Aluminum Electrolytic Capacitors/ FR
Radial Lead Type
Series:
FR
Type:
A
■
Country of origin
Malaysia
■
Features
●
Low ESR (Same as FM Series)
●
Endurance : 2000 h to 10000 h at +105 °C
●
RoHS directive compliant
■
Specifications
Category Temp. Range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
tan
δ
–40 °C to +105 °C
6.3 V.DC to 50 V.DC
22 µF to 8200 µF
±20 % (120 Hz/+20 °C)
I
<
0.01 CV (µA) After 2 minutes
W.V.
6.3
10
16
25
35
50
tan
δ
0.22 0.19 0.16 0.14 0.12 0.10
Add 0.02 per 1000 µF for products of 1000 µF or more.
(120 Hz/+20 °C)
Endurance
After following life test with DC voltage and +105 °C±2 °C ripple current value applied. (The sum
of DC and ripple peak voltage shall not exceed the rated working voltage) when the capacitors
are restored to 20 °C, the capacitors shall meet the limits specified below.
Duration
φ5
11/
φ6.3
11.2 : 2000 hours,
φ8
11.5/
φ10
12.5 : 6000 hours
φ8
15/
φ10
16 : 8000 hours,
φ8×20
: 9000 hours
φ10
20 to
φ10
25/
φ12.5
20 to
φ12.5
35/
φ16
20 to
φ16
25 : 10000 hours
Capacitance change ±25 % of initial measured value (6.3 V to 10 V : ±30 %)
tan
δ
<
200 % of initial specified value
DC leakage current
<
initial specified value
Shelf Life
After storage for 1000 hours at +105 °C±2 °C with no voltage applied and then being stabilized
at +20 °C, capacitors shall meet the limits specified in Endurance. (With voltage treatment)
■
Frequency correction factor for ripple current
W.V.(V.DC)
22
6.3 to 50
47
390
1200
Cap (µF)
to
to
to
to
33
330
1000
8200
Frequency (Hz)
60
0.45
0.60
0.65
0.75
120
0.55
0.70
0.75
0.80
1k
0.75
0.85
0.90
0.95
10 k
0.90
0.95
0.98
1.00
100 k
1.00
1.00
1.00
1.00
■
Dimensions in mm (not to scale)
Sleeve
Pressure relief
φ6.3<
φd±0.05
<φ8
φ10<
[mm]
+
–
F±0.5
L
½
½
14 min.
3 min.
φD±0.5
φD±0.5
L<16 : L±1.5
L>20 : L±2.0
(mm)
Body Dia.
φD
Body Length L
Lead Dia.
φd
Lead space F
5
—
0.5
2.0
6.3
—
0.5
2.5
8
—
0.6
3.5
10
—
0.6
5.0
0.6
12.5
12.5 to 25
5.0
30 to 35
0.8
16
—
0.8
7.5
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
00 Sep. 2010
– EE100 –
Aluminum Electrolytic Capacitors/ FR
■
Case size/Impedance/Ripple current
W.V.(V.DC)
Case size
(φD L)
5
6.3
8
8
8
10
10
10
10
12.5
12.5
12.5
12.5
16
16
11
11.2
11.5
15
20
12.5
16
20
25
20
25
30
35
20
25
6.3 V to 35 V
Impedance
( /100 kHz)
+20 °C
0.300
0.130
0.056
0.041
0.030
0.043
0.028
0.020
0.018
0.018
0.015
0.013
0.012
0.017
0.014
–10 °C
1.000
0.430
0.168
0.123
0.090
0.114
0.078
0.057
0.054
0.045
0.038
0.033
0.030
0.043
0.035
Ripple Current
(mA r.m.s./100 kHz)
+105 °C
280
455
950
1240
1560
1290
1790
2180
2470
2600
3190
3630
3750
3300
3820
Impedance
( /100 kHz)
+20 °C
0.340
0.140
0.061
0.045
0.033
0.042
0.030
0.023
0.022
0.022
0.018
0.016
0.014
0.019
0.016
–10 °C
1.130
0.460
0.183
0.135
0.099
0.126
0.090
0.069
0.066
0.055
0.045
0.040
0.035
0.048
0.040
50 V
Ripple Current
(mA r.m.s./100 kHz)
+105 °C
250
405
870
1140
1430
1170
1650
1890
2150
2260
2660
3160
3270
2870
3320
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
00 Sep. 2010
– EE101 –
Aluminum Electrolytic Capacitors/ FR
■
Standard Products
W.V.
