MMBD4448H
SURFACE MOUNT SWITCHING DIODE
Features
•
•
•
•
•
Fast Switching Speed
Surface Mount Package Ideally Suited for Automated Insertion
For General Purpose Switching Applications
High Conductance
Lead Free/RoHS Compliant (Note 1)
Mechanical Data
•
•
•
•
•
•
Case: SOT23
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over Alloy 42 leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Polarity: See Diagram
Weight: 0.008 grams (approximate)
SOT23
Top View
Top View
Internal Schematic
Ordering Information
(Note 2)
Part Number
MMBD4448H-7-F
Notes:
Case
SOT23
Packaging
3000/Tape & Reel
1. No purposefully added lead.
2. For packaging details, go to our website at http://www.diodes.com.
Marking Information
KA3
KA3 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: N = 2002)
M = Month (ex: 9 = September)
Date Code Key
Year
2001
Code
M
Month
Code
Jan
1
2002
N
Feb
2
2003
P
2004
R
Mar
3
2005
S
Apr
4
2006
T
May
5
YM
2007
U
Jun
6
2008
V
2009
W
Jul
7
2010
X
Aug
8
2011
Y
Sep
9
2012
Z
Oct
O
2013
A
2014
B
Nov
N
2015
C
Dec
D
MMBD4448H
Document number: DS30176 Rev. 10 - 2
1 of 4
www.diodes.com
February 2011
© Diodes Incorporated
MMBD4448H
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Non-Repetitive Peak Reverse Voltage
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current (Note 3)
Average Rectified Output Current (Note 3)
Non-Repetitive Peak Forward Surge Current
Symbol
V
RM
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
@ t = 1.0μs
@ t = 1.0s
I
FSM
Value
100
80
57
500
250
4.0
1.0
Unit
V
V
V
mA
mA
A
Thermal Characteristics
Characteristic
Power Dissipation (Note 3)
Thermal Resistance Junction to Ambient Air (Note 3)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
350
357
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Reverse Breakdown Voltage (Note 4)
Forward Voltage
Symbol
V
(BR)R
V
F
Min
80
0.62
⎯
⎯
⎯
⎯
⎯
⎯
Max
⎯
0.72
0.855
1.0
1.25
100
50
30
25
3.5
4.0
Unit
V
V
Test Condition
I
R
= 2.5μA
I
F
= 5.0mA
I
F
= 10mA
I
F
= 100mA
I
F
= 150mA
V
R
= 70V
V
R
= 75V, T
J
= 150°C
V
R
= 25V, T
J
= 150°C
V
R
= 20V
V
R
= 6V, f = 1.0MHz
V
R
= 6V, I
F
= 5mA
Reverse Current (Note 4)
Total Capacitance
Reverse Recovery Time
Notes:
I
R
C
T
t
rr
nA
μA
μA
nA
pF
ns
3. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at http://www.diodes.com.
4. Short duration pulse test used to minimize self-heating effect.
400
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
500
P
D
, POWER DISSIPATION (mW)
1,000
100
300
10
T
A
= -40ºC
T
A
= 0ºC
200
100
1
T
A
= 25ºC
T
A
= 75ºC
T
A
= 125ºC
0
0
40
80
120
160
T
A
, AMBIENT TEMPERATURE (ºC)
Fig. 1 Power Derating Curve (Note 3)
200
0.1
0
0.8
0.4
1.2
1.6
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
MMBD4448H
Document number: DS30176 Rev. 10 - 2
2 of 4
www.diodes.com
February 2011
© Diodes Incorporated
