Amphenol
Miniature Box Interconnects
G800/1
Materials
Housing
Contacts
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 3A
– 250 VAC/rms 60Hz
2.54mm Pin Headers PCB Mount
This series was designed to offer both Board to Board (B2B)and Board to Wire (B2W) solutions.
The headers can be cut to size and are modular.
Contact Finish/Durability
Gold Flash
5µ” Gold
15µ” Gold
30µ” Gold
– 75 cycles
– 80 cycles
– 150 cycles
– 250 cycles
– G-19
– G-20/21/22
– G-25
– G-23
Electrical
Current
Voltage
Mating Half
Jumpers
B2B Rec.
Ribbon cable Rec.
B2W Rec.
Variations
►
3 Row PCB Mount 9 to 120 Positions
►
Various Post, Solder Tail and Insulator
Dimensions
Part Number System:
G80X XXX XXX X
2.54mm Pin Headers
Through-hole PCB Mount
TYPE
0: Straight
1: Right angle
POSITION CODE
See table
Position
Code
306
305
304
303
302
301
300
299
298
297
296
295
294
293
292
291
290
289
288
287
Position
Code
594
593
592
591
590
589
588
587
586
585
584
583
582
581
580
579
578
577
576
575
AMTA
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
CONTACT FINISH
*018: Full gold flash
025: 5µ” Gold
005: 15µ” Gold
010: 30µ” Gold
* Standard
No. of
Positions
1x2
1x3
1x4
1x5
1x6
1x7
1x8
1x9
1x10
1x11
1x12
1x13
1x14
1x15
1x16
1x17
1x18
1x19
1x20
1x21
No. of
Positions
2x2
2x3
2x4
2x5
2x6
2x7
2x8
2x9
2x10
2x11
2x12
2x13
2x14
2x15
2x16
2x17
2x18
2x19
2x20
2x21
Single Row (SIL)
Position
Dimensions (mm)
Code
A
B
5.08
2.54
286
7.62
5.08
285
10.16
7.62
284
12.70
10.16
283
15.24
12.70
282
17.78
15.24
281
20.32
17.78
280
22.86
20.32
279
25.40
22.86
278
27.94
25.40
277
30.48
27.94
276
33.02
30.48
275
35.56
33.02
274
38.10
35.56
273
40.64
38.10
272
43.18
40.46
271
45.72
43.18
270
48.26
45.72
269
50.80
48.26
268
53.34
50.80
Double Row (DIL)
Position
Dimensions (mm)
Code
A
B
5.08
2.54
574
7.62
5.08
573
10.16
7.62
572
12.70
10.16
571
15.24
12.70
570
17.78
15.24
569
20.32
17.78
568
22.86
20.32
567
25.40
22.86
566
27.94
25.40
565
30.48
27.94
564
33.02
30.48
563
35.56
33.02
562
38.10
35.56
561
40.64
38.10
560
43.18
40.46
559
45.72
43.18
558
48.26
45.72
557
50.80
48.26
556
53.34
50.80
No. of
Positions
1x22
1x23
1x24
1x25
1x26
1x27
1x28
1x29
1x30
1x31
1x32
1x33
1x34
1x35
1x36
1x37
1x38
1x39
1x40
Dimensions (mm)
A
B
55.88
53.34
58.42
55.88
60.96
58.42
63.50
60.96
66.04
63.50
68.58
66.04
71.12
68.58
73.66
71.12
76.20
73.66
78.74
76.20
81.28
78.74
83.82
81.28
86.36
83.82
88.90
86.36
91.44
88.90
93.98
91.44
96.52
93.98
99.06
96.52
101.60
99.06
No. of
Positions
2x22
2x23
2x24
2x25
2x26
2x27
2x28
2x29
2x30
2x31
2x32
2x33
2x34
2x35
2x36
2x37
2x38
2x39
2x40
Dimensions (mm)
A
B
55.88
53.34
58.42
55.88
60.96
58.42
63.50
60.96
66.04
63.50
68.58
66.04
71.12
68.58
73.66
71.12
76.20
73.66
78.74
76.20
81.28
78.74
83.82
81.28
86.36
83.82
88.90
86.36
91.44
88.90
93.98
91.44
96.52
93.98
99.06
96.52
101.60
99.06
AMTA Pin&Socket Catalogue
G-17