Specification
Lead Length
Ripple Imped- Endur- Lead
Lead Space
Cap.
Current ance ance
Dia.
(±20 %) Dia. Length
Taping Taping
(100 kHz) (100 kHz)
Straight
½B
½H
(+105 °C) (+20 °C)
(µF)
(mm) (mm) (mA r.m.s.) ( ) (hours) (mm) (mm) (mm) (mm)
150
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
330
6.3
11.2
455 0.130
2000
0.5
2.5
5.0
2.5
820
8
11.5
950 0.056 6000
0.6
3.5
5.0
8
15
1240 0.041
8000
0.6
3.5
5.0
1200
10
12.5
1290 0.043 6000
0.6
5.0
5.0
1500
8
20
1560 0.030 9000
0.6
3.5
5.0
1800 10
16
1790 0.028 8000
0.6
5.0
5.0
2200 10
20
2180 0.020 10000
0.6
5.0
5.0
2700 10
25
2470 0.018 10000
0.6
5.0
5.0
3900
12.5
20
2600 0.018 10000
0.6
5.0
5.0
4700
12.5
25
3190 0.015 10000
0.6
5.0
5.0
5600
12.5
30
3630 0.013 10000
0.8
5.0
12.5
35
3750 0.012 10000
0.8
5.0
6800
16
20
3300 0.017 10000
0.8
7.5
7.5
8200 16
25
3820 0.014 10000
0.8
7.5
7.5
100
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
150
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
220
6.3
11.2
455 0.130
2000
0.5
2.5
5.0
2.5
680
8
11.5
950 0.056 6000
0.6
3.5
5.0
820 10
12.5
1290 0.043 6000
0.6
5.0
5.0
1000
8
15
1240 0.041
8000
0.6
3.5
5.0
8
20
1560 0.030 9000
0.6
3.5
5.0
1500
10
16
1790 0.028 8000
0.6
5.0
5.0
1800 10
20
2180 0.020 10000
0.6
5.0
5.0
2200 10
25
2470 0.018 10000
0.6
5.0
5.0
3300
12.5
20
2600 0.018 10000
0.6
5.0
5.0
3900
12.5
25
3190 0.015 10000
0.6
5.0
5.0
12.5
30
3630 0.013 10000
0.8
5.0
4700
16
20
3300 0.017 10000
0.8
7.5
7.5
12.5
35
3750 0.012 10000
0.8
5.0
5600
12.5
35
3750 0.012 10000
0.8
5.0
6800
16
25
3820 0.014 10000
0.8
7.5
7.5
68
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
100
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
120
6.3
11.2
455 0.130
2000
0.5
2.5
5.0
2.5
220
6.3
11.2
455 0.130
2000
0.5
2.5
5.0
2.5
470
8
11.5
950 0.056 6000
0.6
3.5
5.0
8
15
1240 0.041
8000
0.6
3.5
5.0
680
10
12.5
1290 0.043 6000
0.6
5.0
5.0
8
20
1560 0.030 9000
0.6
3.5
5.0
1000
10
16
1790 0.028 8000
0.6
5.0
5.0
10
20
2180 0.020 10000
0.6
5.0
5.0
1500
10
25
2470 0.018 10000
0.6
5.0
5.0
1800 10
25
2470 0.018 10000
0.6
5.0
5.0
2200
12.5
20
2600 0.018 10000
0.6
5.0
5.0
2700
12.5
25
3190 0.015 10000
0.6
5.0
5.0
12.5
30
3630 0.013 10000
0.8
5.0
3300
16
20
3300 0.017 10000
0.8
7.5
7.5
12.5
35
3750 0.012 10000
0.8
5.0
3900
16
20
3300 0.017 10000
0.8
7.5
7.5
12.5
35
3750 0.012 10000
0.8
5.0
4700
16
25
3820 0.014 10000
0.8
7.5
7.5
5600 16
25
3820 0.014 10000
0.8
7.5
7.5
Case size
Min. Packaging Q'ty
Part No.
