M80-8980201 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> M80-8980201

M80-8980201: Description7 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET; CategoryThe connector The connector; File Size82KB，1 Pages; ManufacturerHarwin; Websitehttp://www.harwin.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

M80-8980201 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	M80-8980201	-	-	View	Buy Now

M80-8980201 Overview

7 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET

M80-8980201 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Harwin
package instruction	LEAD FREE
Reach Compliance Code	compli
ECCN code	EAR99
Other features	ROHS COMPLIANT
body width	0.136 inch
subject depth	0.321 inch
body length	0.281 inch
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrie
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact resistance	25 mΩ
Contact style	RND PIN-SKT
DIN compliance	NO
Durability	500 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	2.78 N
Insulation resistance	100000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED POLYESTER
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.079 inch
Mixed contacts	NO
Installation option 1	LOCKING
Installation type	CABLE
Number of rows loaded	1
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
Plating thickness	12u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	3 A
Guideline	UL
reliability	COMMERCIAL
Termination type	CRIMP
Total number of contacts	2
UL Flammability Code	94V-0
Maximum wire diameter	24 AWG
Minimum wire diameter	28 AWG
Evacuation force-minimum value	.1946 N

Preview

Download Datasheet

View All

M80-8980201 Related Products

	M80-8980201	M80-8980701	M80-89807T6	M80-89802T6	M80-8981701	M80-89817T6
Description	7 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET	7 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET	7 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET	2 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET	7 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET	17 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, CRIMP, SOCKET
Is it lead-free?	Lead free	Lead free	Contains lead	Contains lead	Lead free	Contains lead
Is it Rohs certified?	conform to	conform to	incompatible	incompatible	conform to	incompatible
Maker	Harwin	Harwin	Harwin	Harwin	Harwin	Harwin
Reach Compliance Code	compli	compli	unknow	unknow	compli	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
body width	0.136 inch	0.136 inch	0.136 inch	0.136 inch	0.136 inch	0.136 inch
subject depth	0.321 inch	0.321 inch	0.321 inch	0.321 inch	0.321 inch	0.321 inch
body length	0.281 inch	0.675 inch	0.675 inch	0.281 inch	1.463 inch	1.463 inch
Body/casing type	SOCKET	SOCKET	SOCKET	SOCKET	SOCKET	SOCKET
Connector type	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR	BOARD CONNECTOR
Contactor design	PREASSEM CONN	PREASSEM CONN	PREASSEM CONN	PREASSEM CONN	PREASSEM CONN	PREASSEM CONN
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED	TIN LEAD (51)	TIN LEAD (51)	NOT SPECIFIED	TIN LEAD (51)
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrie	Matte Tin (Sn)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Matte Tin (Sn)	Tin/Lead (Sn/Pb)
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
Contact material	NOT SPECIFIED	NOT SPECIFIED	BERYLLIUM COPPER	BERYLLIUM COPPER	NOT SPECIFIED	BERYLLIUM COPPER
contact mode	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Contact resistance	25 mΩ	25 mΩ	25 mΩ	25 mΩ	25 mΩ	25 mΩ
Contact style	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT	RND PIN-SKT
DIN compliance	NO	NO	NO	NO	NO	NO
Durability	500 Cycles	500 Cycles	500 Cycles	500 Cycles	500 Cycles	500 Cycles
Filter function	NO	NO	NO	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	NO
maximum insertion force	2.78 N	2.78 N	2.78 N	2.78 N	2.78 N	2.78 N
Insulation resistance	100000000 Ω	100000000 Ω	100000000 Ω	100000000 Ω	100000000 Ω	100000000 Ω
insulator material	GLASS FILLED POLYESTER	GLASS FILLED POLYESTER	GLASS FILLED POLYESTER	GLASS FILLED POLYESTER	GLASS FILLED POLYESTER	GLASS FILLED POLYESTER
JESD-609 code	e3	e3	e0	e0	e3	e0
MIL compliance	NO	NO	NO	NO	NO	NO
Plug contact pitch	0.079 inch	0.079 inch	0.079 inch	0.079 inch	0.079 inch	0.079 inch
Mixed contacts	NO	NO	NO	NO	NO	NO
Installation type	CABLE	CABLE	CABLE	CABLE	CABLE	CABLE
Number of rows loaded	1	1	1	1	1	1
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Plating thickness	12u inch	12u inch	12u inch	12u inch	12u inch	12u inch
Rated current (signal)	3 A	3 A	3 A	3 A	3 A	3 A
Guideline	UL	UL	UL	UL	UL	UL
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Termination type	CRIMP	CRIMP	CRIMP	CRIMP	CRIMP	CRIMP
Total number of contacts	2	7	7	2	17	17
UL Flammability Code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
Maximum wire diameter	24 AWG	24 AWG	24 AWG	24 AWG	24 AWG	24 AWG
Minimum wire diameter	28 AWG	28 AWG	28 AWG	28 AWG	28 AWG	28 AWG
Evacuation force-minimum value	.1946 N	.1946 N	.1946 N	.1946 N	.1946 N	.1946 N
