DXT2907A
60V PNP TRANSISTOR IN SOT89
Features
BV
CEO
> -60V
Ideal for Medium Power Switching or Amplification Applications
Ideally Suited for Automated Assembly Processes
Complementary NPN Type Available (DXT2222A)
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case: SOT89
Case Material: Molded Plastic, “Green” Molding Compound
UL Flammability Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish - Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.072 grams (Approximate)
SOT89
C
E
B
C
E
C
B
Top View
Pin-Out
Top View
Device Symbol
Ordering Information
(Note 4)
Part Number
DXT2907A-13
Notes:
Marking
K2F
Reel Size (inches)
13
Tape Width (mm)
12
Quantity Per Reel
2,500
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html
.
Marking Information
SOT89
K2F = Product Type Marking Code
YWW = Date Code Marking
Y = Last Digit of Year (ex: 5 = 2015)
WW = Week Code (01 to 53)
YWW
K2F
DXT2907A
Document number: DS30944 Rev. 6 - 2
1 of 7
www.diodes.com
January 2016
© Diodes Incorporated
DXT2907A
Absolute Maximum Ratings
(@T
A
= +25° unless otherwise specified.)
C,
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Peak Collector Current
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CM
Value
-60
-60
-5
-600
-800
Unit
V
V
V
mA
mA
Thermal Characteristics
(@T
A
= +25° unless otherwise specified.)
C,
Characteristic
Power Dissipation
Thermal Resistance, Junction to Ambient Air
Operating and Storage Temperature Range
(Note 5)
(Note 6)
(Note 5)
(Note 6)
Symbol
P
D
R
JA
T
J
, T
STG
Value
0.75
1.2
166
104
-55 to +150
Unit
W
°
C/W
°
C
ESD Ratings
(Note 7)
Characteristic
Electrostatic Discharge - Human Body Model
Electrostatic Discharge - Machine Model
Notes:
Symbol
ESD HBM
ESD MM
Value
4,000
400
Unit
V
V
JEDEC Class
3A
C
5
.
For a device mounted with the exposed collector pad on minimum recommended pad layout 1oz copper that is on a single-sided 1.6mm FR-4 PCB;
device is measured under still air conditions whilst operating in a steady-state.
6. Same as note 5, except the device is mounted with the exposed collector pad on 25mm x 25mm 1oz copper.
7. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
DXT2907A
Document number: DS30944 Rev. 6 - 2
2 of 7
www.diodes.com
January 2016
© Diodes Incorporated
DXT2907A
Electrical Characteristics
Characteristic
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage (Note 8)
Emitter-Base Breakdown Voltage
Collector Cut-off Current
Collector Cutoff Current
Emitter Cut-off Current
ON CHARACTERISTICS (Note 8)
75
100
Static Forward Current Transfer Ratio
h
FE
100
100
50
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
Input Capacitance
Current Gain-Bandwidth Product
SWITCHING CHARACTERISTICS
Turn-On Time
Delay Time
Rise Time
Turn-Off Time
Storage Time
Fall Time
Note:
(@T
A
= +25° unless otherwise specified.)
C,
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
CEX
I
EBO
Min
-60
-60
-5
—
—
—
Typ
-120
-80
-8.8
-1
—
—
—
208
207
202
169
103
-130
-0.4
-0.86
-1
—
—
—
Max
—
—
—
-50
-50
-50
-50
—
—
Unit
V
V
V
nA
µA
nA
nA
—
—
—
—
—
mV
V
V
V
pF
pF
MHz
ns
ns
ns
ns
ns
ns
Test Condition
I
C
= -100µA
I
C
= -10mA
I
E
= -100µA
V
CB
= -50V
V
CB
= -50V, T
A
= +100°
C
V
CE
= -30V, V
EB(OFF)
= -0.5V
V
EB
= -5V
I
C
= -100A, V
CE
= -10V
I
C
= -1mA, V
CE
= -10V
I
C
= -10mA, V
CE
= -10V
I
C
= -150mA, V
CE
= -10V
I
C
= -500mA, V
CE
= -10V
I
C
= -150mA, I
B
= -15mA
I
C
= -500mA, I
B
= -50mA
I
C
= -150mA, I
B
= -15mA
I
C
= -500mA, I
B
= -50mA
V
CB
= -10V, I
E
= 0, f = 1MHz
V
EB
= -2V, f = 1MHz, I
C
= 0
V
CE
= -20V, I
C
= -50mA,
f = 100MHz
V
CC
= -30V, I
C
= -150mA,
I
B1
= -15mA
V
CC
= -6V, I
C
= -150mA,
I
B1
=I
B2
= -15mA
—
300
—
V
CE(SAT)
V
BE(SAT))
—
—
—
—
—
200
-400
-1.6
-1.3
-2.6
8
30
45
10
40
100
80
30
C
obo
C
ibo
f
T
t
ON
t
D
t
R
t
OFF
t
S
t
F
8. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
DXT2907A
Document number: DS30944 Rev. 6 - 2
3 of 7
www.diodes.com
January 2016
© Diodes Incorporated
DXT2907A
Typical Electrical Characteristics
(@T
A
= +25° unless otherwise specified.)
C,
-I
C
, COLLECTOR CURRENT (A)
0
-V
CE
, COLLECTOR EMITTER VOLTAGE (V)
Fig.
1
Typical Collector Current as a
2
Function of Collector Emitter Voltage
5
-V
BE(ON)
, BASE-EMITTER TURN-ON VOLTAGE (V)
h
FE
, DC CURRENT GAIN
-I
C
, COLLECTOR CURRENT (A)
Fig.
2
Typical DC Current Gain vs. Collector Current
3
5
1.2
-V
CE(SAT)
, COLLECTOR-EMITTER
SATURATION VOLTAGE (V)
1
0.8
0.6
0.4
0.2
0
0.1
1
10
100
1000
-I
C
, COLLECTOR CURRENT (mA)
Fig.
3
Typical Collector-Emitter Saturation Voltage
4
vs. Collector Current
5
1.2
I
C
/I
B
= 10
-I
C
, COLLECTOR CURRENT (mA)
Fig.
4
Typical Base-Emitter Turn-On Voltage
5
vs. Collector Current
5
35
30
25
20
15
10
5
-V
BE(SAT)
, BASE-EMITTER
SATURATION VOLTAGE (V)
1
0.8
0.6
0.4
0.2
0
0.1
1
10
100
1000
-I
C
, COLLECTOR CURRENT (mA)
Fig.
5
Typical Base-Emitter Saturation Voltage
6
vs. Collector Current
5
CAPACITANCE (pF)
0
0.1
1
10
100
V
R
, REVERSE VOLTAGE (V)
Fig.
6
Typical Capacitance Characteristics
7
5
DXT2907A
Document number: DS30944 Rev. 6 - 2
4 of 7
www.diodes.com
January 2016
© Diodes Incorporated
DXT2907A
500
1.0
f
T
, GAIN BANDWIDTH PRODUCT (MHz)
450
400
350
300
250
200
150
100
50
0
0
20
40
60
80
100
P
D
, POWER DISSIPATION (mW)
0.8
0.6
0.4
0.2
0
150
25
75
100
125
50
o
T
A
, AMBIENT TEMPERATURE
( C)
(癈 )
Fig.
8
Power Dissipation vs. Ambient Temperature (Note 3)
1
0
-I
C
, COLLECTOR CURRENT (mA)
Fig.
7
Typical Gain-Bandwidth Product
8
5
vs. Collector Current
5
DXT2907A
Document number: DS30944 Rev. 6 - 2
5 of 7
www.diodes.com
January 2016
© Diodes Incorporated