Straight
Taping
Leads
(pcs)
200
200
200
200
200
200
200
200
200
200
200
100
100
100
100
200
200
200
200
200
200
200
200
200
200
200
200
100
100
100
100
100
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
100
100
100
100
100
100
(pcs)
2000
2000
1000
1000
500
1000
500
500
500
500
500
(V)
6.3
10
16
EEUFR0J151( )
EEUFR0J331( )
EEUFR0J821( )
EEUFR0J122L( )
EEUFR0J122( )
EEUFR0J152L( )
EEUFR0J182( )
EEUFR0J222( )
EEUFR0J272L( )
EEUFR0J392( )
EEUFR0J472( )
EEUFR0J562L
EEUFR0J682L
EEUFR0J682S( )
EEUFR0J822( )
EEUFR1A101( )
EEUFR1A151( )
EEUFR1A221( )
EEUFR1A681( )
EEUFR1A821( )
EEUFR1A102L( )
EEUFR1A152L( )
EEUFR1A152( )
EEUFR1A182( )
EEUFR1A222L( )
EEUFR1A332( )
EEUFR1A392( )
EEUFR1A472L
EEUFR1A472S( )
EEUFR1A562L
EEUFR1A682L
EEUFR1A682( )
EEUFR1C680( )
EEUFR1C101( )
EEUFR1C121( )
EEUFR1C221( )
EEUFR1C471( )
EEUFR1C681L( )
EEUFR1C681( )
EEUFR1C102L( )
EEUFR1C102( )
EEUFR1C152( )
EEUFR1C152L( )
EEUFR1C182L( )
EEUFR1C222( )
EEUFR1C272( )
EEUFR1C332L
EEUFR1C332S( )
EEUFR1C392L
EEUFR1C392S( )
EEUFR1C472L
EEUFR1C472( )
EEUFR1C562( )
250
250
2000
2000
2000
1000
500
1000
1000
500
500
500
500
500
250
250
2000
2000
2000
2000
1000
1000
500
1000
500
500
500
500
500
500
250
250
250
250
When requesting taped product, please put the letter "B" or "H" between the "( )". Lead wire pitch B=5 mm, 7.5 mm, H=2.5 mm.
The taping dimensions are explained on EE189 of our Catalog. Please use it as a reference guide.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
01 Dec. 2010
– EE102 –
Aluminum Electrolytic Capacitors/ FR
■
Standard Products
W.V.
Specification
Lead Length
Ripple Imped- Endur- Lead
Lead Space
Cap.
Current ance ance
Dia.
(±20 %) Dia. Length
Taping Taping
(100 kHz) (100 kHz)
Straight
½B
½H
(+105 °C) (+20 °C)
(µF)
(mm) (mm) (mA r.m.s.) ( ) (hours) (mm) (mm) (mm) (mm)
47
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
68
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
100
6.3
11.2
455 0.130 2000
0.5
2.5
5.0
2.5
150
6.3
11.2
455 0.130 2000
0.5
2.5
5.0
2.5
330
8
11.5
950 0.056 6000
0.6
3.5
5.0
390
8
15
1240 0.041 8000
0.6
3.5
5.0
8
15
1240 0.041 8000
0.6
3.5
5.0
470
8
20
1560 0.030 9000
0.6
3.5
5.0
10
12.5
1290 0.043 6000
0.6
5.0
5.0
560
8
20
1560 0.030 9000
0.6
3.5
5.0
8
20
1560 0.030 9000
0.6
3.5
5.0
680
10
16
1790 0.028 8000
0.6
5.0
5.0
820 10
20
2180 0.020 10000
0.6
5.0
5.0
10
20
2180 0.020 10000
0.6
5.0
5.0
1000
10
25
2470 0.018 10000
0.6
5.0
5.0
1200 10
25
2470 0.018 10000
0.6
5.0
5.0
1500 12.5
20
2600 0.018 10000
0.6
5.0
5.0
1800 12.5
25
3190 0.015 10000
0.6
5.0
5.0
12.5
30
3630 0.013 10000
0.8
5.0
2200
16
20
3300 0.017 10000
0.8
7.5
7.5
12.5
35
3750 0.012 10000
0.8
5.0
2700
16
20
3300 0.017 10000
0.8
7.5
7.5
3300 16
25
3820 0.014 10000
0.8
7.5
7.5
33
5
11
280 0.300 2000
0.5
2.0
5.0
2.5
0.5
2.5
5.0
2.5
68
6.3
11.2
455 0.130 2000
180
8
11.5
950 0.056 6000
0.6
3.5
5.0
8
15
1240 0.041 8000
