2SC4102 / 2SC3906K
2SC4102FRA / 2SC3906KFRA
NPN 50mA 120V High Voltage Amplifier transistors
lOutline
Parameter
Value
UMT3
Base
Emitter
Datasheet
AEC-Q101 Qualified
V
CEO
I
C
120V
50mA
Collector
SMT3
Base
Collector
Emitter
lFeatures
1) High Breakdown Voltage (V
CEO
=120V).
2) Complementary PNP Types :
2SA1579FRA (UMT3) / 2SA1514KFRA (SMT3)
2SA1579 (UMT3) / 2SA1514K (SMT3)
3) Complex transistors :
IMX8 (SMT6)
IMX8FRA (SMT6)
4) Lead Free/RoHS Compliant.
2SC4102FRA
2SC4102
SOT-323 (SC-70)
2SC3906K
2SC3906KFRA
SOT-346 (SC-59)
lInner
circuit
Collector
lApplications
Base
Emitter
High Voltage Amplifier
lPackaging
specifications
Part No.
2SC4102
2SC4102FRA
2SC3906K
2SC3906KFRA
*1 x : h
FE
rank
Package
UMT3
SMT3
Package
size
(mm)
2021
2928
Taping
code
T106
T146
Basic
Reel size Tape width
ordering
(mm)
(mm)
unit (pcs)
180
180
8
8
3,000
3,000
Marking
Tx
*1
Tx
*1
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
1/7
2013.05 - Rev.B
2SC4102FRA / 2SC3906KFRA
lAbsolute
maximum ratings
(Ta = 25°C)
Parameter
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Power dissipation
Junction temperature
Range of storage temperature
lElectrical
characteristics(Ta
= 25°C)
Parameter
Collector-emitter
breakdown voltage
Collector-base
breakdown voltage
Emitter-base
breakdown voltage
Collector cut-off current
Emitter cut-off current
Collector-emitter
saturation voltage
DC current gain
Transition frequency
Output capacitance
*1 P
W
=100ms Single Pulse
*2 Each terminal mounted on a reference footprint
lh
FE
rank categories
Rank
h
FE
R
180 to 390
S
270 to 560
Symbol
BV
CEO
BV
CBO
BV
EBO
I
CBO
I
EBO
V
CE(sat)
h
FE
f
T
Cob
Conditions
I
C
= 1mA
I
C
= 50mA
I
E
= 50mA
V
CB
= 100V
V
EB
= 4V
I
C
= 10mA, I
B
= 1mA
V
CE
= 6V, I
C
= 2mA
V
CE
= 12V, I
E
=
-2mA
f=100MH
Z
V
CB
= 12V, I
E
= 0mA,
f = 1MHz
Data Sheet
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP *1
2SC4102FRA
2SC4102
2SC3906K
2SC3906KFRA
Values
120
120
5
50
100
200
150
-55
to
+150
Unit
V
V
V
mA
mA
mW
°C
°C
P
D
*2
T
j
T
stg
Min.
120
120
5
-
-
-
180
-
-
Typ.
-
-
-
-
-
-
-
140
2.5
Max.
-
-
-
0.5
0.5
0.5
560
-
-
Unit
V
V
V
mA
mA
V
-
MHz
pF
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
2/7
2013.05 - Rev.B
2SC4102FRA / 2SC3906KFRA
lElectrical
characteristic curves(Ta
= 25°C)
Data Sheet
Fig.1 Ground Emitter Propagation Characteristics
10
Fig.2 Typical Output Characteristics
COLLECTOR CURRENT : I
C
[mA]
1
Ta=-40ºC
25ºC
100ºC
0.1
0
0.5
1
1.5
2
BASE TO EMITTER VOLTAGE : V
BE
[V]
COLLECTOR CURRENT : I
C
[mA]
V
CE
= 6V
COLECTOR TO EMITTE VOLTAGE : V
CE
[V]
Fig.3 DC Current Gain vs. Collector Current(I)
1000
V
CE
= 6V
Fig.4 DC Current Gain vs. Collector Current(II)
1000
Ta=25ºC
DC CURRENT GAIN : h
FE
100
Ta=100ºC
25ºC
-40ºC
DC CURRENT GAIN : h
FE
100
V
CE
= 5V
3V
1V
10
0.1
1
10
100
10
0.1
1
10
100
COLLECTOR CURRENT : I
C
[mA]
COLLECTOR CURRENT : I
C
[mA]
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
3/7
2013.05 - Rev.B
2SC4102FRA / 2SC3906KFRA
lElectrical
characteristic curves(Ta
= 25°C)
Data Sheet
Fig.5 Collector-Emitter Saturation Voltage
vs. Collector Current (I)
1
I
C
/ I
E
= 10/1
Fig.6 Collector-Emitter Saturation Voltage
vs. Collector Current (II)
1
Ta=25ºC
COLLECTOR-EMITTER
SATURATION VOLTAGE : V
CE(sat)
[V]
COLLECTOR-EMITTER
SATURATION VOLTAGE : V
CE(sat)
[V]
0.1
Ta=100ºC
25ºC
-40ºC
I
C
/ I
B
=50/1
20/1
10/1
0.1
0.01
0.1
1
10
100
0.01
0.1
1
10
100
COLLECTOR CURRENT : I
C
[mA]
COLLECTOR CURRENT : I
C
[mA]
Fig.7 Base-Emitter Saturation Voltage
vs. Collector Current
10
Fig.8 Gain Bandwidth Product
vs. Emitter Current
TRANSITION FREQUENCY : f
T
[MHz]
I
C
/ I
B
= 10/1
BASE-EMITTER
SATURATION VOLTAGE : V
BE(sat)
[V]
Ta=
-40ºC
25ºC
100ºC
1
0.1
1
10
100
COLLECTOR CURRENT : I
C
[mA]
EMITTER CURRENT :I
E
[mA]
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
4/7
2013.05 - Rev.B
2SC4102FRA / 2SC3906KFRA
lElectrical
characteristic curves(Ta
= 25°C)
Fig.9 Emitter input capacitance vs.
Emitter-Base Voltage
Collector output capacitance vs.
Collector-Base Voltage
COLLECTOR OUTPUT CAPACITANCE : Cob [pF]
EMITTER INPUT CAPACITANCE : Cib [pF]
100
Data Sheet
Fig.10 Safe Operating Area
1000
2SC4102
COLLECTOR CURRENT : I
C
[mA]
Ta=25ºC
f=1MHz
I
C
=0A
I
E
=0A
1ms
100
10ms
C
ib
10
10
100ms
DC
(Mounted on a
reference land)
Ta=25ºC
Single non repetitive pulse
C
ob
1
1
0.1
1
10
100
0.1
0.1
1
10
100
1000
COLLECTOR - BASE VOLTAGE : V
CB
[V]
EMITTER - BASE VOLTAGE : V
EB
[V]
COLLECTOR TO EMITTER VOLTAGE : V
CE
[V]
Fig.11 Safe Operating Area
1000
2SC3906K
1ms
10ms
100
COLLECTOR CURRENT : I
C
[mA]
10
100ms
DC
(Mounted on a
reference land)
Ta=25ºC
Single non repetitive pulse
1
0.1
0.1
1
10
100
1000
COLLECTOR TO EMITTER VOLTAGE : V
CE
[V]
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
5/7
2013.05 - Rev.B
