RoHS
Axial Shielded Inductors
AS20
0.100±0.01
(2.54±0.25)
Dimensions:
Inches
(mm)
24AWG
1.15
NOMINAL
(29)
0.25±0.01
(6.35±0.25)
1.15
NOMINAL
(29)
Allied
Part
Number
AS20-R10K-RC
AS20-R12K-RC
AS20-R15K-RC
AS20-R18K-RC
AS20-R22K-RC
AS20-R27K-RC
AS20-R33K-RC
AS20-R39K-RC
AS20-R47K-RC
AS20-R56K-RC
AS20-R68K-RC
AS20-R82K-RC
AS20-1R0K-RC
AS20-1R2K-RC
AS20-1R5K-RC
AS20-1R8K-RC
AS20-2R2K-RC
AS20-2R7K-RC
AS20-3R3K-RC
AS20-3R9K-RC
AS20-4R7K-RC
AS20-5R6K-RC
AS20-6R8K-RC
AS20-8R2K-RC
AS20-100K-RC
AS20-120K-RC
AS20-150K-RC
AS20-180K-RC
AS20-220K-RC
AS20-270K-RC
AS20-330K-RC
AS20-390K-RC
AS20-470K-RC
AS20-560K-RC
AS20-680K-RC
AS20-820K-RC
AS20-101K-RC
AS20-121K-RC
AS20-151K-RC
AS20-181K-RC
AS20-221K-RC
AS20-271K-RC
AS20-331K-RC
AS20-391K-RC
AS20-471K-RC
AS20-561K-RC
AS20-681K-RC
AS20-821K-RC
AS20-102K-RC
Inductance
(µh)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
Tolerance
(%)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Q
Min.
39
36
35
33
35
33
33
32
33
30
30
33
35
29
29
29
28
32
32
38
38
40
46
45
45
40
45
45
45
48
54
54
54
60
55
57
60
58
60
60
60
60
60
60
60
60
60
60
60
Test
Freq.
(MHz)
25
25
25
25
25
25
25
25
25
25
25
25
25
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
SRF
Min.
(MHz)
400
400
400
400
400
400
370
348
312
286
262
188
166
149
136
118
110
94
86
85
79
72
65
59
53
60
53
45.8
42.2
31
26
24.2
22
21.2
29.9
16.8
13.2
11
9.1
7.4
7.2
6.8
5.5
5.1
5.0
4.9
4.6
4.2
4.0
DCR
Max.
(Ω)
0.071
0.087
0.109
0.145
0.165
0.192
0.228
0.259
0.348
0.417
0.580
0.132
0.169
0.184
0.260
0.360
0.410
0.550
0.620
0.790
0.910
1.15
1.73
1.96
2.30
0.55
.710
1.00
1.09
1.35
1.90
2.10
2.40
2.90
3.20
3.70
4.60
5.20
5.90
7.40
8.50
10.0
13.4
15.0
21.0
23.0
26.0
34.0
39.0
Rated
Current
(mA)
1580
1360
1280
1110
1040
965
885
830
717
655
555
1160
1030
985
825
705
664
577
540
475
445
395
320
302
280
570
500
423
404
364
305
293
271
248
237
219
198
184
173
156
145
133
115
109
92
88
82
72
67
Electrical
Rated Current:
Inductance will drop
< 10% at rated current.
Tolerance:
±10%
over the entire
inductance range. Tighter tolerances
available.
Shielding:
< 5% coupling with 2 units
side by side at 1 KHz.
Test Procedures:
L & Q Measured with
HP4342A Q-Meter at specified
Frequency. DCR Measured on CH-301
SRF Measured on HP-4191A, HP4291B.
Operating Temp.:
-55°C to + 125°C.
Physical
Marking (on part):
5 Band Color Code
per MIL-C-15305.
Marking (on reel):
Manufacturers
Name, Part Number, Customers
Part Number, Invoice Number, Lot
or Data Code.
Packaging (bulk):
1,000 pieces per bag.
Packaging (tape & reel):
5000 pieces
per reel.
For Tape and Reel packaging please
add ”-TR” to the part number.
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
REVISED 10/01/10
www.alliedcomponents.com
