BZT52C2V0T - BZT52C24T
SURFACE MOUNT ZENER DIODE
Features
•
•
•
•
Ultra-Small Surface Mount Package
Flat Lead Package Design for Low Profile and High Power
Dissipation.
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Mechanical Data
•
•
•
•
•
•
•
•
Case: SOD-523
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminal Connections: Cathode Band
Terminals: Finish - Matte Tin annealed over Alloy 42 leadframe.
Solderable per MIL-STD-202, Method 208
Marking Information: See Page 3
Ordering Information: See Page 3
Weight: 0.001 grams (approximate)
Top View
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Forward Voltage
@ I
F
= 10mA
Symbol
V
F
Value
0.9
Unit
V
Thermal Characteristics
Characteristic
Power Dissipation (Note 3)
Thermal Resistance, Junction to Ambient Air (Note 3)
Operating and Storage Temperature Range
Notes:
Symbol
P
D
R
θ
JA
T
J,
T
STG
Value
300
417
-65 to +150
Unit
mW
°C/W
°C
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Part mounted on FR-4 PC board, single-sided, 2oz. copper with pad areas 1.92mm
2
.
BZT52C2V0T - BZT52C24T
Document number: DS30502 Rev. 10 - 2
1 of 4
www.diodes.com
July 2009
© Diodes Incorporated
BZT52C2V0T - BZT52C24T
30
T
J
= 25°C
C10T
C12T
1,000
T
J
= 25°C
f = 1MHz
C
T
, TOTAL CAPACITANCE (pF)
V
R
= 1V
V
R
= 2V
I
Z
, ZENER CURRENT (mA)
20
C15T
C18T
100
V
R
= 1V
10
Test current I
Z
5mA
C22T
V
R
= 2V
0
0
10
20
30
V
Z
, ZENER VOLTAGE (V)
Fig. 3 Typical Zener Breakdown Characteristics
10
10
100
V
Z
, NOMINAL ZENER VOLTAGE (V)
Fig. 4 Typical Total Capacitance vs. Nominal Zener Voltage
1
Ordering Information
(Note 6)
Case
SOD-523
Packaging
3000/Tape & Reel
Part Number
(Type Number)-7* (Note 7)
*Add “-7” to the appropriate type number in Electrical Characteristics Table, example: 6.2V Zener = BZT52C6V2T-7.
Notes:
6. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
7.
Dispensed in every other cavity of the tape.
Marking Information
xx = Product Type Marking Code
(See Electrical Characteristics Table)
xx
Package Outline Dimensions
L
C
H
SOD-523
Dim
Min
Max
A
0.25
0.35
B
0.70
0.90
C
1.50
1.70
H
1.10
1.30
K
0.55
0.65
L
0.10
0.30
M
0.10
0.12
All Dimensions in mm
A
B
K
M
BZT52C2V0T - BZT52C24T
Document number: DS30502 Rev. 10 - 2
3 of 4
www.diodes.com
July 2009
© Diodes Incorporated
BZT52C2V0T - BZT52C24T
Suggested Pad Layout
C
X
Dimensions Value (in mm)
Z
2.3
G
1.1
X
0.8
Y
0.6
C
1.7
Y
G
Z
