Power Transistor Arrays
PUB4121
(PU4121)
, PUB4421
(PU4421)
Silicon NPN triple diffusion planar type darlington
For power amplification
■
Features
•
Built-in zener diode (30 V) between collector and base
•
Small variation in withstand pressure
•
Large energy handling capability
•
High-speed switching
•
PUB4121 (PU4121): NPN 4 elements
PUB4421 (PU4421): NPN 2 elements
×
2
25.3
±0.2
Unit: mm
4.0
±0.2
9.5
±0.2
8.0
±0.2
0.8
±0.25
0.5
±0.15
1.0
±0.25
2.54
±0.2
9
×
2.54 = 22.86
±0.25
■
Absolute Maximum Ratings
T
C
=
25°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Emitter-base voltage (Collector open)
Collector current
Peak collector current
Collector power dissipation
T
a
=
25°C
Junction temperature
Storage temperature
T
j
T
stg
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
Rating
30±5
30±5
5
2
4
15
3.5
150
−55
to
+150
°C
°C
Unit
V
V
V
A
A
W
1.65
±0.2
Solder Dip
5.3
±0.5
4.4
±0.5
0.5
±0.15
C 1.5
±0.5
1: Emitter
2: Base
3: Collector
4: Base
5: Collector
1 2 3 4 5 6 7 8 9 10
6: Base
7: Collector
8: Base
9: Collector
10: Emitter
SIP10-A1 Package
■
Electrical Characteristics
T
C
=
25°C
±
3°C
Parameter
Collector-emitter voltage (Base open)
Collector-base cutoff current (Emitter open)
Emitter-base cutoff current (Collector open)
Forward current transfer ratio
Symbol
V
CEO
I
CBO
I
EBO
h
FE1
h
FE2 *1
Collector-emitter saturation voltage
Base-emitter saturation voltage
Transition frequency
Turn-on time
Storage time
Fall time
Energy handling capability
*2
V
CE(sat)
V
BE(sat)
f
T
t
on
t
stg
t
f
E
s/b
Conditions
I
C
=
5 mA, I
B
=
0
V
CB
=
25 V, I
E
=
0
V
EB
=
5 V, I
C
=
0
V
CE
=
4 V, I
C
=
1 A
V
CE
=
4 V, I
C
=
2 A
I
C
=
2 A, I
B
=
8 mA
I
C
=
2 A, I
B
=
8 mA
V
CE
=
10 V, I
C
=
0.5 A, f
=
1 MHz
I
C
=
2 A
I
B1
=
8 mA, I
B2
= −8
mA
V
CC
=
20 V
I
C
=
1.45 A, L
=
100 mH, R
BE
=
100
Ω
100
20
0.4
3.0
1.0
1 000
1 000
10 000
2.5
2.5
V
V
MHz
µs
µs
µs
mJ
Min
25
Typ
Max
35
100
2
Unit
V
µA
mA
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *1: Rank classification
*2: E
s/b
test circuit
X
Mercury relay
Rank
Free
P
Q
L
h
FE
1 000 to 10 000 2 000 to 10 000 1 000 to 5 000
Y
R
BE
Z
Note) The part numbers in the parenthesis show conventional part number.
Publication date: March 2004
SJK00064AED
1
