DATA SHEET
MOS FIELD EFFECT TRANSISTOR
2SK3794
SWITCHING
N-CHANNEL POWER MOS FET
DESCRIPTION
The 2SK3794 is N-channel MOS Field Effect Transistor
designed for high current switching applications.
ORDERING INFORMATION
PART NUMBER
2SK3794
2SK3794-Z
PACKAGE
TO-251 (MP-3)
TO-252 (MP-3Z)
FEATURES
•
Low On-state resistance
R
DS(on)1
= 44 mΩ MAX. (V
GS
= 10 V, I
D
= 10 A)
R
DS(on)2
= 78 mΩ MAX. (V
GS
= 4.0 V, I
D
= 10 A)
•
Low C
iss
: C
iss
= 760 pF TYP.
•
Built-in gate protection diode
•
TO-251/TO-252 package
(TO-252)
(TO-251)
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Drain to Source Voltage (V
GS
= 0 V)
Gate to Source Voltage (V
DS
= 0 V)
Drain Current (DC) (T
C
= 25°C)
Drain Current (pulse)
Note1
V
DSS
V
GSS
I
D(DC)
I
D(pulse)
P
T1
P
T2
T
ch
T
stg
60
±20
±20
±50
30
1.0
150
−55
to +150
15
23
23
V
V
A
A
W
W
°C
°C
A
mJ
mJ
Total Power Dissipation (T
C
= 25°C)
Total Power Dissipation (T
A
= 25°C)
Channel Temperature
Storage Temperature
Single Avalanche Current
Single Avalanche Energy
Note2
Note2
Note3
I
AS
E
AS
E
AR
Repetitive Avalanche Energy
Notes 1.
PW
≤
10
μ
s, Duty Cycle
≤
1%
2.
Starting T
ch
= 25°C, V
DD
= 30 V, R
G
= 25
Ω,
V
GS
= 20
→
0 V
3.
I
AR
≤
15 A, T
ch
≤
150°C
