DXT3150
NPN SURFACE MOUNT TRANSISTOR
Features
NEW PRODUCT
•
•
•
•
•
Epitaxial Planar Die Construction
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
SOT89-3L
Mechanical Data
•
•
•
•
•
•
•
Case: SOT89-3L
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Terminals: Finish — Matte Tin annealed over Copper leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Marking & Type Code Information: See Page 3
Ordering Information: See Page 3
Weight: 0.072 grams (approximate)
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
C
Value
50
25
7
5
Unit
V
V
V
A
3 E
C 4
2 C
1 B
COLLECTOR
2,4
1
BASE
TOP VIEW
3
EMITTER
Schematic and Pin Configuration
Maximum Ratings
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Continuous Collector Current
Characteristic
Thermal Characteristics
Characteristic
Power Dissipation (Note 3) @ T
A
= 25°C
Thermal Resistance, Junction to Ambient Air (Note 3) @T
A
= 25°C
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
j
, T
STG
Value
1
125
-55 to +150
Unit
W
°C/W
°C
Electrical Characteristics
Characteristic
OFF CHARACTERISTICS (Note 4)
Collector-Emitter Breakdown Voltage
Collector Cut-off Current
Emitter Cut-off Current
ON CHARACTERISTICS (Note 4)
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
DC Current Gain
SMALL SIGNAL CHARACTERISTICS
Current Gain-Bandwidth Product
Output Capacitance
Notes:
1.
2.
3.
4.
@T
A
= 25°C unless otherwise specified
Symbol
V
(BR)CEO
I
CBO
I
EBO
V
CE(SAT)
V
BE(SAT)
h
FE
Min
25
⎯
⎯
⎯
⎯
250
150
50
⎯
⎯
Typ
⎯
⎯
⎯
⎯
⎯
⎯
Max
⎯
1.0
1.0
0.35
0.50
1.10
1.40
550
⎯
⎯
⎯
50
Unit
V
μA
μA
V
V
⎯
Test Conditions
I
C
= 10mA, I
B
= 0
V
CB
= 50V, I
E
= 0
V
EB
= 7.0V, I
C
= 0
I
C
= 3.0A, I
B
= 150mA
I
C
= 4.0A, I
B
= 200mA
I
C
= 3.0A, I
B
= 150mA
I
C
= 4.0A, I
B
= 200mA
I
C
= 500mA, V
CE
= 2.0V
I
C
= 2.0A, V
CE
= 2.0V
I
C
= 5.0A, V
CE
= 2.0V
I
C
= 50mA, V
CE
= 6.0V,
f = 100MHz
V
CB
= 10V, I
E
= 0, f = 1MHz
f
T
C
obo
220
⎯
MHz
pF
No purposefully added lead.
Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
Device mounted on FR-4 PCB; pad layout as shown on page 3 or in Diodes Inc. suggested pad layout document AP02001, which can be found on our
website at http://www.diodes.com/datasheets/ap02001.pdf.
Measured under pulsed conditions. Pulse width = 300μs. Duty cycle
≤2%.
DS31157 Rev. 3 - 2
1 of 3
www.diodes.com
DXT3150
© Diodes Incorporated
Ordering Information
(Note 5)
Device
DXT3150-13
Notes:
5.
Packaging
SOT89-3L
Shipping
2500/Tape & Reel
For packaging details, go to our website at http://www.diodes.com/ap02007.pdf.
NEW PRODUCT
Marking Information
(Top View)
YWW
N52
N52 = Product Type Marking Code
YWW = Date Code Marking
Y = Last digit of year ex: 7 = 2007
WW = Week code 01 - 52
Package Outline Dimensions
D1
0
20
0.
R
C
SOT89-3L
Dim
A
B
H
Min
1.40
0.45
0.37
0.35
4.40
1.50
2.40
—
3.95
0.90
Max
1.60
0.55
0.47
0.43
4.60
1.70
2.60
—
4.25
1.20
Typ
1.50
0.50
0.42
0.38
4.50
1.60
2.50
1.50
4.10
1.05
E
B1
C
D
D1
E
e
B
B1
8°
e
(4X
)
L
A
H
L
D
All Dimensions in mm
Suggested Pad Layout
1.7
2.7
0.4
1.9
1.3
0.9
3.0
Unit: mm
IMPORTANT NOTICE
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product
described herein; neither does it convey any license under its patent rights, nor the rights of others. The user of products in such applications shall
assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on our website,
harmless against all damages.
LIFE SUPPORT
Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written
approval of the President of Diodes Incorporated.
DS31157 Rev. 3 - 2
3 of 3
www.diodes.com
DXT3150
© Diodes Incorporated
