DN0150ALP4 / DN0150BLP4
50V NPN SMALL SIGNAL TRANSISTOR IN DFN1006
Features
BV
CEO
> 50V
I
C
= 100mA High Collector Current
P
D
= 1000mW Power Dissipation
0.60mm
2
Package Footprint, 13 times Smaller than SOT23
0.4mm Height Package Minimizing Off-Board Profile
Complementary PNP Type: DP0150ALP4/DP0150BLP4
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case: X2-DFN1006-3
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish
NiPdAu.
Solderable per MIL-STD-202, Method 208
e4
Weight: 0.0008 grams (Approximate)
NEW PRODUCT
X2-DFN1006-3
B
C
E
Bottom View
Device Symbol
Top View
Pin Configuration
Ordering Information
(Note 4)
Product
DN0150ALP4-7
DN0150ALP4-7B
DN0150BLP4-7
DN0150BLP4-7B
Notes:
Marking
T3
T3
T4
T4
Reel size (inches)
7
7
7
7
Tape width (mm)
8
8
8
8
Quantity per reel
3,000
10,000
3,000
10,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
XX
DN0150ALP4-7
DN0150BLP4-7
Top View
Dot Denotes Collector Side
From date code 1527 (YYWW),
this changes to:
XX
Top View
Bar Denotes Base and Emitter Side
XX
XX
XX
DN0150ALP4-7B
DN0150BLP4-7B
Top View
Bar Denotes Base and Emitter Side
XX = Product Type Marking Code
(See Ordering Information)
XX
XX
XX
DN0150ALP4 / DN0150BLP4
Document number: DS31492 Rev. 7 - 2
1 of 5
www.diodes.com
XX
XX
XX
XX
May 2015
© Diodes Incorporated
DN0150ALP4 / DN0150BLP4
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current – Continuous
Peak Pulse Collector Current
Base Current
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
Value
60
50
5
100
200
30
Unit
V
V
V
mA
mA
mA
NEW PRODUCT
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Power Dissipation
Thermal Resistance, Junction to Ambient
Thermal Resistance, Junction to Lead
Operating and Storage and Temperature Range
(Note 5)
(Note 6)
(Note 5)
(Note 6)
(Note 7)
Symbol
P
D
R
JA
R
JL
T
J
, T
STG
Value
400
1000
310
120
120
-55 to +150
Unit
mW
C/W
°C/W
°C
ESD Ratings
(Note 8)
Characteristic
Electrostatic Discharge - Human Body Model
Electrostatic Discharge - Machine Model
Symbol
ESD HBM
ESD MM
Value
4,000
400
Unit
V
V
JEDEC Class
3A
C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
V
CE(SAT)
h
FE
Min
60
50
5
—
—
—
120
200
60
—
Typ
—
—
—
—
—
0.10
—
—
—
1.3
Max
—
—
—
0.1
0.1
0.25
240
400
—
—
Unit
V
V
V
μA
μA
V
—
Test Condition
I
C
= 10μA, I
E
= 0
I
C
= 1mA, I
B
= 0
I
E
= 10μA, I
C
= 0
V
CB
= 60V, I
E
= 0
V
EB
= 5V, I
C
= 0
I
C
= 100mA, I
B
= 10mA
V
CE
= 6V, I
C
= 2mA
V
CE
= 10V, I
E
= -1mA
f = 30MHz
V
CB
= 10V, I
E
= 0,
f = 1MHz
Characteristic
OFF CHARACTERISTICS
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage (Note 8)
Emitter-Base Breakdown Voltage
Collector Cut-Off Current
Emitter Cut-Off Current
ON CHARACTERISTICS (Note 9)
Collector-Emitter Saturation Voltage
DC Current Gain
DN0150ALP4
DN0150BLP4
SMALL SIGNAL CHARACTERISTICS
Transition Frequency
Output Capacitance
Notes:
f
T
C
ob
MHz
pF
5. For the device mounted on minimum recommended pad layout 1oz copper that is on a single-sided 1.6mm FR4 PCB; device is measured under still air
conditions whilst operating in steady state condition. The entire exposed collector pad is attached to the heatsink.
6. Same as Note 5, except the exposed collector pad is mounted on 25mm x 25mm 2oz copper.
7. Thermal resistance from junction to solder-point (on the exposed collector pad).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
9. Measured under pulsed conditions. Pulse width
300µs. Duty cycle
2%.
