Green

DFLS1100

1.0A HIGH VOLTAGE SCHOTTKY BARRIER RECTIFIER

POWERDI

Product Summary

V

RRM

(V)

100

I

O

(A)

1

V

F max

(V)

0.77

I

R max

(µA)

0.35

Features and Benefits



Guard Ring Die Construction for Transient Protection

Low Power Loss, High Efficiency

Patented Interlocking Clip Design for High Surge Current

Capacity

Lead Free Finish, RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

PPAP Capable (Note 4)

Description and Applications

This Schottky Barrier Rectifier is designed to meet the stringent

requirements of Automotive Applications. It is ideally suited for use

as:



Polarity Protection Diode



Re-circulating Diode



Switching Diode

Mechanical Data



Case: POWERDI

®

123

Case Material: Molded Plastic, ―Green‖ Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminal Connections: Cathode Band

Terminals: Finish – Matte Tin Annealed over Copper

Leadframe. Solderable per MIL-STD-202, Method 208

Weight: 0.01 grams (Approximate)

Top View

Ordering Information

(Note 5)

Part Number

DFLS1100-7

DFLS1100Q-7

Notes:

Compliance

Commercial

Automotive

Case

POWERDI

®

123

POWERDI

®

123

Packaging

3000/Tape & Reel

1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green‖ products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally

the same, except where specified. For more information, please refer to http://www.diodes.com/product_compliance_definitions.html.

5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Marking Information

F09 = Product Type Marking Code

YM = Date Code Marking

Y = Year (ex: B = 2014)

M = Month (ex: 9 = September)

Date Code Key

Year

Code

Month

Code

2013

A

Jan

1

Feb

2

2014

B

Mar

3

2015

C

Apr

4

2016

D

May

5

Jun

6

2017

E

Jul

7

2018

F

Aug

8

2019

G

Sep

9

Oct

O

2020

H

Nov

N

2021

I

Dec

D

POWERDI is a registered trademark of Diodes Incorporated.

DFLS1100

Document number: DS30497 Rev. 13 - 2

1 of 6

www.diodes.com

December 2015

DFLS1100

Maximum Ratings

(@T

A

= +25° unless otherwise specified.)

C,

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load, derate current by 20%.

Characteristic

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

RMS Reverse Voltage

Forward Current rms (T

C

= +160° D = 0.5)

C,

Average Forward Current

Non-Repetitive Peak Forward Surge Current 8.3ms

Single Half Sine-Wave Superimposed on Rated Load

Repetitive Peak Reverse Current

t

P

= 2μs, f = 1kHz Square

Repetitive Peak Avalanche Power

t

P

= 1µs, T

J

= +25°

C

Non-repetitive Peak Reverse Current

t

P

= 100μs Square

Critical Rate of Rise of Reverse Voltage

(Rated V

R

, T

J

= +25°

C)

Symbol

V

RRM

V

RWM

V

R

V

R(RMS)

I

F(RMS)

I

F(AV)

I

FSM

I

RRM

P

ARM

I

RSM

dV/dt

Value

100

71

2

1.0

50

1.0

1500

1.0

10000

Unit

V

A

W

A

V/μs

Thermal Characteristics

Characteristic

Thermal Resistance Junction to Soldering (Note 6)

Thermal Resistance Junction to Ambient (Note 7) T

A

= +25°

C

Thermal Resistance Junction to Case (Note 7) T

A

= +25°

C

Operating and Storage Temperature Range

Symbol

R



JS

R



JA

R



JC

T

J

, T

STG

Typ

—

125

21

-55 to +175

Max

7

—

Unit

°

C/W

C

Electrical Characteristics

(@T

A

= +25° unless otherwise specified.)

C,

Characteristic

Reverse Breakdown Voltage (Note 8)

Symbol

V

(BR)R

V

F

Min

100











Typ



0.58



0.65









36

Max



0.77

0.62

0.86

0.7

0.10

3

15

0.35



Unit

Test Condition

V

I

R

= 1mA

I

F

= 1.0A, T

A

= +25C

I

F

= 1.0A, T

A

= +125C

V

I

F

= 2.0A, T

A

= +25C

I

F

= 2.0A, T

A

= +125C

µA V

R

= 50V, T

A

= +25C

µA V

R

= 50V, T

A

= +65C

µA V

R

= 50V, T

A

= +85C

µA V

R

= 100V, T

A

= +25C

mA V

R

= 100V, T

A

= +125C

pF V

R

= 5V

DC

, f = 1MHz

Forward Voltage

Leakage Current (Note 8)

I

R

Total Capacitance

Notes:

C

T

6. Theoretical R

θJS

calculated from the top center of the die straight down to the PCB/cathode tab solder junction.

