S-8000 Series
1
/
4
" x 1
1
/
4
" Fuse Blocks
Multiple Pole
Mounting Dimensions
No. of
Poles
1
2
3
4
5
6
7
8
9
10
11
12
Inches
A
–
1
1 /
8
"
1
3
/
4
"
2
3
/
8
"
3"
3
5
/
8
"
4
1
/
4
"
4
7
/
8
"
5
1
/
2
"
6
1
/
8
"
6
3
/
4
"
7
3
/
8
"
B
–
5
/
8
"
1
1
/
4
"
1
7
/
8
"
2
1
/
2
"
3
1
/
8
"
3
3
/
4
"
4
3
/
8
"
5"
5
5
/
8
"
6
1
/
4
"
6
7
/
8
"
Millimeters
A
–
28.6
44.4
60.3
76.2
92.1
108.0
123.8
139.7
155.6
171.4
187.3
B
–
15.9
31.8
47.6
63.5
79.4
95.2
111.1
127.0
142.9
158.8
174.6
Description
• For
1
/
4
" x 1
1
/
4
" (6.3 x 32mm) fuses
• Bolt-in and snap-in mounting available
• Tight cluster mounting
• All types of terminal configurations
• Clips made of spring-bronze
• Anti-rotational pin provided
• Flame retardant thermoplastic meets UL 94V0
Environmental Data
• Relative Temperature Index (RTI)
- Bolt-in 130°C
- Snap-in 110°C
Agency Information
• UL Recognized: E14853
• CSA Certified: 47235
Dimensions - mm/in.
S-8000 Single-Pole Bolt-In Mounting Series
40° Terminal
CSA Max. Amps
21
13
16
25
Specifications
Series
S-8000
S-8100
S-8200
S-8300
Volts
300Vac/dc
300Vac/dc
300Vac/dc
300Vac/dc
UL Max Amps
25
20
20
30
0°
Terminal
Dimensions - mm/in.
S-8000 Single-Pole Snap-In Mounting Series
40° Terminal
Screw
Terminal
Side
Terminal
0°
Terminal
Mounting
Side
Terminal
Mounting
Component
Clip
Body
Material
Spring-Bronze, Bright Tin-Plate
Thermoplastic
1207
BU-SB07222
Page 1 of 2
Data Sheet 2101
Packaging Code
Catalog Number Prefix
Blank
BK/
Description
Varies with number of poles. Contact customer service.
Varies with number of poles. Contact customer service.
Ordering
• Specify packaging, product, and
option code
Bolt-in Mounting Example:
BK/S-8102-6-R
BK/
1
S-8
2
1
3
02
4
6
5
- R
7
1. Packaging Code:
2. Series Number:
3. Type Terminal:
4. Terminal Angle:
5. Number of Poles:
6. Mounting Style:
7. RoHS Compliant Version
R
7
*Available only in single pole
Snap-in Mounting Example:
BK/S-8001-1-SNP-R
BK/
1
S-8
2
0
3
01 - 1 - SNP -
4
5
6
BK/
S-8
0 = Solder
1 =
3
/
16
" quick connect
2 =
1
/
4
" quick connect
3 = Screw
01 = Straight (0°)
02 = 40° Angle
03 = Side*
(1 – 12)
1X = One pole, No Mounting Stud
SNP = Snap-in Mounting*
-R
This bulletin is intended to present product design solutions and technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice,
to change design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any
technical information contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
Life Support Policy: Cooper Bussmann does not authorize the use of any of its products for use in life support devices or systems without the express written approval of an officer of the
Company. Life support systems are devices which support or sustain life, and whose failure to perform, when properly used in accordance with instructions for use provided in the labeling,
can be reasonably expected to result in significant injury to the user.
© 2007 Cooper Bussmann
S t . L o u i s, M O 6 3 1 7 8
w w w. c o o p e r bu s s m a n n . c o m
1207
BU-SB07222
Page 2 of 2
Data Sheet 2101