DN0150ALP4 / DN0150BLP4
Document number: DS31492 Rev. 7 - 2
2 of 5
www.diodes.com
May 2015
© Diodes Incorporated
DN0150ALP4 / DN0150BLP4
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
600
500
0.20
P
D
, POWER DISSIPATION (W)
I
C
, COLLECTOR CURRENT (A)
0.15
I
B
= 1mA
I
B
= 2mA
I
B
= 3mA
I
B
= 4mA
I
B
= 5mA
NEW PRODUCT
400
300
0.10
200
0.05
100
0
R
JA
= 278°C/W
0
0
25
50
75
100
125
150
T
A
, AMBIENT TEMPERATURE (
C)
Fig. 1 Power Dissipation vs. Ambient Temperature (Note 3)
1,000
T
A
= 150°C
T
A
= 85°C
V
CE
= 6V
0
1
2
3
4
V
CE
, COLLECTOR-EMITTER VOLTAGE (V)
Fig. 2 Typical Collector Current
vs. Collector-Emitter Voltage (DN0150BLP4)
5
1
T
A
= 25°C
T
A
= -55°C
V
C E(SAT)
, COLLECTOR-EMITTER
SATURATION VOLTAGE (V)
I
C
/I
B
= 10
h
FE
, DC CURRENT GAIN
100
0.1
T
A
= 150°C
T
A
= 85°C
T
A
= 25°C
T
A
= -55°C
10
0.1
1
10
100
I
C
, COLLECTOR CURRENT (mA)
Fig. 3 Typical DC Current Gain
vs. Collector Current (DN0150BLP4)
1,000
0.01
0.0001
V
BE(ON)
, BASE-EMITTER TURN-ON VOLTAGE (V)
1.2
I
C
/I
B
= 10
V
BE(SAT)
, BASE-EMITTER SATURATION VOLTAGE (V)
0.001
0.01
0.1
1
I
C
, COLLECTOR CURRENT (A)
Fig. 4 Typical Collector-Emitter Saturation Voltage
vs. Collector Current
V
CE
= 6V
1.2
1.0
1.0
0.8
T
A
= -55°C
0.8
T
A
= -55°C
0.6
T
A
= 25°C
0.6
0.4
T
A
= 85°C
T
A
= 25°C
0.2
T
A
= 150°C
0.4
T
A
= 85°C
0
0.0001
T
A
= 150°C
0.001
0.01
0.1
I
C
, COLLECTOR CURRENT (A)
Fig. 5 Typical Base-Emitter Turn-On Voltage
vs. Collector Current
1
0.2
0.0001
0.001
0.01
0.1
I
C
, COLLECTOR CURRENT (A)
Fig. 6 Typical Base-Emitter Saturation Voltage
vs. Collector Current
1
DN0150ALP4 / DN0150BLP4
Document number: DS31492 Rev. 7 - 2
3 of 5
www.diodes.com
May 2015
© Diodes Incorporated
DN0150ALP4 / DN0150BLP4
100
f = 1MHz
320
f
T
, GAIN-BANDWIDTH PRODUCT (MHz)
280
240
200
160
120
80
40
0
V
CE
= 6V
f = 30MHz
CAPACITANCE (pF)
10
C
ibo
NEW PRODUCT
1
C
obo
0
0.1
1
10
V
R
, REVERSE VOLTAGE (V)
Fig. 7 Typical Capacitance Characteristics
100
0
2
4
6
8
I
C
, COLLECTOR CURRENT (mA)
Fig. 8 Typical Gain-Bandwidth Product
vs. Collector Current
10
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for the latest version.
A
A1
D
b1
E
b2
e
X2-DFN1006-3
Dim Min
Max Typ
A
0.40
A1
0
0.05 0.02
b1
0.10 0.20 0.15
b2
0.45 0.55 0.50
D
0.95 1.05 1.00
E
0.55 0.65 0.60
e
0.35
L1
0.20 0.30 0.25
L2
0.20 0.30 0.25
L3
0.40
All Dimensions in mm
L2
L3
L1
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
C
X
1
X
G2
G1
Y
Z
Dimensions
Z
G1
G2
X
X1
Y
C
Value (in mm)
1.1
0.3
0.2
0.7
0.25
0.4
0.7
DN0150ALP4 / DN0150BLP4
Document number: DS31492 Rev. 7 - 2
4 of 5
www.diodes.com
May 2015
© Diodes Incorporated
DN0150ALP4 / DN0150BLP4
IMPORTANT NOTICE
DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDS TO THIS DOCUMENT,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the
application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or
trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume
all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated
website, harmless against all damages.
Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.
Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and
hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or
indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.
Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings
noted herein may also be covered by one or more United States, international or foreign trademarks.
This document is written in English but may be translated into multiple languages for reference. Only the English version of this document is the
final and determinative format released by Diodes Incorporated.
LIFE SUPPORT
Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express
written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:
A. Life support devices or systems are devices or systems which:
1. are intended to implant into the body, or
2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the
labeling can be reasonably expected to result in significant injury to the user.
B. A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the
failure of the life support device or to affect its safety or effectiveness.
Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any
use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related
information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its
representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.
Copyright © 2015, Diodes Incorporated
www.diodes.com
NEW PRODUCT
DN0150ALP4 / DN0150BLP4
Document number: DS31492 Rev. 7 - 2
5 of 5
www.diodes.com
May 2015
© Diodes Incorporated
