UF1501/S - UF1507/S
1.5A ULTRA-FAST RECTIFIER
Features and Benefits
•
•
•
•
•
Diffused Junction
Ultra-Fast Switching for High Efficiency
Surge Overload Rating to 50A Peak
Low Reverse Leakage Current
Lead Free Finish, RoHS Compliant (Note 1)
Mechanical Data
•
•
•
•
•
•
•
•
Case: DO-41, DO-15
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish
⎯
Tin. Plated Leads Solderable per MIL-STD-
202, Method 208
Polarity: Cathode Band
Marking: Type Number
DO-41 Weight: 0.35 grams (approximate)
DO-15 Weight: 0.40 grams (approximate)
Ordering Information
(Note 2)
Device
UF1501-B
UF1501-T
UF1502-B
UF1502-T
UF1503-B
UF1503-T
UF1504-B
UF1504-T
UF1505-B
UF1505-T
UF1506-B
UF1506-T
UF1507-B
UF1507-T
UF1501S-B
UF1501S-T
UF1502S-B
UF1502S-T
UF1503S-B
UF1503S-T
UF1504S-B
UF1504S-T
UF1505S-B
UF1505S-T
UF1506S-B
UF1506S-T
UF1507S-B
UF1507S-T
Notes:
Packaging
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
DO-41
Shipping
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1K/Bulk
5K/Tape & Reel, 13-inch
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see
EU Directive 2002/95/EC Annex Notes
2. For packaging details, visit our website at http://www.diodes.com/datasheets/ap02007.pdf.
UF1501/S - UF1507/S
Document number: DS25006 Rev. 5 - 2
1 of 4
www.diodes.com
December 2010
© Diodes Incorporated
UF1501/S - UF1507/S
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage (Note 3)
RMS Reverse Voltage
Average Rectified Output Current (Note 4) @ T
A
= 50°C
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
UF
UF
UF
UF
UF
UF
UF
1501/S 1502/S 1503/S 1504/S 1505/S 1506/S 1507/S
50
35
100
70
200
140
400
280
1.5
50
600
420
800
560
1000
700
Unit
V
V
A
A
Thermal Characteristics
Characteristic
Typical Thermal Resistance Junction to Ambient
Operating and Storage Temperature Range
Symbol
R
θ
JA
T
J,
T
STG
Value
70
-65 to +150
Unit
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Forward Voltage @ I
F
= 1.5A
Peak Reverse Current @ T
A
= 25°C
at Rated DC Blocking Voltage (Note 3) @ T
A
= 100°C
Reverse Recovery Time (Note 5)
Typical Total Capacitance (Note 6)
Notes:
Symbol
V
FM
I
RM
t
rr
C
T
UF
UF
UF
UF
UF
UF
UF
1501/S 1502/S 1503/S 1504/S 1505/S 1506/S 1507/S
1.0
1.3
1.7
5.0
100
50
75
35
20
Unit
V
μA
ns
pF
3. Short duration pulse test used to minimize self-heating effect.
4. Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
5. Measured with I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A. See figure 5.
6. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
1.2
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
1.5
I
(AV)
, AVERAGE FORWARD RECTIFIED
CURRENT (A)
10
1.0
0.9
0.6
0.1
0.3
Single phase half-wave
60 Hz resistive or inductive load
0
25
0.01
0.6
0.8
1.0
1.2
1.4
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
50
75
100
125
150
175
200
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Forward Current Derating Curve
UF1501/S - UF1507/S
Document number: DS25006 Rev. 5 - 2
2 of 4
www.diodes.com
December 2010
© Diodes Incorporated
UF1501/S - UF1507/S
60
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
100
T
j
= 25
°
C
f = 1.0MHz
C
T
, TOTAL CAPACITANCE (pF)
UF1501 - UF1504
40
UF1505 - UF1507
10
20
0
1
10
NUMBER OF CYCLES AT 60Hz
Fig. 3 Peak Forward Surge Current
100
1
1
10
V
R
, DC REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance
100
Package Outline Dimensions
Dim
DO-41
Min
A
B
C
D
25.40
4.06
0.71
2.00
Max
⎯
5.21
0.864
2.72
DO-15
Min
25.40
5.50
0.686
2.60
Max
⎯
7.62
0.889
3.60
All Dimensions in mm
“S” Suffix Designates DO-41 Package
No Suffix Designates DO-15 Package
UF1501/S - UF1507/S
Document number: DS25006 Rev. 5 - 2
3 of 4
www.diodes.com
December 2010
© Diodes Incorporated
