BU-6174X/6184X/6186X
Make sure the next
Card you purchase
has...
TM
ENHANCED MINIATURE ADVANCED
COMMUNICATIONS ENGINE
FEATURES
•
Fully Integrated 1553A/B Notice 2,
McAir, STANAG 3838 Interface Terminal
•
Compatible with Mini-ACE (Plus)
and ACE Generations
•
Choice of :
-
RT or BC/RT/MT In Same Footprint
- RT or BC/RT/MT with 4K RAM
- BC/RT/MT with 64K RAM, and RAM
parity
•
Choice of 5V or 3.3V Logic
•
5V Transceiver with 1760 and McAir
Compatible Options
•
Comprehensive Built-In Self-Test
DESCRIPTION
The Enhanced Miniature Advanced Communications Engine
(Enhanced Mini-ACE) family of MIL-STD-1553 terminals provide com-
plete interfaces between a host processor and a 1553 bus, and integrate
dual transceiver, protocol logic, and 4K words or 64K words of RAM.
These terminals are nearly 100% footprint and software compatible
with the previous generation Mini-ACE (Plus) terminals, and are soft-
ware compatible with the older ACE series.
They are powered by a choice of 5V or 3.3V logic. Multiprotocol sup-
port of MIL-STD-1553A/B and STANAG 3838, including versions
incorporating McAir compatible transmitters, is provided. There is a
choice of 10, 12, 16, or 20 MHz clocks. The BC/RT/MT versions with
64K words of RAM include built-in RAM parity checking.
BC features include a built-in message sequence control engine, with
a set of 20 instructions. This provides an autonomous means of
implementing multi-frame message scheduling, message retry
schemes, data double buffering, asynchronous message insertion,
and reporting to the host CPU. The Enhanced Mini-ACE incorporates
a fully autonomous built-in self-test, which provides comprehensive
testing of the internal protocol logic and/or RAM.
The RT offers the same choices of subaddress buffering as the ACE
and Mini-ACE (Plus), along with a global circular buffering option,
50% rollover interrupt for circular buffers, an interrupt status queue,
and an "Auto-boot" option to support MIL-STD-1760.
These terminals provide the same flexibility in host interface configu-
rations as the ACE/Mini-ACE, along with a reduction in the host
processor's worst case holdoff time.
Data Device Corporation
105 Wilbur Place
Bohemia, New York 11716
631-567-5600 Fax: 631-567-7358
www.ddc-web.com
•
Flexible Processor/Memory Interface,
with Reduced Host Wait Time
•
Choice of 10, 12, 16, or 20 MHz Clock
•
Highly Autonomous BC with
Built-In Message Sequence Control:
- Frame Scheduling
- Branching
- Asynchronous Message Insertion
- General Purpose Queue
- User-defined Interrupts
•
Advanced RT Functions
- Global Circular Buffering
- Interrupt Status Queue
- 50% Circular Buffer Rollover
Interrupts
•
Selective Message Monitor
- Selection by Address, T/R Bit,
Subaddress
- Command and Data Stacks
- 50% and 100% Stack Rollover
Interrupts