7. Part mounted on FR-4 board with 2oz., minimum recommended copper pad layout, which can be found on our website at http://www.diodes.com.

8. Short duration pulse test used to minimize self-heating effect.

POWERDI is a registered trademark of Diodes Incorporated.

DFLS1100

Document number: DS30497 Rev. 13 - 2

2 of 6

www.diodes.com

December 2015

DFLS1100

I

F

, INSTANTANEOUS FORWARD CURRENT (A)

2

1.8

10

1

P

D

, POWER DISSIPATION (W)

1.6

1.4

1.2

1

0.8

0.6

0.4

0.2

0

2

2.5

0.5

1

3

3.5

1.5

I

F(AV)

, AVERAGE FORWARD CURRENT (A)

Fig. 1 Forward Power Dissipation

T

A

= 175

°

C

0.1

T

A

= 150

°

C

T

A

= 125

°

C

0.01

0.001

T

A

= 75

°

C

0.0001

T

A

= 25

°

C

T

A

= -55

°

C

0.00001

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

V

F

, INSTANTANEOUS FORWARD VOLTAGE (V)

Fig. 2 Typical Forward Characteristics

0

V

R

, INSTANTANEOUS REVERSE VOLTAGE (V)

Fig. 3 Typical Reverse Characteristics

1.2

I

F(AV)

, AVERAGE FORWARD CURRENT (A)

C

T

, TOTAL CAPACITANCE (pF)

0

10

15

20

V

R

, DC REVERSE VOLTAGE (V)

Fig. 4 Total Capacitance vs. Reverse Voltage

5

100,000

1.0

P

ARM

, MAXIMUM AVALANCHE POWER (W)

10,000

T

J

= 25癈

C

0.8

Note 4

1,000

0.6

100

0.4

0.2

10

0

25

50

75 100 125 150 175

T

A

, AMBIENT TEMPERATURE ( °

C)

Fig. 5 Forward Current Derating Curve

200

1

0.01

0.1

1

10

100

T

P

, PULSE DURATION

µs)

)

(礢

Fig. 6 Maximum Avalanche Power Curve

1,000

POWERDI is a registered trademark of Diodes Incorporated.

DFLS1100

Document number: DS30497 Rev. 13 - 2

3 of 6

www.diodes.com

December 2015

DFLS1100

120

P

ARM

, AVALANCHE PEAK PULSE POWER

DERATING IN PERCENTAGE (%)

100

80

60

40

20

0

25

50

75

100

125

150

T

J

, JUNCTION TEMPERATURE (°C)

Fig. 7 Pulse Derating Curve

175

POWERDI is a registered trademark of Diodes Incorporated.

DFLS1100

Document number: DS30497 Rev. 13 - 2

4 of 6

www.diodes.com

December 2015

DFLS1100

Package Outline Dimensions

Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.

POWERDI

®

123

D

POWERDI

®

123

E1

A3

A

L(2X)

L1

b

b2

Dim

Min

Max

Typ

A

0.93

1.00

0.98

A3

0.15

0.25

0.20

b

0.85

1.25

1.00

b2

1.025 1.125 1.10

D

1.63

1.93

1.78

E

3.50

3.90

3.70

E1

2.60

3.00

2.80

L

0.40

0.50

0.45

L1

1.25

1.40

1.35

L3

0.125 0.275 0.20

All Dimensions in mm

L3

E

L3

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

POWERDI

®

123

X2

Dimensions

Y

Y1

X

G

X1

G

X

X1

X2

Y

Y1

Value

(in mm)

0.65

1.05

2.40

4.10

1.50

POWERDI is a registered trademark of Diodes Incorporated.

DFLS1100

Document number: DS30497 Rev. 13 - 2

5 of 6

www.diodes.com

December 2015

DFLS1100_09