0.6
3.5
5.0
270
10
12.5
1290 0.043 6000
0.6
5.0
5.0
390
8
20
1560 0.030 9000
0.6
3.5
5.0
8
20
1560 0.030 9000
0.6
3.5
5.0
470
10
16
1790 0.028 8000
0.6
5.0
5.0
560 10
20
2180 0.020 10000
0.6
5.0
5.0
10
20
2180 0.020 10000
0.6
5.0
5.0
680
10
25
2470 0.018 10000
0.6
5.0
5.0
820 10
25
2470 0.018 10000
0.6
5.0
5.0
1000 12.5
20
2600 0.018 10000
0.6
5.0
5.0
1200 12.5
25
3190 0.015 10000
0.6
5.0
5.0
12.5
30
3630 0.013 10000
0.8
5.0
1500
16
20
3300 0.017 10000
0.8
7.5
7.5
1800 12.5
35
3750 0.012 10000
0.8
5.0
12.5
35
3750 0.012 10000
0.8
5.0
2200
16
25
3820 0.014 10000
0.8
7.5
7.5
22
5
11.5
250 0.340 2000
0.5
2.0
5.0
2.5
56
6.3
11.2
405 0.140 2000
0.5
2.5
5.0
2.5
100
8
11.5
870 0.061 6000
0.6
3.5
5.0
120
8
15
1140 0.045 8000
0.6
3.5
5.0
1170 0.042 6000
0.6
5.0
5.0
150 10
12.5
180
8
20
1430 0.033 9000
0.6
3.5
5.0
220 10
16
1650 0.030 8000
0.6
5.0
5.0
270 10
20
1890 0.023 10000
0.6
5.0
5.0
330 10
25
2150 0.022 10000
0.6
5.0
5.0
470 12.5
20
2260 0.022 10000
0.6
5.0
5.0
560 12.5
25
2660 0.018 10000
0.6
5.0
5.0
680 12.5
30
3160 0.016 10000
0.8
5.0
12.5
35
3270 0.014 10000
0.8
5.0
820
16
20
2870 0.019 10000
0.8
7.5
7.5
1000 16
25
3320 0.016 10000
0.8
7.5
7.5
Case size
Min. Packaging Q'ty
Part No.
Straight
Taping
Leads
(pcs)
2000
2000
2000
2000
1000
1000
1000
1000
500
1000
1000
500
500
500
500
500
500
500
250
250
250
2000
2000
1000
1000
500
1000
1000
500
500
500
500
500
500
500
250
(V)
25
35
50
(pcs)
EEUFR1E470( )
200
EEUFR1E680( )
200
EEUFR1E101( )
200
EEUFR1E151( )
200
EEUFR1E331( )
200
EEUFR1E391L( )
200
EEUFR1E471Y( )
200
EEUFR1E471L( )
200
EEUFR1E471( )
200
EEUFR1E561L( )
200
EEUFR1E681L( )
200
EEUFR1E681( )
200
EEUFR1E821( )
200
EEUFR1E102( )
200
EEUFR1E102L( )
200
EEUFR1E122L( )
200
EEUFR1E152( )
200
EEUFR1E182( )
200
EEUFR1E222L
100
EEUFR1E222S( )
100
EEUFR1E272L
100
EEUFR1E272S( )
100
EEUFR1E332( )
100
EEUFR1V330( )
200
EEUFR1V680( )
200
EEUFR1V181( )
200
EEUFR1V271L( )
200
EEUFR1V271( )
200
EEUFR1V391L( )
200
EEUFR1V471L( )
200
EEUFR1V471( )
200
EEUFR1V561( )
200
EEUFR1V681( )
200
EEUFR1V681L( )
200
EEUFR1V821L( )
200
EEUFR1V102( )
200
EEUFR1V122( )
200
EEUFR1V152L
100
EEUFR1V152S( )
100
EEUFR1V182L
100
EEUFR1V222L
100
EEUFR1V222( )
100
EEUFR1H220( )
200
EEUFR1H560( )
200
EEUFR1H101( )
200
EEUFR1H121L( )
200
EEUFR1H151( )
200
EEUFR1H181L( )
200
EEUFR1H221( )
200
EEUFR1H271( )
200
EEUFR1H331L( )
200
EEUFR1H471( )
200
EEUFR1H561( )
200
EEUFR1H681L
100
EEUFR1H821L
100
EEUFR1H821S( )
100
EEUFR1H102( )
100
250
2000
2000
1000
1000
500
1000
500
500
500
500
500
250
250
When requesting taped product, please put the letter "B" or "H" between the "( )". Lead wire pitch B=5 mm, 7.5 mm, H=2.5 mm.
The taping dimensions are explained on EE189 of our Catalog. Please use it as a reference guide.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
01 Dec. 2010
– EE103 –
Analog electronics
京公网安备 11010802033920号
EEWORLD
