:
Contact Plating = Gold Flash over Silver
Housing Features:
Toggle Style = Flat
Process Sealed = No
Configuration Features:
Configuration (Pole­Throw) = Single Pole ­ Double Throw
Operating Function = On Off (On)
Industry Standards:
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
UL Flammability Rating = UL 94V­0
Other:
Series = MTF
Brand = Alcoswitch
Comment = UL available when ordering ­ consult factory.
