AD7547JNZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> AD7547JNZ

AD7547JNZ: DescriptionDUAL, PARALLEL, WORD INPUT LOADING, 0.8 us SETTLING TIME, 12-BIT DAC, PDIP24, ROHS COMPLIANT, PLASTIC, DIP-24; CategoryAnalog mixed-signal IC converter; File Size1MB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric View All

AD7547JNZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AD7547JNZ	-	-	View	Buy Now

AD7547JNZ Overview

DUAL, PARALLEL, WORD INPUT LOADING, 0.8 us SETTLING TIME, 12-BIT DAC, PDIP24, ROHS COMPLIANT, PLASTIC, DIP-24

AD7547JNZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	24
Reach Compliance Code	unknown
Converter type	D/A CONVERTER
Enter bit code	BINARY
Input format	PARALLEL, WORD
JESD-30 code	R-PDIP-T24
JESD-609 code	e3
length	31.165 mm
Maximum linear error (EL)	0.0244%
Humidity sensitivity level	NOT APPLICABLE
Number of digits	12
Number of functions	2
Number of terminals	24
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
Certification status	COMMERCIAL
Maximum seat height	5.33 mm
Nominal settling time (tstl)	0.8 µs
Nominal supply voltage	12 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
width	7.62 mm
